WittSwitch Smart Plug
Setup Guide
Model: AC1100
Content
Package List ......................................................................1
Brief Introduction ............................................................. 1
1.Configuration Process ................................................. 3
1.1 IoT Gateway Pairing Instructions ....................... 3
1.1.1 Compatible IoT Gateway models ............ 3
1.1.2 Install Ecowitt app ................................... 5
1.2 Pair the AC1100 with an IoT gateway ................6
1.2.1 Power on AC1100....................................6
1.2.2 Pair with an IoT Gateway ........................ 6
2. App Operation Introduction ......................................9
2.1 Main Interface Introduction................................9
3. App Operation Modes .............................................. 13
3.1 Manual Mode ....................................................13
3.1.1 Initial statement ..................................... 14
3.1.2 Running statement ................................. 16
3.2 Button Mode ..................................................... 17
3.2.1 Short Press ............................................. 17
3.3 Plan Mode .........................................................18
3.4 Smart Mode ...................................................... 20
3.4.1 How to add an automation task ............. 21
3.4.2 How to manage automation tasks .......... 26
3.4.3 Smart Mode log ..................................... 27
3.4.4 An operation example ............................ 28
4. Log Introduction .......................................................32
4.1 Log Diary ..........................................................33
4.2 Alerts Introduction............................................ 33
5. Overview and Specifications ....................................35
5.1 AC1100BU American Regulation .................... 35
5.2 AC1100CA Australia Regulation Version .........36
5.3 AC1100AU British Regulation Version ............37
5.4 AC1100AE European Regulation Version ........38
6. Warranty ................................................................... 39
7. Trouble shooting ....................................................... 40
7.1 When you need to reconfigure the AC1100 ......40
7.1.1 Delete the AC1100 .................................40
7.1.2 Restore Factory Setting....................... 42
7.1.3 Reconfigure AC1100 and the IOT
gateway ........................................................... 42
8. Contact Us .................................................................. 42
1
Package List
1* AC1100
1* Manual
Brief Introduction
Figure 1 How Ecowitt Ecosystem works
2
Thank you for purchasing the Ecowitt AC1100 Smart
Plug.
The Ecowitt AC1100 is a brand new smart plug that is
compatible with the Ecowitt IoT ecosystem. When paired
with the Ecowitt IoT gateway, it allows remote control of
power on/off, energy consumption tracking, remote
alarms, and more. Additionally, it features a smart mode,
enabling home appliance automation based on preset
conditions.
Please note that the AC1100 needs to be used in
conjunction with the Ecowitt IoT gateway and can’t be
used as a standalone product.
The following User Manual provides step by step
instructions for installation and operation. Use this
manual to become familiar with your professional Smart
plug and save it for future reference.
3
1.Configuration Process
Before configuring the AC1100, you need to set up an
IoT-enabled gateway. IoT gateway configuration brief
introduction will be covered in Section 1.1, followed by
the configuration and usage of the AC1100 with the IoT
gateway in Section 1.2.
1.1 IoT Gateway Pairing Instructions
1.1.1 Compatible IoT Gateway models
Prepare an IOT-supported gateway that has been added to
Ecowitt, ensuring the frequency matches. The compatible
models are listed in the table below.
4
Table 1 Compatible IoT gateway Models
Compatible Models
Model
GW1200
GW2000
WS3900/WS3910
WN1980/WN1920
WS3800
WN1820/WN1821
5
1.1.2 Install Ecowitt app
1. Install "ecowitt" APP
. Install "ecowitt" app.
. Register and log in.
. Make sure the app has (precise)
location and WiFi service enabled.
. Disable your mobile phone cellular
data service until all setup steps are
done.
2. Pair hub to your home WiFi
.Run"ecowitt"app.
.Tap "menu" — >weather station" —
>"+ add a new weather station.
.Follow the instructions to complete
the hub to be added under your
account.
.You can add as many weather
stations under your account.
3. Pair AC1100 to your hub
. Tap "..." from the dashboard on top
right comer, go to "+subdevice"
. Follow the instructions to pair your
AC1100 to the hub.
4. Register sensors on your hub
. Tap "..." on the top right corner of
the dashboard to access the "Sensor
ID" page.
. Ensure that your sensor has been
correctly registered, with its sensor ID
properly matched.
(*Note: Step 4 is only applicable
when you have additional Ecowitt
sensors or for further reference.)
6
1.2 Pair the AC1100 with an IoT gateway
1.2.1 Power on AC1100
Plug it into a power outlet, press and hold the button for
more than 5 seconds, the blue light flashes and it enters
the pairing mode.
1.2.2 Pair with an IoT Gateway
(In order to illustrate clearly, here is a Pairing
demonstration with GW1200)
Click as the following steps
1. Open ecowitt app
2. Enter the gateway dashboard. Click ‘...’ on top right
corner.
3. Click ‘+Subdevice’ and choose the icon of AC1100.
4. Click ‘Device is in pairing mode’ and wait till the
success tip pops up.
7
5. Pairing completed, and it will automatically navigate
to the AC1100 interface.
