Sightseeing Bus & Cargo Truck Manual
CE certified
Read and Understand the manual before operating the car
37
35-36
34
21-31
32-33
Dear Users,
Thank you for purchasing an Ecar. We have adopted
technological advancements from Europe and the United
States as our main imported components. Our carts are
known for their innovative design. Complete with luxurious
professional paint jobs and high-strength steel which gives
our carts a stylish look while being reliable and having
excellent performance.
The notable features include being lightweight; having a
strong uphill driving function; being eco-friendly; low
noise; easy-to-charge and more while being reasonably
priced. We are proud to say our carts are the most
advanced in the field of electric carts at the moment.
We have created this operation manual in order for
us to help users operate and maintain it correctly. In
order to ensure your ecar is in the best working condition
and can be used for a long time; please read this manual
carefully.
Our products are always improving and updating. If this
manual does not exactly match the actual product at hand,
it can still serve as a standard guide. However, we advise
users to contact us regarding this matter.
NOTE: This car is designed for relaxation and sightseeing
purposes only. It’s suitable for special specific places like
tourism scenic areas, pedestrian mall and anything similar.
Please do not use on highways and roads.
IMPORTANT MANUAL INFORMATION
Particularly important
information is distinguished by
using the following symbols and
notes :
&
THE SAFETY ALERT SYMBOL
means attention and be alert.
Your safety is involved.
A WARNING
Failure to follow
WARNING
instructions could result in
severe injury or death of the golf
car passengers , bystanders, or the
person driving the golf car.
CAUTION
This message describes special
precautions that must be taken to
avoid damage to the car
This message provides
additional information.
II
NOTE:
E
car continually seeks
improvement in product quality.
Even though this manual contains
the latest product information
available at the time of
printing , there may be minor
discrepancies between your golf
car and this manual . If you have
any question concerning this
manual , please contact your
Ecar dealer and we will work it
out . This manual should be
considered as a permanent part of
your golf car and should stay with
the car when the car is resold .
A WARNING
Read and understand the
manual completely before
operating your golf car.
SAFETY OPERATION
Before operating
1.Read this manual and all the other operations or labels marked on
the car body before operating.
2.Only authorized people should drive the car and only in the
designated area.
3.Do not OVERLOAD .
4.Do not drive the car if you are intoxicated this could restrict the
driver's vision and judgment.
When operating:
I . Keep your body in the car and keep well-seated when the car starts
moving .
2. Do not start the car until all passengers are seated.
3 . Keep your hands on the steering wheel and your eyes on the path
ahead.
4. Be especially careful when backing the car in crowded places.
Please keep watching your back and drive slowly
5.
Avoid sudden start and brake.
6.
Please accelerate or decelerate the car according to the ground
condition.
7 . Do not turn the steering wheel too sharply at high speed.
8. Keep driving slowly straight up or straight down,not at one same angle
when on slopes
Do not overload or make any modification towards spare
parts without permission.
IMPORTANT LABELS
•
A WARNING
2
&SAFETY AND
• INSTRUCTION
LABELS
A WARNING
Please read the attached
labels carefully before
driving the golf car, and
promptly replace any
label that is damaged or
removed.
OPERATION SAFETY
3
The Lvtong golf car is designed to
be simple to operate. However,be
sure to follow the steps:
BEFORE OPERATING:
1. Read this manual and all the
other operations or labels marked on
the car body before operating.
2. Do the per-operation checks in
Section 6 of this manual.
3. only authorized people should
dri ve the car only in the
designated area from the
owners.
4. Do not overload,because the
car is designed to load limited
people.
5. Do not be intoxicated. This could
drestrict the driver's vision and
judgment.
6. Do not drive the car on public
roads, streets, highways etc. Such
action is illegal and dangerous.
Collisions might happen.
WHEN OPERATING:
1. make sure your body does not
stick out of the car, and remain
firmly seated when driving.
2. Do not start the car until all
passengers are seated.
34
34. Main power switch "STOP”
STRUCTURE AND SPECIFICATION
Electrical accelerator 0-5kΩ
STOP
1. Press down the "Stop" button to
cut off the main power to stop the
whole system.
2. Reset the "Stop" button by
twisting it and main power starts
working.
Main power switch "STOP”
Attention: "Stop" button can be
used in emergency to cut off the
power and stop the car
immediately.
OPERATION AND CONTROL
Combined Switch
includes: horn, side light, wiper
switch; End button is horn switch; shift
forward to turn on right side
light; shift backward to turn on left
side light; shift upward to turn on
wiper.
48V Voltage Indicator
Voltage Indicator is there to show the
electricity level and remaining charge
time. The voltage will shows fully
charged when charged enough.
1. Electricity display reduces with
the consumption of electricity during
driving.
2. When battery is close to empty, it
will show a warning by moving
between first space and second
space.
3. When the voltage indicator
displays warning, it displays by
flashing on the first space at the left.
Accelerator Pedal
Turning on the key switch,choosing
right gear,then releasing hand brake,
putting your foot on accelerator pedal
and pressing down slowly. Do not
accelerate suddenly.
Hand Brake
After fully stopping the car, pull
up the hand brake on 5-7th gear
to use parking function.
8
OPERATION AND CONTROL
Brake Pedal
Press Brake Pedal to reduce speed
and stop car.
Warning: Avoid braking
suddenly.
9
Electrical accelerator 0-5kΩ
Electrical accelerator 0-5kΩ
1. Press down the "Stop" button to
cut off the main power to stop the
whole system.
2. Reset the "Stop" button by twisting
it and the main power starts working.
3. The Main power switch "STOP” is
located in the left side of dashboard
Main power switch "STOP”
Attention: "Stop" button can be used in
an emergency to cut off the power and
stop the car immediately.
Combined Switch
includes: horn, side light, wiper
switch; End button is horn switch; shift
forward to turn on right side
light; shift backward to turn on left
side light; shift upward to turn on
wiper.
48V Voltage Indicator
Voltage Indicator is there to show the
electricity level and remaining charge
time. The voltage will shows fully
charged when charged enough.
1. Electricity display reduces with
the consumption of electricity during
driving.
2. When battery is close to empty, it
will show a warning by moving
between first space and second
space.
3. When the voltage indicator
displays warning, it displays by
flashing on the first space at the left.
Accelerator Pedal
Turning on the key switch,choosing
right gear,then releasing hand brake,
putting your foot on accelerator pedal
and pressing down slowly. Do not
accelerate suddenly.
Hand Brake
After fully stopping the car, pull
up the hand brake on 5-7th gear
to use parking function.
