EADM SPLIT-TYPE ROOM AIR CONDITIONER
OPERATION Indication lamp:
This lamp illuminates when the air conditioner is in
operation.
TIMER Indication lamp:
Lights up during Timer operation.
DEFROST Indication lamp:
(Enabled on cooling & heating models only): Lights up
when the air conditioner starts defrosting automatically
or when the warm air control feature is activated in
heating operation.
TEMPERATURE Indicator:
Displays the temperature settings when the air
conditioner is operational.
Displays the malfunction code.
OPERATING INSTRUCTIONS
INDICATION LAMP
Signal receiver
（A）
（B）
Signal receiver
defrost run timer
SPECIAL FUNCTIONS
Refrigerant Leakage Detection
With this new technology, the display area will appear EC and the
indication lamps will continue ashing when the outdoor unit
detects refrigerant leakage.
Louver Angle Memory Function (Optional)
Within the scope of safety angle, it will memorize the open angle
of horizontal louver. If it exceeds, it will memorize the boundry
of safety angle. In the following circumstances, it will return to
standard angle:
1) Pressing the turbo or manual control button.
2) Unplug and then plug in the machine.
So we strongly suggest that the open angle of the horizontal
louver should not be set too small, in case the condensed water
forms and drips from the horizontal louver.
Self Clean Function (Optional)
Function used after the shut down of cooling operation to clean
the Evaporator, it keeps the air fresh for the next operation.
For cooling models, the unit will operate under FAN ONLY mode
atLOWfanspeed forhalfan hour,andthen turn o automatically.
For cooling & heating models, the unit will operate as in the
below sequence :
FAN ONLY mode at Low fan speed--Heating operation with
LOW fan speed
---FAN ONLY operation--Stop Operation---Turn o.
This function is only available under COOL (AUTO COOL, FORCED
COOL) and DRY mode.
Before selecting the function, it is recommended to run the air
conditioner under cooling operation for about half an hour.
Once the Self Clean function is activated, all TIMER setting will be
cancelled.
During SELF CLEAN operation, when pressing the SELF CLEAN
button on the remote controller again,the unit will stop the
operation and turn o the unit automatically.
CLEAN AIR Function (On some models)
Improving the quality of indoor air is one of the purposes of
an air conditioner. This air conditioner is equipped with ionizer
or Plasma Dust Collector(depending on specic conguration
of the model). With the anions generated by Ionizer, the air
circulation of the air conditioner lls the room with refreshing,
natural and healthy air. The Plasma Dust Collector generates a
high voltage ionization zone, through which the air is converted
to plasma. Inside the air most of the dust, smoke, and pollen
particles are captured by the electrostatic lter.
Anti-mildew Function (Optional)
When turns o the unit on COOL, DRY, AUTO (Cool) mode, the
air conditioner will continue operating for about 10 minutes
(depending on models) with soft wind.This will help to dry
up the condensed water inside the evaporator, and prevent
the breeding of mildew. Under Anti-mildew operation, do not
restart the air conditioner until the unit iscompletely o.
NOTE
