High TX power boosts coverage and signal strength

Edimax BR-6428HPn is a high speed wireless broadband router that complies with wireless IEEE 802.11b/g/n

standards. The BR-6428HPn’s high power design enhance wireless output power to 27dbm (500mW), giving

coverage range which is double that of standard 11n routers. The fine-tuned performance of the BR-6428HPn

significantly reduces dead zones.

iQ Setup

iQ Setup is a smart feature of Edimax routers that allows even the most inexperienced users to set up an Edimax

router quickly and effortlessly. After the appropriate cable connections are made, simply open a web browser

on a computer or smartphone and iQ Setup will start detecting your Internet connection type automatically. iQ

Setup ensures that most of the setup process is done automatically - little to no configuration is required on the

users’ part and no installation CD is necessary.

Wireless 802.11n Standard (data rates up to 300Mbps)

The Edimax BR-6428HPn is a high-speed solution that complies with IEEE 802.11b/g/n standards. The latest

wireless technology is built in to broaden wireless coverage and reduce dead zones within the wireless range.

When connected to wireless 802.11n compatible devices, the BR-6428HPn can achieve transmission rates of up

to 300Mbps on the 2.4GHz band.

WPS (Wi-Fi Protected Setup) Button & Built-in Wi-Fi On/Off Switch

The Edimax BR-6428HPn allows users to build secure connections with WPS enabled wireless devices simply by

pressing the WPS button, eliminating the need to go through the hassle of setting up and configuring the

security of your wireless network. Additionally, with the built-in Wi-Fi on/off switch users can conveniently

switch on/off the wireless connection without logging into the user interface –enabling users to save electricity

by switching the Wi-Fi signal off when it is not in use.

N300 High Power Wireless

Broadband Router

BR-6428HPn

www.edimax.com

Maximum performance, actual data rates and coverage may vary depending on network conditions and environmental factors. Stated ranges are based on

FEATURES & TECHNICAL SPECIFICATIONS

FUNCTIONS HARDWARE INTERFACE MANAGEMENT

Supports AP, AP Client, Bridge, Bridge+ WDS,

and Universal Repeater modes

Port Triggering for special applications

DDNS

Virtual Server and DMZ hosting

MAC/IP filter and URL blocking

Static routing

UPnP architecture

VPN Pass-Through (IPSec/PPTP)

Schedule control

One RJ-45 Fast Ethernet WAN port

Four RJ-45 Fast Ethernet LAN ports

LED Indicators: Power, Wireless, WAN,

LNK/ACT for LAN

Detachable 5dBi high-gain antenna x 2

WPS / Reset button

Switch for wireless on/off

Supports Remote Management

System Status and Security Log

(Web Interface)

Firmware upgradeable

WAN SECURITY OUTPUT POWER & SENSITIVITY GAIN

Supports WISP connection mode

Supports RJ-45 cable/xDSL modem

WAN protocol: PPPoE/Static IP/PPTP/

Dynamic IP/ L2TP

NAT/NAPT IP Sharing

64/128-bit WEP Encryption and WPA-PSK,

WPA2-PSK security

DHCP Server/Client

QoS for critical operations

SPI Anti-DoS Firewall

11b(1M): 26±1.5dBm, 11b(11M): 25±1.5dBm,

11g(6M): 25±1.5dBm, 11g(54M): 23±1.5dBm,

11n(MCS0): 24±1.5dBm,

11n(MCS7): 22±1.5dBm

11b(1M): -93±2dBm, 11b(11M): -87±2dBm,

11g(6M): -87±2dBm, 11g(54M): -75±2dBm,

11n(MCS0): -87±2dBm,

11n(MCS7): -69±2dBm

MEMORY INSTALLATION KIT HUMIDITY & TEMPERATURE

4 MB NOR Flash

16 MB SDRAM

iQ Setup (web based easy setup)

10-90% (Non-condensing)

0~40oC

POWER ADAPTER DIMENSIONS CERTIFICATIONS

DC 12V, 1A 180 (W) x 120 (D) x 26 (H) mm FCC

High power wireless signal

Standard wireless signal

Maximum performance, actual data rates and coverage may vary depending on network conditions and environmental factors. Stated ranges are based on

N300 High Power Wireless

Broadband Router

EW-6428HPn

www.edimax.com
