❺Power on/off
PressthePower Switchlocatedon therearpanel
to the "ON" position. The dispenser will power up
in the RUN, STEADY, or PRESSURE mode and indi-
cate which cell was selected last. (Dispenser is
shipped with
CEL1
selected in RUN mode).
❻Air output
Pushin andtwistlock the10cc adapter assembly
(part#1000Y5150). Thenumber5150is molded
on the side of the yellow head.
❼Setting the decimal
The dispenser is shipped with the decimal set at
hundredthsofasecond(00.00). Thedecimalcan
bemovedtoshowthousandthsofasecond(0.000)
as follows:
PressRUN/SETUP toplacethe dispenserin SETUP
mode.
To move the decimal, press and hold the STOP
button. After approximately 4.0 seconds, the
decimalwillmovetothethousandthsposition. To
return to the hundredths position, press and hold
the STOP button again.
Note: Changing the decimal place changes the
currenttimesettingbyafactorof10. Forexample,
5.35 seconds becomes 53.50; 15.00 seconds
becomes 1.50.
❽Setting the pressure readout
The dispenser is shipped with pressure display
programmed in psi.
Note: On models with 5 psi and 15 psi regulators,
the pressure is adjustable in 0.1 psi increments.
If bar is desired, change as follows:
PressRUN/SETUPandplacethedispenserintothe
SETUP mode. Press and hold the PRESSURE/TIME
button for 4.0 seconds. The display will change
from psi to bar. To change back to psi, press and
hold PRESSURE/TIME for 4.0 seconds.
❾Vacuum control
Vacuum is turned off (clockwise) during testing
procedures. (Refer to page 16 for operation.)
❿Vacuum toggle switch
To read vacuum pressure, hold toggle switch in
the "up" position. Readout will appear on the
digital display pad, then return to air pressure
readout when toggle is released.
Continue to page 11 for test procedures.
STEADY
RUN
SETUP
CYCLE
STOP
Steady
Run
Setup Fast Slow
Time Set
Teach Pressure
Time
Fast Slow
Time Set
Pressure
Vacuum
Vacuum
Pressure
Cell Select
EL1
C
®
A NORDSON COMPANY
2000XL
❼
❽
❿
❾
