Edimax ECS1100 Series Manuel de programmation

Web Management Guide

www.edge-core.com

ECS1100 Series

Release v1.0.1.0

Web Management Guide

ECS1100-5P

L2 Gigabit Ethernet Web Managed PoE Switch

with 4 1000BASE-T RJ-45 PoE+ (30W) Ports,

and 1 1000BASE-T RJ-45 Port

ECS1100-10HP

L2 Gigabit Ethernet Web Managed PoE Switch

with 4 1000BASE-T RJ-45 PoE++ (90W) Ports,

4 1000BASE-T RJ-45 PoE+ (30W) Ports,

and 2 100/1000M SFP Ports

E082023-CS-R01

– 3 –

How to Use This Guide

This guide includes detailed information on the switch software, including how to

operate and use the management functions of the switch. To deploy this switch

effectively and ensure trouble-free operation, you should first read the relevant

sections in this guide so that you are familiar with all of its software features.

Who Should Read

This Guide?

This guide is for network administrators who are responsible for operating and

maintaining network equipment. The guide assumes a basic working knowledge of

LANs (Local Area Networks), the Internet Protocol (IP), and Simple Network

Management Protocol (SNMP).

How This Guide is

Organized

This guide describes the switch’s web browser interface.

The guide includes these sections:

Section I “Getting Started” — Includes basic settings required to access the

management interface.

Section II “Web Configuration” — Includes all management options available

through the web browser interface.

Section III “Appendices” — Includes information on troubleshooting device

management access.

Documentation

This guide focuses on software configuration through a web browser.

For information on how to install the switch and all safety information and

regulatory statements, see the following documents:

Quick Start Guide

Safety and Regulatory Information

Conventions The following conventions are used throughout this guide to show information:

Note:

Emphasizes important information or calls your attention to related features

or instructions.

How to Use This Guide

– 4 –

Caution:

Alerts you to a potential hazard that could cause loss of data, or

damage the system or equipment.

Warning:

Alerts you to a potential hazard that could cause personal injury.

Revision History This section summarizes the changes in each revision of this guide.

August 2023 Revision

This is the first version of this guide. This guide is valid for software release

v1.0.1.0.

– 5 –

Contents

How to Use This Guide 3

Contents 5

Section I Getting Started 8

1 Using the Web Interface 9

Connecting to the Web Interface 9

Navigating the Web Browser Interface 10

Dashboard 10

Configuration Options 10

Saving the Configuration 11

Panel Display 11

Main Menu 12

Section II Web Configuration 13

2 System Management 14

System Information 14

IP Settings 15

Account Settings 17

System Time 18

Setting the Time Manually 18

Setting the Time Using SNTP 19

Cloud Manage 20

Jumbo Frames 21

3 Port Configuration 22

Port Settings 22

Storm Control 24

Contents

– 6 –

Port Speed Limit 25

Port Trunk 26

Port Statistics 28

SFP 29

4 VLAN Configuration 30

Static VLAN 30

VLAN Setting 31

5 QoS Configuration 33

QoS Basic 33

QoS Advanced 35

Port-Based Priority 35

802.1p-Based Priority 36

DSCP-Based Priority 37

Priority Queue Mapping 38

6 PoE Configuration 40

PoE Port Config 40

PoE System Power 42

PD Alive 43

PoE Timer Rule 44

PoE Timer Set 45

Poe Extend Mode 46

7 IGMP Configuration 48

IGMP Snooping 48

Router Port 49

Group Address 51

8 Tools 53

System Upgrade 53

Backup Restore 54

System Reset 56

System Reboot 56

Contents

– 7 –

Section III Appendices 58

A Troubleshooting 59

Problems Accessing the Management Interface 59

B License Information 60

The GNU General Public License 60

– 8 –

Section I

Getting Started

This section describes the basic settings required to access the management

interface.

This section includes these chapters:

“Using the Web Interface” on page 9

– 9 –

1Using the Web Interface

This switch provides an embedded HTTP web management interface. Using a web

browser you can configure the switch and view statistics to monitor network activity.

The web management interface can be accessed by any computer on the network

using a standard web browser.

Connecting to the Web Interface

Prior to accessing the switch from a web browser, be sure you have first performed

the following tasks:

1. The default IP address and subnet mask for the switch is 192.168.2.10 and

255.255.255.0, with no default gateway. If this is not compatible with the

subnet connected to the switch, you can configure it with a valid IP address,

subnet mask, and default gateway.

2. Set user names and passwords. Access to the web interface is controlled by a

default user name and password. For security reasons, you should change the

default password and configure new user accounts as soon as possible. (See

“Account Settings” on page 17.)

3. After you enter a user name and password, you will have access to the web

management interface.

Note:

Users are automatically logged off of the web server if no input is detected

for 600 seconds.

Chapter 1

| Using the Web Interface

Navigating the Web Browser Interface

– 10 –

Navigating the Web Browser Interface

To access the web-browser interface you must first enter a user name and

password. The administrator has read/write access to all configuration parameters

and statistics. The default user name and password for the administrator is

“admin.” The administrator has full access privileges to configure any parameters

in the web interface. Refer to “Account Settings” on page 17 for more details.

Dashboard When your web browser connects with the switch’s web agent, the Dashboard is

displayed as shown below. The Dashboard displays the main menu on the left side

of the screen and System Information on the right side. The main menu links are

used to navigate to other menus, and display configuration parameters and

statistics.

Figure 1: Dashboard

Configuration

Options

Configurable parameters have a dialog box or a drop-down list. Once a

configuration change has been made on a page, be sure to click on the Apply

button to confirm the new setting.

The following table summarizes some common web page configuration buttons.

Table 1: Web Page Configuration Buttons

Button Action

Sets specified values to the system.

Selects all entries in a table.

Deletes the selected items.
