EDMI Variant 450 Manuel utilisateur

EDMI Dual Band Variant 450

Communications Hub Variant (CS-21)

Author: EDMI

Approver: Rajan Bhandari

Date: 15/04/2019

Version / Status: 1.2

Document Classification: Public

Distribution and approvals are maintained in Share Point, distribution to the public via EDMI

webpage.

It is the responsibility of the user of this document to verify that it is the most current edition.

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 2 OF 22

Preface

Privacy information

This document is public information and is shared on EDMI’s webpage.

Revision history

Name

Description of Change

Date

Version

EDMI

First Version

05/03/2019

1.0

EDMI

Several corrections to WAN frequencies across the

document

04/04/2019

1.1

EDMI

Receiver WAN frequencies slightly modified

15/04/2019

1.2

Approval

Name

Position

Signature

Date

Rajan Bhandari

Technical Director

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 3 OF 22

Table of Contents

Preface...................................................................................................................................... 2

Privacy information ........................................................................................................... 2

Revision history ................................................................................................................ 2

Approval ........................................................................................................................... 2

1Dual Band EDMI Variant 450 Communications Hub....................................................... 4

1.1 Photograph.............................................................................................................. 4

1.2 Communications Hub Enclosure Engineering Drawing............................................ 5

1.3 Communications Hub Block Diagram....................................................................... 6

1.4 General Specification............................................................................................... 6

1.5 Sub GHz 915-921 MHz Channel............................................................................ 14

1.6 JTM ....................................................................................................................... 14

1.7 Communications Hub Labelling / Artwork Engineering Drawing............................. 14

1.8 Product SKU Naming Convention.......................................................................... 15

1.9 Packaging Drawing (Box) ...................................................................................... 16

1.10 Packaging Drawing (Carton).................................................................................. 17

1.11 Packaging Drawing (Pallet Loading)...................................................................... 18

1.12 Compliance Declaration......................................................................................... 18

2Expected Normal Use and Warnings............................................................................. 19

2.1 Home User ............................................................................................................ 19

2.2 Exclusions ............................................................................................................. 19

2.3 Restrictions............................................................................................................ 19

3Appendix - Noise............................................................................................................. 20

3.1 Noise Limit............................................................................................................. 20

3.2 Noise Calculations................................................................................................. 20

3.3 Spectrum Analyser Guide Settings ........................................................................ 21

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 4 OF 22

1 Dual Band EDMI Variant 450 Communications Hub

1.1 Photograph

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 5 OF 22

1.2 Communications Hub Enclosure Engineering Drawing

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 6 OF 22

1.3 Communications Hub Block Diagram

3V9

HAN

2.4 GHz Tran

2 LEDs

User Interface

Quad SPI

UART

31.25 MHz TCXO

Host processor

ROM SRAM

SDRAM

Flash

Power Supply Switching Step

Down Converter and last gasp

energy storage

12V DC

3V3

FlexNet

WAN 412

& 454

MHz

2.4 GHz

Zigbee

MEMORY

Flexnet WAN

LRR

HAN

PSU

WAN

RF WAN

Transceiver

3V9

Timing Unit

12 MHz

XTAL

32 MHz

XTAL

Radio Transceivers

Memory

Power Supply

Timing Unit

DBCH Only

Hardware Security

Module

32 kHz

XTAL

HAN

868 MHz Transceiver

SPI

868 MHz

Zigbee

55.2 MHz

XTAL

1.4 General Specification

For terms and abbreviations used in this document please see the DCC document: Joint

HAN Radio Testing Methodology (JTM v3.2).

Specification

Description

Dimensions (mm)

Height from bottom face: 92mm

Height from ICHIS datum: 80mm

Depth: 65mm

Width: 131mm

Weight (g)

200g

Environment Protection

IP Rating: IP53

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 7 OF 22

Ambient temperature limits: -20°C to 55°C

SM WAN specification

Standard : ETSI EN300 113-1

Frequency Range:

Transmit: 412-414 and 453.0-455.0 MHz

Receive: 453.0-455.0 MHz

TRP: 1W Maximum.

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 8 OF 22

HAN Specification

Transceiver

TRP: 2.4GHz

>6.5dBM

TRP: Sub-GHz (excluding 915Mhz)

>11dBm

TRS: 2.4GHz

<-91.5dBm

TRS: Sub GHz( excluding 915Mhz)

<-97dBm

MAPL : (Sub GHz excluding 915Mhz)

>108dB

MAPL : 2.4GHz

>99dB

MAPL : Sub GHz 915Mhz

>40dB

Directivity

Omni

Maximum Output Power

13dBm EIRP for

2.4Ghz

14dBm ERP for Sub

GHz

Note! The CS-21 Sub GHz radio complies with “Receiver

Category 2” per EN 300 220-1 v3.1.1:2017

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 9 OF 22

Power Consumption (W)

6W maximum

1W typical

EDMI Dual Band Variant 450 Communications Hub Variant

(CS-21)

Version / Status: 1.2

Public

PAGE 10 OF 22

Visual Indicator

SM WAN_LED (Left)

SM HAN_LED (Right)
