FAVORIT 50674

User manual Dishwasher

Dear Customer

Thank you for choosing one of our high-quality products.

With this appliance you will experience the perfect combination of functional

design and cutting edge technology.

Convince yourself that our appliances are engineered to deliver the best

performance and control - indeed we are setting the highest standards of

excellence.

In addition to this you find environmental and energy saving aspects as an integral

part of our products.

To ensure optimal and regular performance of your appliance please read this

instruction manual carefully. It will enable you to navigate all processes perfectly

and most efficiently. To refer to this manual any time you need to, we recommend

you to keep it in a safe place. And please pass it to any future owner of the appliance.

We wish you much joy with your new appliance.

The following symbols are used in this user manual:

Important information concerning your personal safety and information on how

to avoid damaging the appliance.

General information and tips

Environmental information

Contents

Operating instructions 5

Safety information 5

Correct use 5

General safety 6

Child safety 6

Installation 6

Product description 7

Control panel 8

Setting mode 9

First use 10

Set the water softener 10

Setting manually 11

Setting electronically 11

Use of dishwasher salt 12

Use of rinse aid 13

Adjusting the dosage of rinse aid 14

Daily use 14

Loading cutlery and dishes 15

The lower basket 16

The cutlery basket 17

The upper basket 18

Use of detergent 19

Fill with detergent 19

Multi-tab function 20

Activation/deactivation of the Multi-Tab function 21

Washing programmes 22

Select and start a washing programme 22

Unloading the dishwasher 24

Care and cleaning 24

Contents 3

117980510-19092007

Cleaning the filters 24

Cleaning the spray arms 26

External cleaning 26

Internal cleaning 26

Prolonged periods of non-operation 26

Frost precautions 26

Moving the machine 27

What to do if ... 27

Technical data 29

Hints for test institutes 30

Installation instructions 32

Installation 32

Fitting under a counter (kitchen worktop or sink) 32

Levelling 33

Water supply connections 33

Water outlet hose connection 34

Electrical connection 35

Environment concerns 36

Packaging material 36

4Contents

Operating instructions

Safety information

In the interest of your safety and to ensure the correct use, before installing and

first using the appliance, read this user manual carefully, including its hints and

warnings. To avoid unnecessary mistakes and accidents, it is important to ensure

that all people using the appliance are thoroughly familiar with its operation and

safety features. Save these instructions and make sure that they remain with the

appliance if it is moved or sold, so that everyone using it through its life will be

properly informed on appliance use and safety.

Correct use

• This dishwasher is only intended for washing household utensils suitable for

machine washing.

• Do not put any solvents in the dishwasher. This could cause an explosion.

• Knives and other items with sharp points must be loaded in the cutlery basket

with their points down or placed in a horizontal position in the upper basket.

• Only use products (detergent, salt and rinse aid) suitable for dishwashers.

• Avoid opening the door whilst the appliance is in operation, hot steam may

escape.

• Do not take any dishes out of the dishwasher before the end of the dishwashing

cycle.

• After use, isolate the appliance from the power supply and turn off the water

supply.

• This product should be serviced only by an authorised service engineer, and only

genuine spare parts should be used.

• Under no circumstances should you attempt to repair the machine yourself.

Repairs carried out by inexperienced persons will cause injury or serious mal-

functioning. Contact your local Service Force Centre. Always insist on genuine

spare parts.

Safety information 5

General safety

• Dishwasher detergents can cause chemical burns to eyes, mouth and throat.

Could endanger life! Comply with the safety instructions of the dishwasher de-

tergent manufacturer.

• The water in your dishwasher is not for drinking. Detergent residues may still be

present in your machine.

• Ensure that the door of the dishwasher is always closed when it is not being

loaded or unloaded. In this way you will avoid anybody tripping over the open

door and hurting themselves.

• Do not sit or stand on the open door.

Child safety

• This appliance is designed to be operated by adults. Don’t allow children to use

the dishwasher unsupervised.

• Keep all packaging well away from children. There is risk of suffocation.

• Keep all detergents in a safe place out of children’s reach.

• Keep children well away from the dishwasher when the door is open.

Installation

• Check your dishwasher for any transport damage. Never connect a damaged

machine. If your dishwasher is damaged contact your supplier.

• All packaging must be removed before use.

• Any electrical and plumbing work required to install this appliance must be

carried out by a qualified and competent person.

• For safety reasons it is dangerous to alter the specifications or attempt to modify

this product in any way.

• Never use the dishwasher if the electrical supply cable and water hoses are

damaged; or if the control panel, work top or plinth area are damaged such that

the inside of the appliance is freely accessible. Contact your local Service Force

centre, in order to avoid hazard.

• All sides of the dishwasher must never be drilled to prevent damage to hydraulic

and electric components.

6Safety information

WARNING!

For electrical and water connection carefully follow the instructions given in

specific paragraphs.

Product description

1Upper basket

2Water hardness dial

3Salt container

4Detergent dispenser

5Rinse aid dispenser

6Rating plate

7Filters

8Lower spray arm

9Upper spray arm

Product description 7

10 Worktop

Control panel

1On/off button

2Programme selection buttons

3Delay start button

4Indicator lights

5Digital display

6Function buttons

Indicator lights

Programme in progress Illuminates when a washing programme is set

and remains illuminated for all the duration of

the washing programme.

8Control panel

Indicator lights

End of programme Illuminates when a washing programme has

ended. It also has added functions of visual sig-

nalling as:

- the setting of the water softener

- activation/deactivation of the rinse aid

dispenser

- intervention of an alarm due to the malfunc-

tion of the machine

MULTITAB Indicates the activation/deactivation of the

Multi-tab function (see Multi-tab function)

Salt Illuminates when the special salt has run out.

Rinse aid Illuminates when the rinse aid has run out.

1) The salt and rinse aid indicator lights are never illuminated while a washing programme is running even if filling

with salt and/or rinse aid is necessary.

Function buttons

In addition to the programme selection, the setting of the water softener and the

activation/deactivation of the rinse aid dispenser can also be set with the help of

these buttons.

Setting mode

The appliance is in setting mode when all programme lights are illuminated and

in the display 3 horizontal lines are visible.

Always remember that when performing operations such as:

• selecting a washing programme

• setting the water softener

• activating/deactivating the rinse aid dispenser

the appliance MUST be in setting mode.

If a programme light is illuminated and in the display 1 horizontal line is visible,

the last performed programme is still set.

In this case, to return to setting mode, the programme has to be cancelled.

Control panel 9

To cancel a set programme or a programme in progress: simultaneously press

and hold the two programme buttons positioned over the word RESET, until all the

programme button lights will illuminate. The programme has been cancelled and

the machine is now in setting mode.

First use

Before using your dishwasher for the first time:

• Ensure that the electrical and water connections comply with the installation

instructions

• Remove all packaging from inside the appliance

• Set the water softener

• Pour 1 litre of water inside the salt container and then fill with dishwasher salt

• Fill the rinse aid dispenser

If you want to use combi detergent tablets such as: "3 in 1", "4 in 1", "5 in 1" etc...

set the Multi-tab function (see "Multi-tab function").

Set the water softener

The dishwasher is equipped with a water softener designed to remove minerals and

salts from the water supply, which would have a detrimental or adverse effect on

the operation of the appliance.

The higher the content of these minerals and salts, the harder your water is. Water

hardness is measured in equivalent scales, Clarke degrees, French degrees (°TH) and

mmol/l (millimol per litre - international unit for the hardness of water).

The softener should be adjusted according to the hardness of the water in your

area. Your local Water Authority can advise you on the hardness of the water in

your area.

Water hardness Adjusting the water hardness

setting

Use of salt

Clarke °TH mmol/l manually electronically

64 - 88 91 - 125 9,1 - 12,5 2level 10 yes

53 - 63 76 - 90 7,6 - 8,9 2level 9 yes

10 First use
