Edimax HP-5101AC Manuel utilisateur

0



HP-5101AC

User Manual

08-2012 / v1.0



publicationmaybereproduced,transmitted,transcribed,storedinaretrieval

system,ortranslatedintoanylanguageorcomputerlanguage,inanyformorby

anymeans,electronic,mechanical,magnetic,optical,chemical,manualor

otherwise,withoutthepriorwrittenpermissionfromEdimaxTechnologyCo.,

Ltd.

EdimaxTechnologyCo.,Ltd.makesnorepresentationsorwarranties,either

expressedorimplied,withrespecttothecontentshereofandspecifically

disclaimsanywarranties,merchantability,orfitnessforanyparticularpurpose.

Anysoftwaredescribedinthismanualissoldorlicensedasis.Shouldthe

programsprovedefectivefollowingtheirpurchase,thebuyer(andnotthis

company,itsdistributor,oritsdealer)assumestheentirecostofallnecessary

servicing,repair,andanyincidentalorconsequentialdamagesresultingfrom

anydefectinthesoftware.EdimaxTechnologyCo.,Ltd.reservestherightto

revisethispublicationandtomakechangesfromtimetotimeinthecontents

hereofwithouttheobligationtonotifyanypersonofsuchrevisionorchanges.

Theproductyouhavepurchasedandthesetupscreenmayappearslightly

differentfromthoseshowninthisQIG.Formoreinformationaboutthisproduct,

pleaserefertotheusermanualontheCD‐ROM.Thesoftwareandspecifications

aresubjecttochangewithoutnotice.Pleasevisitourwebsitewww.edimax.com

forupdates.Allbrandandproductnamesmentionedinthismanualare

trademarksand/orregisteredtrademarksoftheirrespectiveholders.



EdimaxTechnologyCo.,Ltd.

Add:No.3,Wu‐Chuan3rdRd.,Wu‐KuIndustrialPark,NewTaipeiCity,Taiwan

Tel:+886‐2‐77396888

Email:[email protected]

Contents

Chapter1:Introduction.....................................................................................................................................1

1.1ProductFeatures..................................................................................................................................1

1.2Application...........................................................................................................................................1

1.3Compatibility........................................................................................................................................2

1.4SystemRequirements..........................................................................................................................2

Chapter2:AbouttheProduct............................................................................................................................3

2.1LEDDefinitions.....................................................................................................................................3

2.2Interface...............................................................................................................................................4

Chapter3:GettingStarted.................................................................................................................................5

3.1HardwareInstallation..........................................................................................................................5

3.2CreatingaPowerlineNetwork.............................................................................................................6

3.3CreatinganEncryptedPowerlineNetworkwithTwoAdapters..........................................................7

Chapter4:UtilitySoftwareInstallation.............................................................................................................8

Chapter5:UsingtheUtilitySoftware..............................................................................................................14

5.1MainTab............................................................................................................................................14

5.2PrivacyTab.........................................................................................................................................17

5.3DiagnosticsTab..................................................................................................................................19

5.4AboutTab...........................................................................................................................................20

Chapter6:PowerlineNetworkManagementwithGroupButton..................................................................21

6.1FormingaHomePlugAVLogicalNetwork.........................................................................................21

6.2JoiningaNetwork..............................................................................................................................22

6.3LeavingaNetwork&JoininganotherNetwork.................................................................................23

Chapter7:Troubleshooting.............................................................................................................................24

1



Chapter1:Introduction



1.1ProductFeatures



zIntegratedwithpowersocketjustasanadditionalwallsocket

zEasyplug‐n‐playsetupand128‐bitAESsecurity

zMax.powerlinespeedupto500Mbps

zBackwardcompatiblewith200Mbpspowerlineadapters

zFeaturesenergysavingmodetoreducepowerconsumption

zIntegratedpowersocketwithnoisefilter

zPowerlinetransmissionrangeupto300meters



1.2Application



zHigh‐definition(HD)andstandard‐definition(SD)videodistribution

zBroadbandInternetsharing

zInternetProtocolTelevision(IPTV)andVoiceoverInternetProtocol(VoIP)

applications



2



1.3Compatibility



200Mbps(EdimaxHP‐200xseries)and500Mbps(EdimaxHP‐500xseries)powerline

adaptersareabletocommunicatedirectlywithoneanother.200Mbpsand500Mbps

powerlineadapterscanbeusedonthesamehouseholdelectricwiringas14Mbps&

85Mbpspowerlineadapters(EdimaxHP‐85XXseries)withoutinterfering,butarenotable

tocommunicatedirectlywith14Mbpsand85Mbpspowerlineadapters.



1.4SystemRequirements



zComputerwithEthernetportrunningWindowsXP/Vista/7,Linux,MACOSXand

anyotheroperatingsystem.

zAnyconnecteddevicesmustfeatureanetworkport.

zUtilitysoftwaresupportsWindowsXP/Vista/7.



3



Chapter2:AbouttheProduct



2.1LEDDefinitions



LEDStatusDescription



LAN

GreenLANportconnected

BlinkingLANactivity(transferringdata)

LANportnotconnected



PLC

Green/Yellow

Thegreenindicatorturnsonandtheyellowindicator

blinksslowlywhenthedeviceisdetectinga

powerlinelink.

Thegreenindicatorturnsonandtheyellowindicator

blinksquicklytoindicatedataisbeingtransferred

overthepowerlinelink.

Noother PLC device detected



PWR

GreenPoweredon

Poweredof



Note:Thedevicewillenterstandbymode,andallLEDswillextinguish,after

5secondswithoutanydatatransfer,includingwhentheEthernetcableis

disconnected.ThePowerLEDwillflashonceevery15seconds.



4



2.2Interface





InterfaceDescription

Integrated

PowerSocket

Theintegratedelectricalsocketenablesadditionalterminal

devicesormultiplesockettobeconnectedtotheadapter,just

asanormalwall socketwould.

EthernetPortThisisaFastEthernetportforconnectingtoacomputeror

otherdeviceswithanetworkport.

Group/ResetCreatesanencryptedpowerlinenetworkgroupautomatically

(pressthebuttonforlessthan3seconds).

Leavesanencryptedpowerlinenetworkgroup

(pressthebuttonfor5~8seconds).

Restoresthepowerlineadaptertofactorydefaults(pressthe

buttonfor10~15 seconds).



5



Chapter3:GettingStarted



3.1HardwareInstallation



1. Alwaysplugthepowerlineadapterdirectlyintoapowersocket.Neverplugitintoa

multiplesocketoruninterruptiblepowersupply(UPS).



2. Ifyouneedtouseamultiplesocketforadditionalnetworkdevices,

thenconnectthemultiplesockettotheintegratedpowersocketoftheadapter,and

plugthepowerlinedirectlyintoapowersocket,asshownbelow.Thepowersocketof

theadapterfeaturesafilterfunctionwhichisabletoimprovethedatatransmissionin

thenetwork.



6



3.2CreatingaPowerlineNetwork



1. ConnectapowerlineadaptertoyourrouterviaEthernetcable,andthenplugitintoa

powersocket.



2. Connectanotherpowerlineadaptertoyourcomputer,andthenplugitintoapower

socket.



Note:Youcanalsoconnecttheadaptertoaprinter,settopbox,gamingconsole,TVor

otherdevicewithanetworkport,toaddthedeviceintothepowerlinenetwork.



3. MakesurethatthePLCandLANLEDslightuponbothPLCadapters.



4. Thecomputerandtherouterwillbeconnectedtothepowerlinenetworkautomatically.

7



3.3CreatinganEncryptedPowerlineNetworkwithTwoAdapters



Oncebothadaptershavebeensuccessfullyconnected,pressthe“Group/Reset”button

ofeachadapterforlessthan3secondswithin2minutes.Theadapterswill

automaticallygeneratearandompasswordtoencryptthepowerlinenetwork.



Note:

zToaddadditionaladaptersintotheencryptedpowerlinenetworkortoremove

anadapterfromthepowerlinenetwork,pleaserefertotheChapter6inthe

manual

zIfthepowerlineadapterinyournetworkdoesnotfeaturea“Group/Reset”or

an“Encrypt”button,youcanusetheutilitysoftwareasanalternative.For

moredetailspleaserefertoChapter5inthemanual.

Autres manuels pour HP-5101AC
