Elation ELAR DW BRICK Manuel utilisateur

Rev. 01/06/2011 Version 1.3

Elation Professional™

6122 S. Eastern Ave.

Los Angeles, CA. 90040

www.elationlighting.com

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 1 www.ElationLighting.com

TABLE OF CONTENS

CONTENTS

1. General Information………………………………………………………………………2

a. Introduction……………………………………………………………………….2

b. Unpacking………………………………………………………..…………..… 2

c. Customer Support…………………………………………….………………… 2

d. Warranty Registration……………………………………………………..…… 3

2. Safety Instructions………………………………………………………........…………. 4

3. Features……………………………………………………………………………………6

4. General Guidelines……………………………………………………………………….7

5. Fixture Overview…………………………………………………………………………. 8

6. Mounting and Installation………………………………………………………….……. 10

7. Understanding DMX……………………………………………………………………...12

a. DMX Connections………………………………………………………………. 12

b. DMX Terminator………………………………………………………………….13

c. 3-Pin to 5-Pin Conversion……………………………………………………….14

d. Understanding DMX Addressing.………………………………………………14

8. Display LED Indicator….…………………………………………………………………16

9. DISPLAY MENU….……………………………………………………………………… 17

10. DMX Traits…………………………………………………………………………………24

11. Cleaning and Maintenance………………………………………………………………27

12. Warranty…………………………………………………………………………………...28

13. Photometric Data………………………………………………………………………… 30

14. Dimensional Drawings………………………………………………….……………….. 31

15. Change lens to get different beam angles……………………………………………. 32

16. Circuit Schematic………...……………………………………………………………….33

17. Technical Specifications…………………………………………...………….………… 34

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 2 www.ElationLighting.com

1. GENERAL INFORMATION

INTRODUCTION: Congratulations, you have just purchased one of the most innovative and

reliable LED fixtures on the market today! The ELAR DW BRICK™ has been designed to

perform reliably for years when the guidelines in this booklet are followed. Please read and

understand the instructions in this manual carefully and thoroughly before attempting to

operate this unit. These instructions contain important information regarding safety during

use and maintenance.

UNPACKING: Thank you for purchasing the ELAR DW BRICK™ by Elation Professional®.

Every ELAR DW BRICK™ has been thoroughly tested and has been shipped in perfect

operating condition. Carefully check the shipping carton for damage that may have occurred

during shipping. If the carton appears to be damaged, carefully inspect your fixture for

damage and be sure all accessories necessary to operate the fixture have arrived intact. In

the event damage has been found or parts are missing, please contact our customer support

team for further instructions. Please do not return this unit to your dealer without first

contacting customer support at the number listed below.

Inside the box you should find: the fixture,Two DMX XLR waterproof connection cables,

One waterproof power cables, a safety cable, and this manual. Please contact customer

support at the number listed below if any of the above items are missing.

CUSTOMER SUPPORT: Elation Professional®provides a customer support line, to provide

set up help and to answer any question should you encounter problems during your set up

or initial operation. You may also visit us on the web at www.elationlighting.com for any

comments or suggestions. For service related issue please contact Elation Professional®.

Service Hours are Monday through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.

Voice: (323) 582-3322

Fax: (323) 582-3108

E-mail: [email protected]

Forum: www.ElationLighting.com/forum

Warning! To prevent or reduce the risk of electrical shock or fire, do not expose this unit to

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 3 www.ElationLighting.com

rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not attempt any repairs

yourself. Doing so will void your manufactures warranty.

Please do not discard the shipping carton in the trash. Please recycle whenever possible.

WARRANTY REGISTRATION: The ELAR DW BRICK™ carries a two year (730 days)

limited warranty. Please fill out the enclosed warranty card to validate your purchase. All

returned service items whether under warranty or not, must be freight pre-paid and

accompany a return authorization (R.A.) number. The R.A. number must be clearly written

on the outside of the return package. A brief description of the problem as well as the R.A.

number must also be written down on a piece of paper and included in the shipping

container. If the unit is under warranty, you must provide a copy of your proof of purchase

invoice. Items returned without a R.A. number clearly marked on the outside of the package

will be refused and returned at customer’s expense. You may obtain a R.A. number by

contacting customer support at (323) 582-3322.

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 4 www.ElationLighting.com

2. SAFETY INSTRUCTIONS

To guarantee proper and consistent operation, it is important to

follow the guidelines in this manual. Elation Professional will not

accept responsibility for damages resulting from the misuse of

this fixture due to the disregard of the information printed in this

manual.

1. Always be sure that the fan and the air inlets remain clean and are never

blocked. Allow about 6” (15cm) between this fixture and other devices or a wall

to allow for proper cooling.

2. Never touch the fixture during normal operation.

3. Never look directly into the lamp beam. You risk injury to your retina, which may

induce blindness.

4. For safe operation, follow the Installation guide described in chapter two of this

manual. Operating the ELAR DW BRICK™ without suited safety aids such as

safety cables or clamps can increase the risk of damage and/or personal injury.

5. Installation should only be performed by qualified and certified personal.

6. When mounting this fixture, use only the original rigging points included with this

fixture. Any structural modification will void the original manufactures warranty

and may increase the risk of damage and/or personal injury.

7. To reduce the risk of fire or shock, do not expose this fixture to rain or moisture.

8. Do not attempt to operate this fixture if the power cord has become damaged or

frayed.

9. Never open this fixture while in use.

10.This device falls under protection-class I. Therefore it is essential that the device

be grounded properly.

11.All electrical connections must performed by qualified personal.

12.Be sure the available voltage matches the voltage requirements of the unit. Be

sure the power cord is never crimped or damaged. If the power cord is damaged,

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 5 www.ElationLighting.com

replace it immediately with a new one of similar power rating.

13.Always disconnect from main power before performing any type of service or

any cleaning procedure.

14.Only handle the power cord by the plug. Never pull out the plug by tugging the

wire portion of the cord.

15.If the external flexible cable or cord of this luminaire is damaged, it shall

be exclusively replaced by the manufacturer or his service agent or a similar

qualified person in order to avoid a hazard.

16.Please be aware that damages caused by modifications to the device are

not subject to warranty.

Important Notice: Damages resulting from the disregard of safety and general user

instructions found in this user manual are not subject to any warranty claims.

Never look directly into the light source,

as sensitive persons may suffer an epileptic shock.

Never touch the device during operation!

The housing may heat up

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 6 www.ElationLighting.com

3. FEATURES

• Low power consumption

• Minimal heat emission

• Maintenance free operation

• Equipped with 12 three-watt LEDS: (4 cool white, 8 warm white)

• 100,000 hours rated LED life

• Seamless white and warm color changing

• USITT DMX-512 complaint

• 5-pin and 3-pin Male and Female XLR Data Connectors

• Preprogrammed colored macros

• Strobe-effect with a maximum flash rate of 18fps

• DMX-controlled operation or stand-alone operation with Master/Slave-function

• Individual control over each LED

• Electronic/Switching power supply (AC 100V-240V~, 50 Hz /60Hz)

• Two DMX Modes:

5 DMX-channels

10 DMX-channels

• Flicker-free operation for television and film

• Compact design: fits in 12” box truss

• Brilliant light output

• Linkable power supply (in and out power connectors) up to 8 units.

• Firmware upgradeable via Elation “E-Loader”

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 7 www.ElationLighting.com

4. GENERAL GUIDELINES

This fixture is a professional lighting effect designed for use on stage, in nightclubs, in

theatres, and other types of architectural installations. Do not attempt operation or

installation without a proper knowledge on how to do so.

This fixture was designed for indoor use only; use of this fixture outside will void the

manufacture’s warranty.

Consistent operational breaks will ensure that the fixture will function properly for many

years to come.

Do not shake the fixture around. Avoid brute force when installing or operating the fixture.

While choosing an installation location, please be sure that the fixture will not be exposed to

extreme heat, moisture, or dust. The minimum distance between the fixture and a wall or flat

surface should be at least .5 meter (about 1.5ft).

Always install the fixture with an appropriately rated safety cable. When installing the fixture

in a suspended environment always be sure to use mounting hardware no less than M10 x

25 mm, also be sure the hardware is only inserted in the yoke’s mounting holes.

Do not attempt to operate this fixture until you have familiarized yourself with all of its

functions.

Do not permit operation by persons not qualified for operating this type of theatrical fixture.

Most damages are the result of improper operation.

Please use the original packaging to transport the fixture in for service.

For your own safety, please read this user manual carefully before installing the device.

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 8 www.ElationLighting.com

5. FIXTURE OVERVIEW

1. LED Assembly –Cool white warm white LED assembly 3 watt LEDS

2. Bracket Locking Knob – This knob is used to secure the bracket in place after

angle adjustments have been made.

3. LED Housing – This part include all hardware.

4. DMX Input Jack – This jack accepts an incoming DMX signal via a male, 3-pin or a

5-pin XLR jack.

ELAR DW BRICK ™

©Elation Professional, LosAngeles Ca. 9 www.ElationLighting.com

5. DMX Output Jack – This jack is used to send an incoming DMX signal to the next

fixture in the DMX chain via a female, 3-pin or a 5-pin XLR jack.

6. Main Power Input Lead – This lead is the main power input lead. When the unit is

the first in a chain or the only fixture to be used, be sure to use the power starter

cable that converts a standard Edison 3-prong to the IP rated twist lock connector.

When jumping from fixture to fixture be sure to only use Elation IP rated power

connectors to maintain the IP rating.

7. Power Output Jack – Use this jack to jump power to another ELAR DW BRICK™

8. MENU BUTTON – This button is used to access and exit the fixture’s on-board menu

system.

9. UP BUTTON – This button is used to scroll forward when navigating through the

fixture’s menu system.

10. DOWN BUTTON – This button is used to scroll backwards when navigating through

the fixture’s menu system.

11. ENTER BUTTON – This button is used to select and confirm a menu function.

12. LED MENU DISPLAY –Four segment LED menu display, details all menu functions

Table des matières

Autres manuels Elation Luminaire

Elation

Elation ACL BAR Manuel utilisateur

Elation

Elation Vision Scan 250 Manuel utilisateur

Elation

Elation 60TM Manuel utilisateur

Elation

Elation Platinum Beam 5R Extreme Manuel utilisateur

Elation

Elation Waterfall 250 Manuel utilisateur

Elation

Elation ProTron LED Manuel utilisateur

Elation

Elation TVL3000-II WW Manuel utilisateur

Elation

Elation PLATINUM FLX Manuel utilisateur

Elation

Elation ZW19 Manuel utilisateur

Elation

Elation PIXEL BAR 40 Manuel utilisateur

Elation

Elation TVL F1WW Manuel utilisateur

Elation

Elation PROTEUS BEAM WMG PRB162 Manuel utilisateur

Elation

Elation DESIGN WASH 250 Manuel utilisateur

Elation

Elation Platinum Wash ZFX Pro XL Manuel utilisateur

Elation

Elation FUZE PENDANT Manuel utilisateur

Elation

Elation COLOUR CHORUS 48 Manuel utilisateur

Elation

Elation PLATINUM SPOT 5R PRO Manuel utilisateur

Elation

Elation ELAR 180 PRO RGBAW Manuel utilisateur

Elation

Elation MiniPatend Manuel utilisateur

Elation

Elation emotion Manuel utilisateur

Elation

Elation FUZE SFX WH Manuel utilisateur

Elation

Elation TVL2000 II Manuel utilisateur

Elation

Elation FUZ035 Manuel utilisateur

Elation

Elation Color Spot 575 Manuel utilisateur

Manuels Luminaire populaires d'autres marques

Emos

Emos CLASSIC ZY1431T Manuel utilisateur

Westinghouse

Westinghouse Outdoor Lighting Fixture Manuel utilisateur

Hedler

Hedler C 12 silent Manuel utilisateur

Blizzard Lighting

Blizzard Lighting Puck: CSI Manuel utilisateur

Energetic Lighting

Energetic Lighting ELYSL-5004 Series Manuel utilisateur

Lightmaxx

Lightmaxx Shaft 5R Manuel utilisateur

Triarch

Triarch 31083 Manuel utilisateur

Philips

Philips 32614 Series Manuel utilisateur

IKEA

IKEA TIVED Manuel utilisateur

Lightolier

Lightolier LP200 Manuel utilisateur

Chauvet Professional

Chauvet Professional ROGUE R1 BEAM WASH Manuel utilisateur

Martin

Martin MAC 250 Krypton Manuel utilisateur

Cooper Lighting

Cooper Lighting Halo L3232E Manuel utilisateur

Stageline

Stageline ODW-2410RGBW Manuel utilisateur

Light Sky

Light Sky Tornado Series Manuel utilisateur

Lightolier

Lightolier Paralyte 2424 PLA2G9LS26U Manuel utilisateur

Lightolier

Lightolier Lytespan 83ED17S Manuel utilisateur

Lightolier

Lightolier Calculite CS8226 Manuel utilisateur
