Electrolux FAVORIT 77009 Manuel utilisateur

FAVORIT 77009

DISHWASHER USER MANUAL

GESCHIRRSPÜLER BENUTZERINFORMATION

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have

created it to give you impeccable performance for many

years, with innovative technologies that help make life

simpler – features you might not find on ordinary

appliances. Please spend a few minutes reading to get the

very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to

keep all your AEG appliances looking spotless and

working perfectly. Along with a wide range of accessories

designed and built to the high quality standards you

would expect, from specialist cookware to cutlery baskets,

from bottle holders to delicate laundry bags…

Visit the webshop at:

www.aeg-electrolux.com/shop

CONTENTS

4 Safety information

8 Product description

9 Control panel

11 Use of the appliance

12 Setting the water softener

13 Use of dishwasher salt

14 Use of detergent and rinse aid

15 Multitab function

15 Loading cutlery and dishes

16 Washing programmes

17 Select and start a washing

programme

19 Care and cleaning

21 What to do if…

23 Technical data

24 Environment concerns

24 Installation

The following symbols are used in this user

manual:

Important information concerning your

personal safety and information on how to

avoid damaging the appliance.

General information and tips

Environmental information

Subject to change without notice

Contents 3

SAFETY INFORMATION

Before the installation and use, read this manual carefully:

• For your safety and the safety of your property.

• To help the environment.

• For the correct operation of the appliance.

Always keep these instructions with the appliance also if you move or give it to a different

person.

The manufacturer is not responsible if an incorrect installation and use causes damage.

Children and vulnerable persons safety

• Do not let persons, children included, with reduced physical sensory, reduced mental

functions or lack of experience and knowledge to use the appliance. They must have su-

pervision or instruction for the operation of the appliance by a person who is responsible

for their safety.

• Children must get supervision to make sure that they do not play with the appliance.

• Keep all packaging away from children. There is the risk of suffocation or injury.

• Keep all detergents in a safe area. Do not let the children touch the detergents.

• Keep children and pets away from the appliance when the door is open.

General safety

• Do not change the specifications of this appliance. There is the risk of injury and damage

to the appliance.

• Obey the safety instructions from the detergent manufacturer to prevent burns to eyes,

mouth and throat.

• Do not drink the water from the appliance. Particles of detergent can stay in your appli-

ance.

• Do not keep the appliance door open without supervision. This to prevent injury and to

fall on an open door.

• Do not sit or stand on the open door.

Use

• The appliance is only for domestic use. Do not use the appliance for other uses to pre-

vent injury to persons and damage to property.

• Only use the appliance to clean accessories that are applicable for dishwashers.

• Do not put flammable products or items that are wet with flammable products in, near

or on the appliance. Risk of explosion or fire.

• Put the knives and all items with sharp points in the cutlery basket with their points

down. If not, put in a horizontal position in the upper basket or in the knife basket. (Not

all models have the knife basket).

• Use only specified products for dishwashers (detergent, salt, rinse aid).

• Types of salt that are not specified for dishwashers can cause damage to the water soft-

ener.

4Safety information

• Fill the appliance with salt before you start a washing programme. Remaining salt in the

appliance can cause corrosion or make a hole in the bottom of the appliance.

• Do not fill the rinse aid dispenser with other products than the rinse aid, (dishwasher

cleaning agent, liquid detergent). This can cause damage to the appliance.

• Make sure that the spray arms can move freely before you start a washing programme.

• The appliance can release hot steam if you open the door while a washing programme

operates. There is a risk of skin burns.

• Do not remove the dishes from the appliance until the washing programme is comple-

ted.

Care and cleaning

• Before you clean the appliance, deactivate it and disconnect the mains plug from the

mains socket.

• Do not use flammable products or products that can cause corrosion.

• Do not use the appliance without the filters. Make sure that the installation of the filters

is correct. An incorrect installation causes unsatisfactory washing results and damage to

the appliance.

• Do not use spray water or steam to clean the appliance. Risk of electrical shock and

damage to the appliance.

Installation

• Make sure that the appliance is not damaged. Do not install or connect a damaged appli-

ance, contact the supplier.

• Remove all packaging before you install and use the appliance.

• Only a qualified person must do the electrical connection, the plumbing and the installa-

tion of the appliance. This to prevent the risks of structural damage or injury.

• Make sure that the mains plug is disconnected from the mains socket during installation.

• Do not drill into the sides of the appliance to prevent damage to hydraulic components

and electrical components.

Frost precautions

• Do not install the appliance where the temperature is less than 0 °C.

• The manufacturer is not responsible for frost damage.

Water connection

• Use new hoses to connect the appliance to the water supply. Do not use used hoses.

• Do not connect the appliance to new pipes or pipes not used for a long time. Let the

water flow for some minutes, then connect the inlet hose.

• Make sure not to squash or cause damage to the water hoses when you install the appli-

ance.

• Make sure that the water couplings are tight to prevent a water leakage.

• The first time you use the appliance, make sure that the hoses do not have water leaks.

Safety information 5

• The water inlet hose has a safety valve and a double sheath with an inner mains cable.

There is pressure in the water inlet hose only when the water flows. If there is a leak in

the water inlet hose, the safety valve interrupts the flow of water.

– Be careful when you connect the water inlet hose:

– Do not put the water inlet hose or the safety valve in water.

– If the water inlet hose or the safety valve are damaged, immediately disconnect the

mains plug from the mains socket.

– Contact the service centre to replace the water inlet hose with safety valve.

WARNING!

Dangerous voltage.

Electrical connection

• The appliance must be earthed.

• Make sure that the electrical information on the rating plate agrees with the power sup-

ply.

• Always use a correctly installed shockproof socket.

• Do not use multiple plugs and extension cables. There is a risk of fire.

• Do not replace or change the mains cable. Contact the service centre.

• Make sure not to squash or cause damage to the mains plug and cable behind the appli-

ance.

• Make sure that there is access to the mains plug after the installation.

• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

Internal lamp

This appliance has an internal lamp that comes on when you open the door and goes off

when the door is closed.

WARNING!

Visible led radiation, do not look directly into the beam.

The LED of the lamp is CLASS 2 and agrees with IEC 60825-1: 1993 + A1:1997 + A2:2001.

Emission wave length: 450 nm

Maximum emitted power: 548 μW

6Safety information

To replace the internal lamp, contact the service centre.

Disconnect the mains plug from the mains socket before the replacement of the internal

lamp.

Service centre

• Only a qualified person can repair or work on the appliance. Contact the service centre.

• Use only original spare parts.

To discard the appliance

• To prevent the risk of injury or damage:

– Disconnect the mains plug from the mains socket.

– Cut off the mains cable and discard it.

– Remove the door catch. This prevents children or pets to be closed in the appliance.

There is a risk of suffocation.

– Discard the appliance at the local waste disposal centre.

WARNING!

The dishwasher detergents are dangerous and can cause corrosion !

• If an accident occurs with these detergents, contact immediately a physician.

• If the detergent gets into the mouth, contact immediately a physician.

• If the detergent gets into the eyes, contact immediately a physician and clean the eyes

with water.

• Keep dishwasher detergents in a safe area and out of children touch.

• Do not keep the appliance door open when there is detergent in the detergent dispenser.

• Fill the detergent dispenser only before you start a washing programme.

Safety information 7

PRODUCT DESCRIPTION

1Upper basket

2Water hardness dial

3Salt container

4Detergent dispenser

5Rinse aid dispenser

6Rating plate

7Filters

8Lower spray arm

9Upper spray arm

10 Top spray arm

11 Worktop

8Product description

CONTROL PANEL

34 5 6

1On/off button

2Programme guide

3Program button

4Programme indicators

5Display

6Delay button

7Start button

8Indicators

9Option button

Indicators

Multitab indicator. It comes on when you activate the function.

Extra-Hygiene indicator. It comes on when you activate the function.

Washing phase indicator. It comes on when the washing phase operates.

Rinsing phase indicator. It comes on when the rinsing phases operate.

Drying phase indicator. It comes on when the drying phase operates.

End indicator. It comes on when the washing programme is completed.

Rinse aid indicator. It comes on when it is necessary to fill the rinse aid dispens-

er.

Salt indicator. It comes on when it is necessary to fill the salt container.

After you fill the container, the salt indicator can stay on for some hours. This

does not have an unwanted effect on the operation of the appliance.

Delay indicator. It comes on when you activate the delay start.

Control panel 9

Indicators

Door indicator. It comes on when the door is open or not closed correctly.

1) When the salt container and/or the rinse aid dispenser are empty, the related indicators do not come on while a

washing programme operates.

On/off button

Press this button to activate or deactivate the appliance.

After ten minutes from the end of the washing programme, the Auto Off function auto-

matically deactivates the appliance. This helps to decrease energy consumption.

Programme guide

This guide helps you in the selection of the washing programme.

Program button

Press this button again and again until the indicator of the washing programme comes on.

Refer to 'Washing programmes'.

Display

The display shows:

• The electronic adjustment of the level of the water softener

• The activation and deactivation of the rinse aid dispenser (only with the multitab func-

tion on)

• The washing programme time

• The remaining time to the end of the washing programme

• The end of a washing programme (the display shows a zero)

• The delay start time

• The alarm codes.

Delay button

Press this button again and again to delay the start of the washing programme from 1 to

24 hours.

Start button

Press this button to start:

• The washing programme

• The countdown of the delay start.

Option button

Press this button to set the functions.

When a function is activated, the related indicator comes on.

Option button Multitab Extra-Hygiene

Press one time ACTIVATED DEACTIVATED

Press two times DEACTIVATED ACTIVATED

10 Control panel

Table des matières

Langues :

Autres manuels Electrolux Lave-vaisselle

Electrolux

Electrolux ESL5310LO Manuel utilisateur

Electrolux

Electrolux ESL 47030 Manuel utilisateur

Electrolux

Electrolux ZANUSSI DCS12W Manuel utilisateur

Electrolux

Electrolux ESF6720ROW Manuel utilisateur

Electrolux

Electrolux ESL7510RO Manuel utilisateur

Electrolux

Electrolux ESF 6145 Manuel utilisateur

Electrolux

Electrolux Green&Clean EUCAI60 Manuel utilisateur

Electrolux

Electrolux KEZA9310L Manuel utilisateur

Electrolux

Electrolux EPPWELGM5 Manuel utilisateur

Electrolux

Electrolux GS 24 CH Manuel utilisateur

Electrolux

Electrolux ESL 6610RO Manuel utilisateur

Electrolux

Electrolux ESF6121 Manuel utilisateur

Electrolux

Electrolux TRICITY BENDIX DH 200 Manuel utilisateur

Electrolux

Electrolux FAVORIT 40760 Manuel utilisateur

Electrolux

Electrolux ESL4201LO Manuel utilisateur

Electrolux

Electrolux GA930IFWE Manuel utilisateur

Electrolux

Electrolux ESF 68040 Manuel utilisateur

Electrolux

Electrolux GA55SLI301 Manuel utilisateur

Electrolux

Electrolux EEA27200L Manuel utilisateur

Electrolux

Electrolux ESF 45010 Manuel utilisateur

Electrolux

Electrolux ESF 68040 Manuel utilisateur

Electrolux

Electrolux ESI5530LOW Manuel utilisateur

Electrolux

Electrolux WTCS90ERB Manuel utilisateur

Electrolux

Electrolux ESL 4115 Manuel utilisateur

Manuels Lave-vaisselle populaires d'autres marques

KitchenAid

KitchenAid KUDB230B Manuel utilisateur

Brandt

Brandt BDJ424DB Manuel utilisateur

Asko

Asko DSD767UXXL.AU Manuel utilisateur

Beko

Beko DFN26210W Manuel utilisateur

NEFF

NEFF S153ITX00E Fiche technique

Midea

Midea SV 4.45 wi Manuel utilisateur

LG LDF7932 Manuel utilisateur

Gorenje

Gorenje GV63214 Manuel utilisateur

Hotpoint

Hotpoint HDA1100ZWH Manuel de service

Blomberg

Blomberg LDFN2240W Manuel utilisateur

AEG

AEG FFB83836PM Manuel utilisateur

Cylinda

Cylinda DM3220RFD Manuel utilisateur

Atag

Atag DW8214MB Manuel utilisateur

GE GLD8000 Series Manuel utilisateur

Siemens

Siemens SN23HI02KE Fiche technique

Omega

Omega ODW717X Manuel utilisateur

BORETTI

BORETTI BVW-683 Manuel utilisateur

Siemens

Siemens SN 56N591 Manuel utilisateur
