Edelbrock 6571 Manuel utilisateur

Brochure #63-6571

Rev. 5/06 - DA/mc

Catalog #6571, #65711

Edelbrock Victor Series (Competition ) Y-Pipe

for 1998-2002 LS1 Camaro and Firebird

with 5.7L V8 Engine

Catalog #6571, #65711

INSTALLATION INSTRUCTIONS

Please study these instructions carefully before installing your new Victor Series Competition Y-pipe system. If you have

any questions, contact our Technical Hotline at: 1-800-416-8628 , 7am - 5pm, Monday-Friday, Pacific Standard Time

or e-mail us at [email protected]. Please fill out and mail your warranty card.

1. With Edelbrock headers part #6570 installed, slip the left inlet adapter tube onto the left header collector.

2. Slip the Y-pipe assembly into place. The right side will slip directly onto the header collector, the left side slips over

the adapter tube that was installed in step 1.

3. Install T-bolt clamps as needed on header collector and on left inlet adapter. Position the clamps so the bolt is either

on the top or the side of the tubing for best ground clearance. The short adapter tube can be used, if needed, to attach

the vehicle’s exhaust system to the new Y-pipe assembly.

4. Be sure the hanger bar welded to the Y-pipe assembly is fully engaged into the insulator and the insulator is straight

and the attaching bolts are tight.

Note: If O2sensors are to be used, supplied O2bungs can be welded onto the Y-pipe where they are needed. Simply

mark the tube where you want the sensor, drill a 5/8” hole and weld the bung to the tube.

Special Components that may be needed, if applicable: Oxygen Senson Simulators may be purchased from the

following: SLP PT #31036, Phone (732) 349-2109; Mid America Designs, Inc. PT #609132, Phone (217) 347-5591;

RPM Outlet, Phone (713) 858-8095.

INSTALLATION INSTRUCTIONS

Suggested Tools for Installation:

❑SAE and metric socket set and rachet

❑Drill motor and 5/8” drill bit*

❑MIG or Gas welder*

*If O2sensors are being used.

Note: Your competition y-pipe is intended to be used on off-highway non-emission vehicles. It does not have a California

Air Resources Board (C.A.R.B.) Exemption Order (E.O.) number. This Y-pipe is designed to fit 1998-2002 Camaro

and Firebird with 5.7L LS1 V8 Edelbrock race headers part #6570 and #65701.

IMPORTANT NOTE:

Proper installation is the responsibility of the installer. Improper installation will void warranty and may

result in poor performance and engine or vehicle damage.

Brochure #63-6571

Rev. 5/06 - DA/mc

Catalog #6571, #65711

KIT CONTENTS

Catalog #6571

Qty.Part # Description

1 25-9074 Adapter Tube (Outlet)

1 25-9354 Y-Pipe Assembly

1 25-9355 Inlet Tube (Left)

2 46-5160 3” T-Bolt Clamps

2 46-5189 3 1/2” T-Bolt Clamps

2 52-9710 O2 Sensor Bungs

Edelbrock Corporation, 2700 California St., Torrance, CA 90503

Tech Line: (800) 416-8628; Office: (310) 781-2222

E-Mail: [email protected]

KIT CONTENTS

Catalog #65711

Qty.Part # Description

1 25-9489 Adapter Tube (Outlet)

1 25-9487 Y-Pipe Assembly

1 25-9488 Inlet Tube (Left)

2 46-5160 3” T-Bolt Clamps

2 46-5189 3 1/2” T-Bolt Clamps

2 52-9711 O2 Sensor Bungs
