Edimax EN-9260TX-E Manuel utilisateur

FCC Certifications

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received;

including interference that may cause undesired operation.

CE Mark Warning

This equipment complies with the requirements relating to

electromagnetic compatibility, EN 55022 class B for ITE, the essential

protection requirement of Council Directive 89/336/EEC on the

approximation of the laws of the Member States relating to

electromagnetic compatibility.

Edimax has an on-going policy of upgrading its products and it may be

possible that information in this document is not up-to-date. Please check

for the latest information at www.edimax.com. No part of this document

can be copied or reproduced in any form without written consent from the

company.

Trademarks:

All trade names and trademarks are the properties of their respective

companies.

Table of Contents

1. UNPACKING INFORMATION................................ 3

2. OVERVIEW ............................................................ 3

2.1 INTRODUCTION.................................................. 3

2.2 KEY FEATURES ................................................. 4

2.3 LED INDICATORS............................................... 4

3. INSTALLING THE PCI EXPRESS GIGABIT

ETHERNET ADAPTER.......................................... 3

3.1 SYSTEM REQUIREMENTS................................... 5

3.2 HARDWARE INSTALLATION ................................. 5

3.3 DRIVER INSTALLATION ....................................... 6

4. PRODUCT SPECIFICATIONS............................. 11

1. Unpacking Information

Thank you for purchasing the EN-9260TX-E PCI Express Gigabit Ethernet Adapter.

Before you start, please verify that your package contains the following items:

1. One EN-9260TX-E PCI Express Gigabit Ethernet Adapter.

2. One Driver/ Manual CD-ROM

2. Overview

2.1 Introduction

The EN-9260TX-E PCI Express Gigabit Ethernet Adapter is a high

performance Gigabit Ethernet adapter designed for PCI Express Bus,

which has better performance than the current PCI interface.

Supporting connection speeds of up to 1000 Mbps, it boosts your

networking throughput easily. The EN-9260TX-E allows users to transfer

high-bandwidth needed files faster and hence get a real efficiency

improvement.

The EN-9260TX-E also supports NWay auto-negotiation that detects the

networking speeds (10/100/1000 Mbps) and the duplex modes (full/half)

automatically. Auto MDI/MDI-X is also supported to alleviate the effort

choosing crossover cables.

2.2 Key Features

‧ Compliant with PCI Express 1.0a - x1 PCI Express standard

‧ Compliant with CSMA/CD protocol

‧ Supports 10/100/1000 Mbps and Full/Half-Duplex auto negotiation

‧ Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

‧ Supports Full Duplex flow control (IEEE 802.3x)

‧ Supports Auto MDI/ MDI-X auto crossover.

‧ Wake On LAN and ACPI Power Management, compliant to ACPI 2.0

‧ Integrated 128KB Frame Buffer Memory

‧ Supports Windows 98SE/2000/XP/Vista, MSC 10.4x, and Linux OS

‧ CE FCC, VCCI class B approved

2.3 LED Indicators

10M Green This adapter is connected at 10 Mbps

Blinking Green Data transmitting/ receiving at 10 Mbps

100M Green This adapter is connected at 100 Mbps

Blinking Green Data transmitting/ receiving at 100 Mbps

1000M Green This adapter is connected at 1000 Mbps

Blinking Green Data transmitting/ receiving at 1000

Mbps

3. Installing the PCI Express Gigabit Ethernet

Adapter

3.1 System Requirements

yOne available PCI Express slot

yMicrosoft Windows 98SE/2000/XP/MAC 10.4x/Linux based computer.

yA CD-ROM Drive

3.2 Hardware Installation

Caution:

Before installing this adapter, please touch the metal case of your

computer to discharge any static electricity from your body. We

recommend users to install this adapter wearing a wrist strap attached to

the PC chassis.

1.Turn off the computer.

2.Remove the computer’s cover in accordance to its manual.

3.Insert the contact edge of the adapter card into the connector of an

available PCI Express slot. Press the card firmly into the connector.

Please make sure that the card’s contacts are fully seated in the PCI

slot.

4.Install the bracket screw that secures the card to the computer

chassis.

5.Replace the computer’s cover.

6.Connect the network cable to the RJ-45 network connector.

7.Turn on the computer.

Note: You may select the networking cable according to the following

information:

10 BASE-T: Category 3,4 or 5 UTP/STP

100 BASE-TX: Category 5 UTP/STP

1000 BASE-T: Category 5, 5e UTP/STP

3.3 Driver Installation

After mounting this adapter to your computer, you have to install a driver

to activate this adapter. The following instruction uses Windows XP as the

presumed operation system. The screens upon installation differ slightly

from each operation system but the procedures are familiar. Please refer

to the following for instructions.

1. Turn your computer on after plugging the EN-9260TX-E to a PCI-E

slot. When the “Found New Hardware Wizard” pops up, click the

“Cancel” button to close the window.

2. Insert the Driver CD into your CD ROM drive. The Setup Wizard will

run automatically and display the following screen. Select

EN-9260TX-E by clicking on its product icon.

3. On the following screens, choose Setup Driver and select your

operating system.

4. When the Welcome window pops up. Click the “Next” button to start

driver installation.

5. On the following screen, click Install.

6. Please wait while driver is being installed.
