Ectaco C610D Manuel utilisateur

Date:2016-03-23

C610D User Guide

Brief Introduction

The C-Pen DictionaryPen (C610D) is a portable digital tool powering linguistic

understanding and work/study efficiency.

Technically it is a Digital Highlighter pen with high quality Optical Character

Recognition (OCR), naturally speaking TTS, and multiple dictionaries

supporting English, French, German, Italian, Russian and Spanish.

C610D is *the* tool for anyone working in their second language.

Look up/translate a word: in Dictionary mode –look up word

definitions or translate words to/from English with OXFORD

dictionaries.

Listen to a word being pronounced: In Dictionary mode –Listen to

single words being pronounced with natural speaking high quality TTS.

Capture notes and quotes: In Scan to File mode –Highlight and store

text from books. Connect and upload text files to computer.

Translate word from text file: In Scan to File mode select a single word

and look it up or translate with one of the embedded dictionaries.

Voice memos: In Recorder mode –Record or listen to voice memos.

USB HID: Connect to a computer by USB and the C610D will emulate a

keyboard and input text directly to the computer. Supports English,

French, German, Italian, Spanish on Windows, MAC OSX and Linux –no

software installation required!

Date:2016-03-23

Settings / First use

At first use it is recommended to go through settings and adjust based on

preferences.

Global settings are accessible in the Main Menu -> Settings.

Left/Right handed: The DictionaryPen supports both left and right

hand usage. Use direction keys and OK button to select left or right

hand usage.

Brightness: Sets screen brightness. Use left/right direction key to set

level and OK button to confirm.

Date/Time: Use direction keys to set correct date and time. Press OK

button to confirm.

Auto shutdown: The DictionaryPen shuts down automatically when

not used for a certain time. Set this time to suit your way of using the

product.

System Information: In System Information it is possible to check

battery/charge level, available memory for storing text and voice

memos, software version, and general dictionary information.

Software upgrade: Software upgrades may be released. Information

about this will be released on www.cpen.com. For more details see

below.

Default settings: In case required, the software can be reset to factory

settings.

Date:2016-03-23

Language settings

Scan language 1: In Scan to File mode scan language setting is

accessible in Scan to File -> Scan Languages.

Scan language 2: In Dictionary mode scan language is automatically set

to match the source language of the selected dictionary. If e.g. the

French-English dictionary is selected, scan language is automatically set

to French.

Text to Speech language: In Dictionary mode it is possible to listen to

a word being pronounced (single word/words one by one). TTS

language is automatically set to match the source language of the

selected dictionary. TTS settings like e.g. reading speed and volume are

accessible in Dictionary sub menu.

Date:2016-03-23

Dictionary

C610D contains multiple dictionaries. For more details see www.cpen.com.

In Main menu, use direction keys to move to Dictionary and press OK button

to enter Dictionary mode.

Selection of a language pair (e.g. English-German): Press the left/right

direction buttons to select language pair according to your preference (first

time loading a specific dictionary may cause a short delay). Start scanning, or

press OK access settings.

Selection of a dictionary: Some language pairs have more than one

dictionary. Press the up/down direction buttons to select the preferred one.

Start scanning or press OK access history.

Dictionary settings: in Dictionary mode press the Menu button to get access

to the Dictionary settings.

Switch Dictionary: access dictionary selection per above.

Reading settings:

a. Read OK toggles re-reading of word when pressing OK button

b. Read Scan toggles reading of word directly when scanned.

c. Read Def toggles reading of dictionary definition/translation.

NOTE: only available in ENG_ENG dictionary.

Date:2016-03-23

Scan to File

Use this mode to highlight and store text from books into text files in the

device. Connect the DictionaryPen to a computer to upload/download text

files.

Files are automatically named “[date]_[index] [the last six characters of the

file]”

E.g., the fifth file created on February 15th 2016 containing the text “Use this

mode to highlight and store text from books.” will be named 160215_5

[books.].txt.

Create a new file: Move the cursor to Create a new file, and press the OK

button to create a new .txt file named by the system’s current date. Start

scanning. To exit, press the Back button.

Continue scanning into latest file: Press direction buttons + OK to select

latest (Continue…) file and use direction buttons to position the text cursor

within the file. Scan to enter text. To exit, press the Back button.

EDIT file: If there are errors in the recognition results of the words scanned,

press the OK button to delete the highlighted parts and scan again. Press the

Back button to save and quit. Moving cursor around selects character by

character. Pressing OK button deletes the highlighted character.

Open a file: Move the cursor to “Open a file”, and press the OK button to

open the list of saved files. Select your desired file, and press the OK button

to open it. Position cursor and start scanning to append text. Press Back

button to exit.

Delete a file: Move the cursor to “Delete a file”, and press the OK button to

display the list of saved files. Select the file to be deleted and press the OK

button. A dialog box will pop up to ask you whether to delete the file. Select

“Yes” to confirm the deletion, and select “No” to return to the list of files

Date:2016-03-23

without deleting any file. This action is irreversible.

File context menu: when a file is open, press Menu button to access file

context menu

Translate: In Scan to File it is possible to look up/translate a word in any

of the embedded dictionaries. Use the direction buttons to move the

cursor to any character in the chosen word. Press Menu button + select

Translate from the submenu to enter the dictionary. In the sub menu,

enter Select Dictionary to change dictionary.

Select dictionary: Use this option to select which dictionary to use for

Translate (above).

Scan languages: Go to Scan to File -> Scan Languages, or press menu

button within a text file to select OCR/scan language.

Audio

Select Recorder in the main menu.

Record: Select Record in the Recorder submenu, then left/right to set

recording quality and up down to select audio format. Press OK button to

start/stop recording.

Play recording: Select this item to play any recorded files. In the submenu,

use up/down to select the file and press OK to play. While playing, press

up/down to adjust volume.

Erase recording: Select this item to erase recorded audio files. In the

submenu, use up/down to select the file and press ok to erase. Select Yes or

No to confirm.

Play Music: Music files, or other audio files may be copied from the PC (see

USB connection – File Storage Location below) to the DictionaryPen internal

memory. Select Play Music to listen to these audio files.

Record Settings: In Record Settings, default File format and Sound Quality

can be set.

Date:2016-03-23

USB connection to PC

After connecting the pen to a computer via USB cable, the pen will prompt

you to select Keyboard, U-disk or Charging.

Keyboard mode enables text input to computer (keyboard emulation /

no drivers required / supports English and German only!). The device

charges during use.

In U-disk mode the DictionaryPen connects as a USB disk and allows to

upload/download/manage files. The device charges during use.

In Charging mode the device only charges. There is no data connection

to the PC.

Keyboard mode:

When connected to a USB Host (e.g. a computer or USB Host compliant tablet)

in Keyboard mode it emulates a keyboard. All characters scanned will be

entered into the open application just as if typing on the keyboard. There is

no specific software required.

NOTE: it is required that the keyboard setting of the computer matches the

input language in Keyboard mode.

Example: if Keyboard mode scan language is set to French, then the computer

keyboard setting must also be set to French keyboard. If the computer

keyboard setting is set to another language (different keyboard layout) then

some characters will be wrongly decoded.

U-disk file storage location:

The files of extracted text are saved in the e_ScanFile folder.

The historical records of dictionary lookup are saved in the

Date:2016-03-23

e_HistoricalRecords folder.

The sound recording files are saved in the e_Recorder folder.

The music playing files are saved in root or e_Music folder.

Date:2016-03-23

Software Update

If you want to update the system for your C-Pen DictionaryPen, please enter

this mode.

1. Update of upgrade package: Connect the DictionaryPen to a computer and

enter the U-disk mode. Copy the downloaded upgrade package to root

directory, and then exit from the U-disk mode.

2. System upgrade: In the DictionaryPen’s main system menu, select

Software Update. Select Yes and press the OK button to update the system,

or select No to return to the main menu without updating. After the upgrade,

the system will restart automatically.

Ensure the pen is properly charged prior to upgrade and make sure not to

turn off the pen during the upgrade process.

Date:2016-03-23

C-Pen DictionaryPen

1. Power On/Off & Back button: A long press powers the device on or off. In

the sub-interface, press this button to exit from the current level back to

previous interface. When prompted for selection or input, this button cancels

the operation.

2. OK button: When a dialog box or option list pops up, press this button to

confirm the operation.

3. Up/Down/Left/Right: Press these buttons to move focus or cursor. In the

Dictionary sub interface, press the left/right direction button continuously

for 1 second to roll back to the previous/next scan. Rollback is limited to the

recent 100 scans in the current session of using the dictionary.

4. Scan Trigger: When scanning, the Scan Trigger is automatically pressed to

activate scanning.

5. Screen: The device’s display screen.

6. Microphone: Used for sound recording of voice memos.

7. Speaker: Used to play audio or listen to text speech. Muted when

headphones are connected.

8. Menu button: Press this button to display context menu settings when

available.

9. Scanning window: Frames the text to be scanned.

Table des matières

Autres manuels Ectaco Dictionnaire électronique

Ectaco

Ectaco Partner EF400T Deluxe Manuel utilisateur

Ectaco

Ectaco Partner EFR430T Manuel utilisateur

Ectaco

Ectaco Partner PW800 Manuel utilisateur

Ectaco

Ectaco Partner EKS430T Manuel utilisateur

Ectaco

Ectaco Partner EF400T Deluxe Manuel utilisateur

Ectaco

Ectaco Partner EP-X5 Manuel utilisateur

Ectaco

Ectaco Partner EP-X8 Manuel utilisateur

Ectaco

Ectaco Partner P900 Manuel utilisateur

Ectaco

Ectaco Partner EFa400T Manuel utilisateur

Ectaco

Ectaco Language Teacher ECz600T Manuel utilisateur

Ectaco

Ectaco Partner EER430T Manuel utilisateur

Ectaco

Ectaco Partner ER200DM Manuel utilisateur

Ectaco

Ectaco iTRIVAL Series Manuel utilisateur

Ectaco

Ectaco Language Teacher ET200D Manuel utilisateur

Ectaco

Ectaco Language Teacher EGR486T Manuel utilisateur

Ectaco

Ectaco Partner EB600T Manuel utilisateur

Ectaco

Ectaco Partner EB400T Manuel utilisateur

Ectaco

Ectaco Partner EEL400T Manuel utilisateur

Ectaco

Ectaco Partner ER850 Manuel utilisateur

Ectaco

Ectaco Partner ESC400T Manuel utilisateur

Ectaco

Ectaco Partner LUX Manuel utilisateur

Ectaco

Ectaco Partner EP900 Manuel utilisateur

Ectaco

Ectaco SpeechGuard TL-4 Manuel utilisateur

Ectaco

Ectaco Partner AzER430T Manuel utilisateur

Manuels Dictionnaire électronique populaires d'autres marques

Sharp

Sharp PW-E310 Manuel utilisateur

Franklin

Franklin BookMan III HBD-1450 Manuel utilisateur

Eaton

Eaton DNP MINT Guide de démarrage rapide

Franklin

Franklin IC-142 Manuel utilisateur

Franklin

Franklin SCD-1890 Manuel utilisateur

Franklin

Franklin SpellingAce SA-98 Manuel utilisateur

Franklin

Franklin BOOKMAN DMQ-440 Manuel utilisateur

Besta

Besta cd 739p Manuel d'instructions

LEGRAND

LEGRAND tynetec ZXT360 Manuel utilisateur

HORITA

HORITA RLT-50 Manuel utilisateur

Language Teacher

Language Teacher ES400T Manuel utilisateur

Accent

Accent 800 Manuel utilisateur

SUPREME

SUPREME BTLT200 Manuel utilisateur

Franklin

Franklin SCD-1870 Manuel utilisateur

KMC Controls

KMC Controls KMD-5551E Guide de l'utilisateur

Sharp

Sharp PW-AM700 Manuel utilisateur

Franklin

Franklin HR-61 Manuel utilisateur

Bosch

Bosch LTC 8782 Series Manuel utilisateur
