EKOM DK 50 4X2VT/M Manuel utilisateur

DK50 4x2VT/M

DK50 6x2VT/M

USER MANUAL

COMPRESSOR

DK50 4x2VT/M

EKOM spol. s r. o.

Priemyselná 5031/18

SK-921 01 Piešťany

Slovak Republic

tel.: +421 33 7967255

fax: +421 33 7967223

www.ekom.sk

email: eko[email protected]

DATE OF LAST REVISION

06/2022

NP-DK50-Nx2VTM-ADM-

EN-1_06-2022

112000595-0001

CONTENTS

NP-DK50-Nx2VTM-ADM-EN-1_06-2022 4 06/2022

CONTENTS

IMPORTANT INFORMATION....................................................................................................... 5

1. CONFORMITY WITH THE REQUIREMENTS OF EUROPEAN UNION DIRECTIVES.... 5

2. INTENDED USE.............................................................................................................. 5

3. CONTRAINDICATIONS AND SIDE-EFFECTS ............................................................... 5

4. SYMBOLS....................................................................................................................... 5

5. WARNINGS .................................................................................................................... 6

6. STORAGE AND TRANSPORT CINDITIONS.................................................................. 8

PRODUCT DESCRIPTION ........................................................................................................... 9

7. VARIANTS...................................................................................................................... 9

8. ACCESSORIES .............................................................................................................10

9. PRODUCT FUNCTION..................................................................................................11

TECHNICAL DATA......................................................................................................................15

INSTALLATION...........................................................................................................................22

10. INSTALLATION CONDITIONS.......................................................................................22

11. COMPRESSOR ASSEMBLY .........................................................................................23

12. PNEUMATIC CONNECTION .........................................................................................26

13. ELECTRICAL CONNECTION ........................................................................................28

14. COMMISSIONING .........................................................................................................29

15. PNEUMATC DIAGRAMS ...............................................................................................31

OPERATION................................................................................................................................34

16. SWITCHING THE COMPRESSOR................................................................................34

17. SWITCHING OFF THE COMPRESSOR........................................................................37

AD DRYER...................................................................................................................................38

18. PRINCIPLE OF OPERATION.........................................................................................38

19. USER INTERFACE / SETTINGS....................................................................................39

20. MAIN SCREENS............................................................................................................41

21. INDICATION OF MAINTENANCE AND ALARM STATES..............................................43

PRODUCT MAINTENANCE ........................................................................................................45

22. PRODUCT MAINTENANCE...........................................................................................45

23. LONG-TERM SHUTDOWN............................................................................................52

24. DISPOSAL OF DEVICE.................................................................................................52

TROUBLESHOOTING.................................................................................................................53

25. REPAIR SERVICE .........................................................................................................55

ANNEX.........................................................................................................................................56

25. INSTALLATION RECORD..............................................................................................56

IMPORTANT INFORMATION

06/2022 5 NP-DK50-Nx2VTM-ADM-EN-1_06-2022

IMPORTANT INFORMATION

1. CONFORMITY WITH THE REQUIREMENTS OF EUROPEAN UNION DIRECTIVES

This product conforms to the requirements of

the Regulation (EU) on medical devices (MDR 2017/745) and is safe for the intended use if

all safety instructions are followed.

2. INTENDED USE

The compressor is used as a source of clean,

oil-free compressed air to power active

medical devices where the parameters and

properties of the compressed air are suitable

for the specific application.

Compressed air supplied by the

compressor is unsuitable for

use with artificial lung

ventilation devices without

further filtration

Any other use of the product beyond its

intended use is considered an incorrect use.

The manufacturer is not liable for any

damages or injuries resulting from the

incorrect use.

3. CONTRAINDICATIONS AND SIDE-EFFECTS

There are no contraindications or side-effects known.

4. SYMBOLS

The following symbols and marks are used in the User manual, on the device and its packaging:

General warning

Warning - risk of electric shock

Warning - compressor is controlled automatically

Warning - hot surface

General caution

Read the operating instructions

Refer to instruction manual

CE –marking

Medical device

Serial number

IMPORTANT INFORMATION

NP-DK50-Nx2VTM-ADM-EN-1_06-2022 6 06/2022

Protecting earthing

Terminal for ground connection

Alternating current

Package handling label –fragile

Package handling label –this side up

Package handling label –keep dry

Package handling label –temperature limits

Package handling label –limited stacking

Package label –recyclable material

Manufacturer

5. WARNINGS

The product is designed and manufactured to

be safe for the user and the surrounding

environment when used in the defined

manner. Keep the following warnings in mind.

5.1. General warnings

READ THE USER MANUAL CAREFULLY

BEFORE USING THE DEVICE AND KEEP IT

FOR FUTURE USE!

The user manual supports the correct

installation, operation and

maintenance of the product. Careful

review of this manual will provide the

information necessary for the correct

operation of the product for its

intended use.

Original packaging should be retained

for the return of the device. Only the

original packaging ensures protection

of the device during transport. If it is

necessary to return the product during

the warranty period, the manufacturer

is not liable for damages caused by

improper packaging.

This warranty doesnot cover damages

originating from the use of accessories

other than those specified or

recommended by the manufacturer.

The manufacturer only guarantees the

safety, reliability and function of the

device if:

- installation, new settings, changes,

expansion, and repairs are performed

by the manufacturer or an organisation

authorised by the manufacturer

- the product is used pursuant to the

user manual

The user manual corresponds to the

configuration of the product and its

compliance with the applicable safety

and technical standards at the time of

printing. The manufacturer reserves all

rights for the protection of its

configuration, methods and names.

Translation of the user manual is

performed in accordance with the best

available knowledge. The Slovak

IMPORTANT INFORMATION

06/2022 7 NP-DK50-Nx2VTM-ADM-EN-1_06-2022

version is to be used in the event of

any uncertainties.

This user manual is the original

instructions. Translation is performed

in accordance with the best available

knowledge.

5.2. General safety warnings

The manufacturer designed and

manufactured the product to minimise all risks

when used correctly for the intended use. The

manufacturer considers it its obligation to lay

down the following general safety

precautions.

Use and operation of the product must

comply with all laws and local

regulations valid in the place of use.

The operator and user are responsible

for following all the appropriate

regulations in the interests of

performing work safely.

Only the use of original parts

guarantees the safety of operating

personnel and the flawless operation

of the product itself. Only the

accessories and parts mentioned in

the technical documentation or

expressly approved by the

manufacturer should be used.

The operator must ensure that the

device is functioning correctly and

safely before every use.

The user must be familiar with the

operation of the device.

Do not use the product in

environments with a risk of explosion.

The user must inform the supplier

immediately if any problem directly

related to the operation of the device

occurs.

Any serious incident that has occurred

in relation to the device should be

reported to the manufacturer and the

competent authority of the Member

State in which the user and / or patient

is established.

5.3. Safety warnings on protection

from electric current

The device must only be connected to

a properly installed, earthed socket.

Before the product is plugged in,

ensure that the mains voltage and

frequency stated on the product are in

compliance with the values of the

mains.

Prior to putting the device into

operation check for any damage to the

connected pneumatic lines and

electrical wiring. Replace damaged

pneumatic lines and electrical wirings

immediately.

Immediately disconnect the product

from the mains (remove power cord

from the socket) in hazardous

situations or in the case of a technical

malfunction.

During all repairs and maintenance,

ensure that:

- the mains plug is removed from the

power socket

- pressure is vented from the air tank

and pipes

The product shall only be installed by

a qualified technician.

IMPORTANT INFORMATION

NP-DK50-Nx2VTM-ADM-EN-1_06-2022 8 06/2022

6. STORAGE AND TRANSPORT CINDITIONS

The compressor is shipped from the

manufacturer in transport packaging. This

protects the product from damage during

transport.

Potential for damage to

pneumatic components.

The compressor must be

transported only when all air

has been vented. Before

moving or transporting the

compressor, release all the air

pressure from the tank and

pressure hoses, from dryer

chambers and drain

condensate from the tank and

from the condensate separator

on the dryer.

Keep the original factory

packaging in case the device

needs to be returned Use the

original factory packaging

during transport as it provides

optimum protection for the

product. . If it is necessary to

return the product during the

warranty period, the

manufacturer is not liable for

damages caused by improper

packaging.

The compressor is shipped in a

vertical position and must be

secured using transport straps.

Protect the compressor from humid

and dirty environments and

extreme temperatures during

transport and storage. Do not store

near any volatile chemical

substances.

If not, please dispose of the original

packaging material in an

environmentally-friendly way. The

packaging cardboard can be

recycled with old paper.

Storing or shipping the equipment

in any conditions other than those

specified below is prohibited.

6.1. Ambient conditions

Products may only be stored and transported in vehicles that are free of any traces of volatile

chemicals under the following climactic conditions:

Temperature

–25°C to +55°C, do 24h at up to +70°C

Relative humidity

max. 90% (non-condensing)

PRODUCT DESCRIPTION

06/2022 9 NP-DK50-Nx2VTM-ADM-EN-1_06-2022

PRODUCT DESCRIPTION

7. VARIANTS

The compressor is manufactured according to its intended application in the following variants:

DK50 4x2VT/M

Composed of modules:

1 compressor module with adsorption dyer - 4x2V air pumps

2 air tank module –2x110 l

DK50 4x2VT/M

PRODUCT DESCRIPTION

NP-DK50-Nx2VTM-ADM-EN-1_06-2022 10 06/2022

8. ACCESSORIES

Accessories that are not included in the

standard order must be ordered separately.

Set of compressed air outlet filters

The compressor may be equipped with a set

of filters if specified. The filter set may be

equipped with an air pressure regulator.

Where a different level of air

filtration is required, this

requirement must be agreed

upon with the supplier and

specified in the order.

Type

Use

Leve of filtration

(µm)

Bypass

function*

Article number

FS 40F

DK50 4x2VT/M

604014119-000

FS 40M

1+0,1

604014119-004

FS 40S

1+0,01

604014119-024

FS 40AH

1+AC+HC(0,01)

604014119-005

*) These FS do not contain a filter bypass, which will ensure a continuous flow of air when

replacing the filter element. Such a set must be ordered separately.

Set of filters

Filter set regulator assembly

The compressor may be equipped with a

pressure regulator of the compressed air

outlet if specified. The regulator must be

selected according to the application to the

filter set, or separately The regulator shall

ensure constant pressure at the outlet.

Type

Use

Article number

Regulator complete

DK50 4x2VT/M

604014125-000

Filter set brackets

A suitable bracket must be

ordered for every filter set.

Type

Use

Article number

Compressor-mounted bracket

DK50 4x2VT/M

603014137-000

Wall-mounted bracket

603014120-000

Table des matières

Autres manuels EKOM Compresseur d'air

EKOM

EKOM DK50-10 Series Manuel utilisateur

EKOM

EKOM DK50 4x4VRT/M Manuel utilisateur

EKOM

EKOM DK50 2x4VR/110 S Manuel utilisateur

EKOM

EKOM DK50 Z Manuel utilisateur

EKOM

EKOM DK50 PLUS/M Series Manuel utilisateur

EKOM

EKOM DK50 2x4VR/110 S Document technique

EKOM

EKOM DK50 DS Manuel utilisateur

EKOM

EKOM DK50 4VR/50/M Manuel utilisateur

EKOM

EKOM DK50 2V S Manuel utilisateur

EKOM

EKOM DK50 2V/110 Manuel utilisateur

EKOM

EKOM DK50 PLUS/M MOBILE Manuel utilisateur

EKOM

EKOM DK50 Plus Mobile Manuel utilisateur

EKOM

EKOM DK50 4VR/50/M Manuel utilisateur

EKOM

EKOM DK50 DE Manuel utilisateur

EKOM

EKOM DK50-10 Z Manuel utilisateur

EKOM

EKOM AD500 Manuel utilisateur

EKOM

EKOM DK50 4VR/50 Manuel utilisateur

EKOM

EKOM DK50 2V S Manuel utilisateur

EKOM

EKOM DK50 Z Manuel d'instructions

EKOM

EKOM DK50 3x4VR/M Manuel utilisateur

EKOM

EKOM DK50 4x2VT/M Manuel utilisateur

EKOM

EKOM DK50 3x4VR/M Manuel utilisateur

EKOM

EKOM DK50 DE Manuel utilisateur

EKOM

EKOM DK50 9x4VRT/M Manuel utilisateur

Manuels Compresseur d'air populaires d'autres marques

Sparmax

Sparmax DC-25XR Manuel utilisateur

KAESER

KAESER M122 Manuel utilisateur

GMC

GMC GAC1500 Manuel utilisateur

Briggs & Stratton

Briggs & Stratton Air Compressor Manuel utilisateur

Fini

Fini F3GST2TK Manuel utilisateur

Industrial Air

Industrial Air CP1580325 Manuel de programmation

Campbell Hausfeld

Campbell Hausfeld RP3300 Guide de démarrage rapide

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Manuel utilisateur

Hitachi

Hitachi EC99S Manuel de l'opérateur

Parkside

Parkside PKO 270 A1 Manuel utilisateur

Sullair

Sullair 185 Manuel utilisateur

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Manuel utilisateur

Ferm

Ferm CRM1046 Manuel utilisateur

BE AC153 Manuel utilisateur

RIDGID

RIDGID OF25150A Manuel utilisateur

Johnson Controls

Johnson Controls QUANTUM LX Manuel

Sears

Sears Craftsman 919.167463 Manuel utilisateur

Ring Automotive

Ring Automotive RAC700 Manuel utilisateur
