Edimax ES-1008PH Manuel utilisateur

ES-1008PH / ES-1008P

GS-1008PH / GS-1008P

Quick Installation Guide

07-2012 / v1.0

publication may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language, in any form or by

any means, electronic, mechanical, magnetic, optical, chemical, manual or

otherwise, without the prior written permission from Edimax Technology Co.,

Ltd.

Edimax Technology Co., Ltd. makes no representations or warranties, either

expressed or implied, with respect to the contents hereof and specifically

disclaims any warranties, merchantability, or fitness for any particular purpose.

Edimax Technology Co., Ltd. reserves the right to revise this publication and to

make changes from time to time in the contents hereof without the obligation to

notify any person of such revision or changes.

The product you have purchased and the setup screen may appear slightly

different from those shown in this QIG. The specification is subject to change

without notice. Please visit our web site www.edimax.com for the update. All

brand and product names mentioned in this manual are trademarks and/or

registered trademarks of their respective holders.

Edimax Technology Co., Ltd.

Add: No. 3, Wu‐Chuan 3rd Rd., Wu‐Ku Industrial Park, New Taipei City, Taiwan

Tel: +886‐2‐77396888

Email: sales@edimax.com.tw

PRODUCT INTRODUCTION

Model no.:

ES-1008PH: 8-Port Fast Ethernet Switch with 4 PoE+ Ports

ES-1008P: 8-Port Fast Ethernet PoE+ Switch

GS-1008PH: 8-Port Gigabit Ethernet Switch with 4 PoE+ Ports

GS-1008P: 8-Port Gigabit Ethernet PoE+ Switch

Package Contents

Before you start using this switch, please check if there is anything missing in the

package, and contact your dealer to claim the missing item(s):

PoE switch x 1pcs

Quick installation guide x 1pcs

Power cord x 1pcs

Rubber feet x 4pcs

Rack-mount brackets and screws x 1 set

Front Panel:

Please refer to the following description for the front panel:

ES-1008PH

ES-1008P

GS-1008PH

GS-1008P

LED Definitions:

LED Name

Light Status

Description

PWR

Switch on and correctly powered

Off

Switch not powered or not correctly powered

LINK/ACT

Port is connected

Off

Port is not connected

Flashing

Port is active and transferring/receiving data

PoE

PoE on and powering PoE/PoE+

Off

PoE is not activated

Back Panel:

Power Connector:

Plug in the female connector of the provided power cord into this connector, and

the male into a power outlet. Supported input voltages range from 100-240V AC,

and 50-60 Hz.

Product Specifications:

Model

ES-1008PH

ES-1008P

GS-1008PH

GS-1008P

Standards

IEEE 802.3 10BaseT

IEEE 802.3u 100BaseTX

IEEE 802.3af/802.3at PoE

IEEE 802.3x Flow Control

IEEE 802.3az Energy Efficient Ethernet

IEEE 802.3 10BaseT

IEEE 802.3u 100BaseTX

IEEE 802.3ab 1000BaseT

IEEE 802.3af/802.3at PoE

IEEE 802.3x Flow Control

IEEE 802.3az Energy Efficient Ethernet

Interface

RJ-45

8 ports

PoE

4 ports

8 ports

4 ports

8 ports

MAC Address

Buffer Memory

128KB

96KB

Jumbo Frames

9KB

N/A

Power budget

80W

150W

80W

150W

Power Consumption

5 Watts (Max)

Dimensions

266 x 184 x 44 x W x H)

Weight

1.95 kg

Operating Temperature

0 to 50℃

Storage Temperature

-40 to 70℃

Humidity

Operating:10 to 90% RH (non-condensing)

1. PRODUCT INSTALLATION

There are two ways to install your switch, please select one that suits

you.

2. Desktop Installation

1. Install the switch on a level surface that can support the weight of

the unit and the relevant components, and attach the rubber feet to

the bottom. The rubber feet cushion the switch and helps protect the

case from scratches.

2. Plug the switch into an electrical source with the provided power cord.

3. Rack-Mount Installation

Rack mounting allows for a more orderly installation when a

series of network devices is being installed.

1. Disconnect all the cables from the switch.

2. Place the unit the right way up on a hard, flat surface with the front

facing you.

3. Position a mounting bracket over the mounting holes on one side of

the unit.

4. Insert the screws and fully tighten with a suitable screwdriver.

5. Repeat the two previous steps for the other side of the unit.

6. Insert the unit into the rack and secure with suitable screws

7. Reconnect all the cables.

Regarding the installation environment, we strongly recommend:

1. The switch should be placed in an appropriately ventilation environment.

A minimum 25 mm space around the unit is recommended.

2. The switch and the relevant components should be kept away from sources

of electrical noise such as radios, transmitters and broadband amplifiers.

3. Avoid environments with higher than recommended moisture levels.

Troubleshooting

1. Power LED is not lit

Check if the power cord is properly connected to the plug and the power

outlet; make sure the power cord is firmly plugged into the power socket of

the switch.

2. LINK/ACT LED is not lit when connected to devices

Make sure the network device attached to the switch is turned on.

Make sure the network cable is properly connected to the switch and the

network device.

Make sure the network cable is a UTP cable that complies with EIA/TIA 568

and Category 5 specifications.

Contact your dealer if problems persist.

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of

the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

4. Consult the dealer or an experienced radio technician for help.

FCC Caution

This device and its antenna must not be co-located or operating in conjunction

with any other antenna or transmitter.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible

for compliance could void the authority to operate equipment.

CE Mark Warning

This is a class B product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures.
