ISLAND

USER MANUAL

COOKER HOOD

eiQCURVISL90SS

eiQCURVISL90BL

CONTENTS

SAFETY PRECAUTIONS 2

INTRODUCTION 4

DIMENSIONS 4

UNPACKING YOUR APPLIANCE 4

PRODUCT OVERVIEW – PARTS SUPPLIED 5

OPTIONS FOR VENTILATION 6

OPERATION 12

MAINTENANCE 13

TROUBLESHOOTING 15

MANUFACTURER SUPPORT 15

SPECIFICATION 16

SAFETY PRECAUTIONS

Whilst this product complies with all safety requirements, incorrect

or inappropriate use can lead to personal injury and potential

damage to property. Please read the contents of this instruction

booklet or using this cooker hood.

· The cooker hood must be installed in accordance with the

installation instructions provided, making sure all measurements

and guidance are followed.

· All installation work must be carried out electrician

or a competent person.

· If venting externally, make sure the ducting has no bends sharper

than 90 degrees as this will

of the cooker hood.

· The cooker hood is for domestic use only and is not designed for

commercial use. It should only be us ed for the purpose it was

intended – to extract vapours and cooking odours.

· Do use an cooker hood.

· Do not try to use the cooker hood without the supplied grease

, or if excessively greasy. The filters should be

cleaned regularly following the guidance provided , and replaced

if necessary.

· Clean your appliance regularly, by following the method provided

in this manual. Failing to maintain the unit would increase the risk

· Do not discharge the air into

fumes from other appliances burning gas or other fuels.

· Do not leave frying pans unattended during use because

overheated fat or oils might catch .

· If the cooker hood is damaged, do not attempt to use it

· If the supply cord is

damaged , it must be replaced by the

manufacturer, its service agent, or

order to avoid an accident.

· cooker hood should not be used by people

(including children) with reduced physical , sensory , or mental

capabilities, or by those who lack experience and knowledge ,

unless they have been given supervision and instruction on how

to use the appliance by a person responsible for their safety.

· Accessible parts may become hot when

used with cooking

appliances.

· This cooker hood is not a toy and children should be supervised

to ensure they do not play with it.

· The plug must be accessible after installation in case you need to

isolate it in an emergency. If the unit is hardwired to the mains via

a spur, a fused switch should be installed and accessible for it.

· The minimum distance between the hob surface and the lowest

part of the hood should be at least 65cm.

70cm and 80cm gives peak .

· The room MUST be adequately ventilated when the hood is in

use.

· Regulations concerning the discharge of air have to .

· If used in recirculation mode, the charcoal and

must be replaced at

least once a year

depending on how

frequently the cooker hood has been used.

CAUTION: Accessible parts of the hood can become very hot

during use with cooking appliances, even when not in use, due

to heat rising from the hob . Sufﬁcient cooling time should be

allowed before touching either the housing or the grease ﬁlters.

INTRODUCTION

Thank you for choosing an electriQ cooker hood.

This instruction manual is designed to provide you with all required

instructions related to the installation, use and maintenance of the appliance.

In order to operate the unit correctly and safely, please read this instruction

manual carefully before installation and usage.

YOUR APPLIANCE

• Please take great care when unpacking; a sharp blade should not be used

to open the box, as it may go deep enough inside to damage components.

Components damaged or marked by careless unpacking are not covered

under the guarantee.

• Carefully unpack the contents and check against the next section (Product

overview – parts supplied)

• Packaging materials should be recycled in accordance with local

regulations

DIMENSIONS OF THE HOOD

PRODUCT OVERVIEW - SUPPLIED

Description Illustration Qty.

Cooker hood

Chimney

Adaptor

Cable Tie 1

Wall Bracket

Hanging hook 1

Metal angle bar 8

Screw (ST4) (4mm x

30mm)

Wall plug

Expansion bolt

(6mm x 50mm)

Screw (M5) (5mm x

10mm)

Screw (self-tapping)

(4mm x 6mm)

Nut

Metal washer 16

Air Flaps

OPTIONS

This hood supports both external venting or recirculation. The type of setup

should be decided before commencing installation.

EXTERNAL VENTING

A pipe is provided which allows

the cooking odours to be extracted

outside. If this is the chosen installation

method consideration to the route of the

vent pipe should be made. The mounting

plate contains a hole allowing the vent

pipe to be connected and routed through the

ceiling.

If a vent pipe is to run through the ceiling a hole with a diameter of around

170mm should be made in the ceiling before installation. This would allow the

vent pipe to run through the mounting plate.

This cooker hood also supports the recirculation of air

once it has passed through the . The ltered air is

then expelled through the vent holes in the side of the

chimney.

When setting the unit up in this , carbon

also be used to remove odours from the air.

Details of sourcing the can be found in

the Carbon section.

Do not connect the hood to the mains supply before installing it .

1. Position the hanging plate on the ceiling

and then mark the position of the screw

holes with a pencil.

Securely the hanging plate to the ceiling,

using (30 mm) screws.

Please ensure that the bracket is in a way it would support the weight of

the hood.

Depending on the construction of the ceiling, alternative may be

required. 6 x expansion bolts are also provided to allow to concrete.

2. Fix the angle bars to the hanging plate, using

the 8 x M5 screws.

3. Extend the angle bars to the required height and then

them in position using the 16 x M5 screws. The

angle bars must have an overlap of at least 100mm.

4. At this point, if the unit is to be externally vented

connect the ducting hose to the hanging plate.

Then upper chimney section to the hanging

plate, using the 4 x self-tapping screws (4mm x

6mm).

Slide the lower chimney section onto the angle bars

and raise it until it sits just below the upper chimney

section.

Use the hanging hook to temporarily keep the lower

chimney section in this position, to make sure that it

does not drop down whilst the main body of the hood to the angle bars.

5. On the top of the hood unit, where the air outlet vent is located, the 2 x air

should be carefully installed, bending very slightly so the lugs at each

end the holes This enables to pivot upwards when the unit

is in operation, opening up the outlet fully for the air to pass through.

Please note: The small spindles/lugs at each end of each the

holes on the housing, not the grooves above them:

6. Lift the main body of the cooker hood

onto the angle bar and then it into

position using the 16 x M5 screws.

This stage of the installation process MUST

be completed by two people, as one person

must support the weight of the hood until all

16 of the M4 screws have been securely

tightened.

8. The unit should then be connected to a suitable power source, either by

using the supplied plug, or hardwiring the unit into a spur. Please note if

hard wiring the unit, a suitable switch should be in a conveniently

accessible position.

9. Remove the hanging hook and

then slide the lower chimney

section downwards, until it rests

against the main body of the

cooker hood.

FOR MINIMUM CHIMNEY

LENGTH

Do not connect the hood to the mains supply before installing it.

1. Position the hanging plate on the ceiling

and then mark the position of the screw

holes with a pencil.

Securely the hanging plate to the

ceiling, using x ST4 (30 mm)

screws.

Please ensure that the bracket is in a way it would support the weight of

the hood. Depending on the construction of the ceiling, alternative may

be required. 6 x expansion bolts are also provided to allow to concrete.

2. Calculate the length of the angle bars

according to the overall height of the hood

required. Extend the angle bars to the

requi in position

using the 16 x M5 screws. The angle bars

must have an overlap of at least 100mm.

3. On the top of the hood unit , where the air outlet vent is located, the 2 x

air should be carefully installed, bending very slightly so the lugs at

each end the holes This enables to pivot upwards when

the unit is in operation, opening up the outlet fully for the air to pass

through
