Electrolux ESF 8530ROW Manuel utilisateur

ESF 8530ROW

ESF 8530ROX EN DISHWASHER USER MANUAL 2

PT MÁQUINA DE LAVAR

LOIÇA

MANUAL DE INSTRUÇÕES 20

ES LAVAVAJILLAS MANUAL DE INSTRUCCIONES

CONTENTS

1. SAFETY INFORMATION...................................................................................... 3

2. SAFETY INSTRUCTIONS.....................................................................................4

3. PRODUCT DESCRIPTION................................................................................... 5

4. CONTROL PANEL ..............................................................................................6

5. PROGRAMMES...................................................................................................7

6. SETTINGS........................................................................................................... 8

7. OPTIONS...........................................................................................................11

8. BEFORE FIRST USE..........................................................................................11

9. DAILY USE........................................................................................................ 13

10. HINTS AND TIPS............................................................................................. 14

11. CARE AND CLEANING....................................................................................15

12. TROUBLESHOOTING......................................................................................17

13. TECHNICAL INFORMATION............................................................................18

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can be

safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes

injuries and damages. Always keep the instructions with

the appliance for future reference.

1.1 General Safety

•This appliance is intended to be used in household and

similar applications such as:

–farm houses; staff kitchen areas in shops, offices and

other working environments;

–by clients in hotels, motels, bed & breakfast and

other residential type environments.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and maximum)

must be between 0.5 (0.05) / 8 (0.8) bar (Mpa)

•Obey the maximum number of 15 place settings.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•Put knives and cutlery with sharp points in the cutlery

basket with the points down or in a horizontal position.

•Do not keep the appliance door open without

supervision to prevent to fall on it.

•Before maintenance, deactivate the appliance and

disconnect the mains plug from the mains socket.

•Do not use water spray and steam to clean the

appliance.

•The ventilation openings in the base (if applicable) must

not be obstructed by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

ENGLISH 3

1.2 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•Cleaning and user maintenance shall not be made by

children without supervision.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature is less than 0

°C.

• Obey the installation instruction

supplied with the appliance.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the mains cable need to be

replaced, this must be carried out by

our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the E.E.C.

Directives.

• Only for UK and Ireland. The appliance

has a 13 amp mains plug. If it is

necessary to change the fuse in the

mains plug, use fuse: 13 amp ASTA

(BS 1362).

2.3 Water connection

• Make sure not to cause damage to the

water hoses.

• Before you connect the appliance to

new pipes or pipes not used for a long

time, let the water flow until it is clean.

• The first time you use the appliance,

make sure that there is no leakage.

• The water inlet hose has a safety valve

and a sheath with an inner mains

cable.

www.electrolux.com4

WARNING!

Dangerous voltage.

• If the water inlet hose is damaged,

immediately disconnect the mains plug

from the mains socket. Contact the

Authorised Service Centre to replace

the water inlet hose.

2.4 Use

• Do not sit or stand on the open door.

• Dishwasher detergents are dangerous.

Obey the safety instructions on the

detergent packaging.

• Do not drink and play with the water in

the appliance.

• Do not remove the dishes from the

appliance until the programme is

completed. There can be detergent on

the dishes.

• The appliance can release hot steam if

you open the door while a programme

operates.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

2.5 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. PRODUCT DESCRIPTION

11 10 78

1Worktop

2Top spray arm

3Upper spray arm

4Lower spray arm

5Filters

6Rating plate

7Salt container

8Air vent

ENGLISH 5

9Rinse aid dispenser

10 Detergent dispenser

11 Lower basket

12 Upper basket

13 Cutlery drawer

4. CONTROL PANEL

2 4

1On/off button

2Program button

3Programme indicators

4Display

5Delay button

6Start button

7Indicators

8Option button

4.1 Indicators

Indicator Description

Washing phase. It comes on when the washing phase and the rinsing

phases operate.

Drying phase. It comes on when the drying phase operates.

Multitab indicator.

Salt indicator. It is always off while the programme operates.

Rinse aid indicator. It is always off while the programme operates.

TimeManager indicator.

www.electrolux.com6

5. PROGRAMMES

Programme Degree of soil

Type of load Programme pha-

ses Options

1) • Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• TimeManager

• Multitab

2) • All

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash from 45 °C

to 70 °C

• Rinses

• Dry

• Multitab

3) • Mixed soil

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash 50 °C and

65 °C

• Rinses

• Dry

• TimeManager

• Multitab

4) • Heavy soil

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash 70 °C

• Rinses

• Dry

• TimeManager

• Multitab

5) • Fresh soil

• Crockery and

cutlery

• Wash 60 °C

• Rinses • Multitab

6) • All • Prewash

1) With this programme you have the most efficient use of water and energy consumption for

crockery and cutlery with normal soil. (This is the standard programme for test institutes).

2) The appliance senses the degree of soil and the quantity of items in the baskets . It auto-

matically adjusts the temperature and the quantity of water, the energy consumption and the

programme duration.

3) With this programme you can wash a load with mixed soil. Very heavy soil in the lower bas-

ket and normal soil in the upper basket. The pressure and the temperature of the water in the

lower basket are higher than in the upper basket.

4) This programme has a high temperature rinsing phase for better hygiene results. During the

rinsing phase, the temperature stays at 70 °C for at least 10 minutes.

5) With this programme you can wash a load with fresh soil. It gives good washing results in a

short time.

6) With this programme you can quickly rinse dishes to prevent remains of food to bond on

dishes and odours to form in the appliance. Do not use detergent with this programme.

5.1 Consumption values

Programme 1) Water

(l) Energy

(kWh) Duration

(min)

11 0.961 225

ENGLISH 7

Programme 1) Water

(l) Energy

(kWh) Duration

(min)

7 - 14 0.6 - 1.4 40 - 150

14 - 16 1.2 - 1.5 139 - 149

12.5 - 14.5 1.4 - 1.6 154 - 164

10 0.9 30

4 0.1 14

1) The pressure and the temperature of the water, the variations of the mains supply, the op-

tions and the quantity of dishes can change the values.

5.2 Information for test institutes

For all the necessary information for test

performance, send an email to:

[email protected]

Write down the product number (PNC)

that is on the rating plate.

6. SETTINGS

6.1 Programme selection mode

and user mode

When the appliance is in programme

selection mode it is possible to set a

programme and to enter the user mode.

In user mode, the following settings

can be changed:

• The level of the water softener

according to the water hardness.

• The activation or the deactivation of the

acoustic signal for end of programme.

• The deactivation of the rinse aid

dispenser when you want to use the

Multitab option without rinse aid.

• The level of rinse aid according to the

required dosage.

These settings will be saved until you

change them again.

How to set the programme

selection mode

The appliance is in programme selection

mode when the programme indicator

is on and the display shows the

programme duration.

When you activate the appliance, usually it

is in programme selection mode.

However, if this does not happen, you can

set the programme selection mode in the

following way:

Press and hold simultaneously Program

and Option until the appliance is in

programme selection mode.

6.2 The water softener

The water softener removes minerals from

the water supply, which would have a

detrimental effect on the washing results

and on the appliance.

The higher the content of these minerals,

the harder your water is. Water hardness

is measured in equivalent scales.

The water softener should be adjusted

according to the hardness of the water in

your area. Your local water authority can

advise you on the hardness of the water in

your area. It is important to set the right

level of the water softener to assure good

washing results.

www.electrolux.com8

Water hardness

German de-

grees (°dH) French de-

grees (°fH) mmol/l Clarke de-

grees Water softener

level

47 - 50 84 - 90 8.4 - 9.0 58 - 63 10

43 - 46 76 - 83 7.6 - 8.3 53 - 57 9

37 - 42 65 - 75 6.5 - 7.5 46 - 52 8

29 - 36 51 - 64 5.1 - 6.4 36 - 45 7

23 - 28 40 - 50 4.0 - 5.0 28 - 35 6

19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)

15 - 18 26 - 32 2.6 - 3.2 18 - 22 4

11 - 14 19 - 25 1.9 - 2.5 13 - 17 3

4 - 10 7 - 18 0.7 - 1.8 5 - 12 2

<4 <7 <0.7 < 5 1 2)

1) Factory setting.

2) Do not use salt at this level.

How to set the water softener

level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously Delay and Start

until the indicators ,

, and start to flash

and the display is blank.

2. Press Program.

• The indicators , and

go off.

• The indicator continues to

flash.

• The display shows the current

setting: e.g. = level 5.

3. Press Program again and again to

change the setting.

4. Press the on/off button to confirm the

setting.

6.3 The rinse aid dispenser

The rinse aid helps to dry the dishes

without streaks and stains.

The rinse aid is automatically released

during the hot rinse phase.

You can set the released quantity of rinse

aid between level 1 (minimum quantity)

and level 6 (maximum quantity). Level 0

will deactivate the rinse aid dispenser and

no rinse aid will be released.

Factory setting: level 4.

How to set the rinse aid level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously Delay and Start

until the indicators ,

, and start to flash

and the display is blank.

2. Press Delay.

• The indicators ,

and go off.

• The indicator continues to

flash.

• The display shows the current

setting: e.g. = level 4.

ENGLISH 9

– The levels of rinse aid are from

0A to 6A.

– Level 0 = no rinse aid is

released.

3. Press Delay again and again to

change the setting.

4. Press the on/off button to confirm the

setting.

6.4 Use of rinse aid and multi-

tablets

The factory setting of the rinse aid

dispenser is with the dispenser activated.

This means that the rinse aid dispenser

always releases rinse aid.

It is possible to deactivate the rinse aid

dispenser, in this case the dispenser will

not release rinse aid only if the option

Multitab is activated.

If the dispenser is deactivated and you do

not select the option Multitab, the

dispenser will release rinse aid.

The use of the option Multitab with the

rinse aid dispenser deactivated may not

give satisfying drying results.

When the rinse aid dispenser is

deactivated, the rinse aid indicator is

always off when the option Multitab is

activated.

How to deactivate the rinse aid

dispenser

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously Delay and Start

until the indicators ,

, and start to flash

and the display is blank.

2. Press Option.

• The indicators , and

go off.

• The indicator continues

to flash.

• The display shows the current

setting: = the rinse aid

dispenser is activated (factory

setting).

3. Press Option to change the setting.

= the rinse aid dispenser is

deactivated.

4. Press the on/off button to confirm the

setting.

6.5 Acoustic signals

Acoustic signals sound when a

malfunction of the appliance occurs. It is

not possible to deactivate these acoustic

signals.

There is also an acoustic signal that

sounds when the programme is

completed. By default this acoustic signal

is deactivated but it is possible to activate

it.

How to activate the acoustic

signal for the end of programme

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously Delay and Start

until the indicators ,

, and start to flash

and the display is blank.

2. Press Start

• The indicators ,

and go off.

• The indicator continues to flash.

• The display shows the current

setting: = Acoustic signal off.

3. Press Start to change the setting.

= Acoustic signal on.

4. Press the on/off button to confirm the

setting.

6.6 MyFavourite

With this option you can set and save the

programme that you use more frequently.

You can only save 1 programme. A new

setting cancels the previous one.

www.electrolux.com10

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Electrolux Lave-vaisselle

Electrolux

Electrolux ESF 662 Manuel utilisateur

Electrolux

Electrolux FAVORIT 88014 I Manuel utilisateur

Electrolux

Electrolux ESF 6800ROW Manuel utilisateur

Electrolux

Electrolux ESI5530LOW Manuel utilisateur

Electrolux

Electrolux ARTHUR MARTIN ASL67050 Manuel utilisateur

Electrolux

Electrolux 506029 Manuel utilisateur

Electrolux

Electrolux ESF5533LOX Manuel utilisateur

Electrolux

Electrolux EEA17200L Manuel utilisateur

Electrolux

Electrolux EDW5505ESS Manuel utilisateur

Electrolux

Electrolux EIDW6405HT - Fully Integrated Dishwasher Manuel utilisateur

Electrolux

Electrolux FAVORIT 65010 VI Manuel utilisateur

Electrolux

Electrolux EIDW1805KS Manuel utilisateur

Electrolux

Electrolux Zanussi DA 4441 Manuel utilisateur

Electrolux

Electrolux ESL 4200LO Manuel utilisateur

Electrolux

Electrolux EES48400L Manuel utilisateur

Electrolux

Electrolux EEQ47310L Manuel utilisateur

Electrolux

Electrolux FAVORIT 65511 VI Manuel utilisateur

Electrolux

Electrolux GA55GLI220 Manuel utilisateur

Electrolux

Electrolux GA60LI221 Manuel utilisateur

Electrolux

Electrolux NUC1DDRUKP Manuel utilisateur

Electrolux

Electrolux ESL 4114 Manuel utilisateur

Electrolux

Electrolux GA553IF Manuel utilisateur

Electrolux

Electrolux ESL 7310RO Manuel utilisateur

Electrolux

Electrolux TW1E Manuel utilisateur

Manuels Lave-vaisselle populaires d'autres marques

KitchenAid

KitchenAid KUDB230B Manuel utilisateur

Brandt

Brandt BDJ424DB Manuel utilisateur

Asko

Asko DSD767UXXL.AU Manuel utilisateur

Beko

Beko DFN26210W Manuel utilisateur

NEFF

NEFF S153ITX00E Fiche technique

Midea

Midea SV 4.45 wi Manuel utilisateur

LG LDF7932 Manuel utilisateur

Gorenje

Gorenje GV63214 Manuel utilisateur

Hotpoint

Hotpoint HDA1100ZWH Manuel de service

Blomberg

Blomberg LDFN2240W Manuel utilisateur

AEG

AEG FFB83836PM Manuel utilisateur

Cylinda

Cylinda DM3220RFD Manuel utilisateur

Atag

Atag DW8214MB Manuel utilisateur

GE GLD8000 Series Manuel utilisateur

Siemens

Siemens SN23HI02KE Fiche technique

Omega

Omega ODW717X Manuel utilisateur

BORETTI

BORETTI BVW-683 Manuel utilisateur

Siemens

Siemens SN 56N591 Manuel utilisateur
