Electrolux ESF 63020 Manuel utilisateur

user manual

Dishwasher

ESF 63020

We were thinking of you

when we made this product

Welcome to the world of Electrolux

You’ve chosen a first class product from Electrolux,

which hopefully will provide you with lots of pleasure in

the future. Electrolux ambition is to offer a wide variety of

quality products that would make your life even more

comfortable. You can look at some examples on the

cover in this manual. But now it’s time to study this

manual and start using and enjoying the benefits from

your new machine. We promise that it’ll make your life a

little easier. Good luck!

The following symbols are used in this user manual:

Important information concerning your personal safety and information on

how to avoid damaging the appliance.

General information and tips

Environmental information

156994410-00-15062007

electrolux 3

Contents

Safety information 5

Product description 7

Control panel 7

First use 9

Set the water softener 10

Filling with dishwasher salt 12

Use of rinse aid 13

Adjusting the dosage of rinse aid

Daily use 14

Loading cutlery and dishes 15

Use of detergent 18

Select and start a washing

programme 20

Unloading the dishwasher 22

Washing programmes 22

Care and cleaning 23

Something not working 26

Technical data 29

Consumption values 29

Hints for test institutes 30

Installation 31

Environment concerns 34

4 electrolux

Safety information

In the interest of your safety and to

ensure the correct use, before in-

stalling and first using the appliance,

read this user manual carefully, in-

cluding its hints and warnings. To

avoid unnecessary mistakes and ac-

cidents, it is important to ensure that

all people using the appliance are

thoroughly familiar with its opera-

tion and safety features. Save these

instructions and make sure that they

remain with the appliance if it is

moved or sold, so that everyone us-

ing it through its life will be properly

informed on appliance use and

safety.

Correct use

• This dishwasher is only intended for

washing household utensils suitable

for machine washing.

• Do not put any solvents in the

dishwasher. This could cause an ex-

plosion.

• Knives and other items with sharp

points must be loaded in the cutlery

basket with their points down or

placed in a horizontal position in the

upper basket.

• Only use products (detergent, salt and

rinse aid) suitable for dishwashers.

• Avoid opening the door whilst the ap-

pliance is in operation, hot steam may

escape.

• Do not take any dishes out of the

dishwasher before the end of the dish-

washing cycle.

• After use, isolate the appliance from

the power supply and turn off the wa-

ter supply.

• This product should be serviced only

by an authorised service engineer,

and only genuine spare parts should

be used.

• Under no circumstances should you

attempt to repair the machine your-

self. Repairs carried out by inexper-

ienced persons will cause injury or

serious malfunctioning. Contact your

local Service Force Centre. Always in-

sist on genuine spare parts.

General safety

• Dishwasher detergents can cause

chemical burns to eyes, mouth and

throat. Could endanger life! Comply

with the safety instructions of the

dishwasher detergent manufacturer.

• The water in your dishwasher is not for

drinking. Detergent residues may still

be present in your machine.

• Ensure that the door of the

dishwasher is always closed when it is

not being loaded or unloaded. In this

way you will avoid anybody tripping

over the open door and hurting them-

selves.

• Do not sit or stand on the open door.

safety information electrolux 5

Child safety

• This appliance is designed to be

operated by adults. Don’t allow chil-

dren to use the dishwasher unsuper-

vised.

• Keep all packaging well away from

children. There is risk of suffocation.

• Keep all detergents in a safe place out

of children’s reach.

• Keep children well away from the

dishwasher when the door is open.

Installation

• Check your dishwasher for any trans-

port damage. Never connect a dam-

aged machine. If your dishwasher is

damaged contact your supplier.

• All packaging must be removed be-

fore use.

• Any electrical and plumbing work re-

quired to install this appliance must be

carried out by a qualified and compe-

tent person.

• For safety reasons it is dangerous to

alter the specifications or attempt to

modify this product in any way.

• Never use the dishwasher if the elec-

trical supply cable and water hoses

are damaged; or if the control panel,

work top or plinth area are damaged

such that the inside of the appliance is

freely accessible. Contact your local

Service Force centre, in order to avoid

hazard.

• All sides of the dishwasher must never

be drilled to prevent damage to

hydraulic and electric components.

For electrical and water connection

carefully follow the instructions

given in specific paragraphs.

6 electrolux safety information

Product description

1Upper basket

2Water hardness dial

3Salt container

4Detergent dispenser

5Rinse aid dispenser

6Rating plate

7Filters

8Lower spray arm

9Upper spray arm

10 Worktop

product description electrolux 7

Control panel

1Programme guide

2Programme knob

3Start/cancel button

4Delay start button

5Indicator lights

6On/Off indicator light

7Programme marker

Indicator lights

Wash Illuminates when the washing and rins-

ing phases are running.

Dry Illuminates when the drying phase is

running.

End of programme Illuminates when the washing pro-

gramme has ended. It also has added

functions of visual signalling as:

• the setting of the water softener,

• intervention of an alarm due to the

malfunction of the machine.

Salt refilling

Illuminates when special salt needs to

be filled.

8 electrolux control panel

Indicator lights

Rinse aid

Illuminates when rinse aid needs to be

filled.

1) The salt and rinse aid indicator lights are never illuminated while a washing programme is running even

if filling with salt and rinse aid is necessary.

The salt indicator light on the control

panel can remain illuminated for 2-6

hours after the salt has been

replenished, assuming the

dishwasher remains switched on. If

you are using salts that take longer

to dissolve then this can take longer.

The function of the machine is not

affected.

Programme knob and On/Off

indicator light

• The selection of a washing pro-

gramme occurs by turning the pro-

gramme knob clockwise or anticlock-

wise, until the programme marker,

placed on the knob, corresponds with

the desired washing programme indi-

cated on the control panel.

The On/Off indicator light illuminates

(position ON)

• To switch off the appliance turn the

programme knob until the pro-

gramme marker corresponds with the

On/Off indicator light. The On/Off in-

dicator light turns off (position OFF).

With the programme knob it is also

possible to set the level of the water

softener.

First use

Before using your dishwasher for the first

time:

• Ensure that the electrical and water

connections comply with the installa-

tion instructions

• Remove all packaging from inside the

appliance

• Set the water softener

• Pour 1 litre of water inside the salt

container and then fill with dishwasher

salt

• Fill the rinse aid dispenser

first use electrolux 9

If you want to use combi detergent

tablets ("3 in 1", "4 in 1", "5 in 1"

etc... ) follow the instructions given

in "Use of detergent".

Set the water softener

The dishwasher is equipped with a water

softener designed to remove minerals

and salts from the water supply, which

would have a detrimental or adverse ef-

fect on the operation of the appliance.

The higher the content of these minerals

and salts, the harder your water is. Water

hardness is measured in equivalent

scales, German degrees (°dH), French

degrees (°TH) and mmol/l (millimol per

litre - international unit for the hardness

of water).

The softener should be adjusted accord-

ing to the hardness of the water in your

area. Your local Water Authority can ad-

vise you on the hardness of the water in

your area.

The water softener must be set in

both ways: manually and

electronically.

Water hardness Adjusting the water

hardness setting

Use of salt

°dH °TH mmol/l manually electronic

ally

51 - 70 91 - 125 9,1 - 12,5 2level 10 yes

43 - 50 76 - 90 7,6 - 8,9 2level 9 yes

37 - 42 65 - 75 6,51 - 7,5 2level 8 yes

29 - 36 51 - 64 5,1 - 6,4 2level 7 yes

23 - 28 40 - 50 4,0 - 5,0 2level 6 yes

19 - 22 33 - 39 3,3 - 3,9 2level 5 yes

15 - 18 26 - 32 2,61 - 3,2 1level 4 yes

11 - 14 19 - 25 1,9 - 2,5 1level 3 yes

4 - 10 7 - 18 0,71 - 1,8 1level 2 yes

10 electrolux set the water softener
