Eaton Powerware 9155 Manuel utilisateur

Powerware 9155

UPS-Mounted Bypass Switch

User's Guide

For use with Powerware 9155 8–15 kVA UPS Models

Class A EMC Statements

FCC Part 15

NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in

which case the user will be required to correct the interference at his own expense.

ICES-003

This Class A Interference Causing Equipment meets all requirements of the Canadian Interference Causing Equipment Regulations ICES‐003.

Cet appareil numérique de la classe A respecte toutes les exigences du Reglement sur le matériel brouilleur du Canada.

IEC 62040-2

Some configurations are classified under IEC 62040-2 as “Class‐A UPS for Unrestricted Sales Distribution.” For these configurations, the following

applies:

WARNING This is a Class A‐UPS Product. In a domestic environment, this product may cause radio interference, in which case, the user may be

required to take additional measures.

VCCI Notice

Powerware is a registered trademark of Eaton Electrical Inc.

Greenlee is a registered trademark of Greenlee Textron.

express written approval of Eaton Corporation.

Requesting a Declaration of Conformity

Units that are labeled with a CE mark comply with the following harmonized standards and EU directives:

SHarmonized Standards: IEC 62040-1-1 and IEC 62040-2; IEC 60950 Third Edition

SEU Directives: 73/23/EEC, Council Directive on equipment designed for use within certain voltage limits

93/68/EEC, Amending Directive 73/23/EEC

89/336/EEC, Council Directive relating to electromagnetic compatibility

92/31/EEC, Amending Directive 89/336/EEC relating to EMC

The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC Declaration of Conformity, contact:

Eaton Power Quality Oy

Koskelontie 13

FIN-02920 Espoo

Finland

Phone: +358-9-452 661

Fax: +358-9-452 665 68

Special Symbols

The following are examples of symbols used on the UPS or accessories to alert you to important information:

RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the associated warning should

be observed.

CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for additional information, such

as important operating and maintenance instructions.

This symbol indicates that you should not discard the UPS or the UPS batteries in the trash. This product

contains sealed, lead‐acid batteries and must be disposed of properly. For more information, contact your

local recycling/reuse or hazardous waste center.

This symbol indicates that you should not discard waste electrical or electronic equipment (WEEE) in the

trash. For proper disposal, contact your local recycling/reuse or hazardous waste center.

EATON Powerware®9155 UPS-Mounted Bypass Switch (8–15 kVA) User's Guide S164201644 Rev A www.eaton.com/powerquality i

Table of Contents

1 Introduction 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Safety Warnings 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 UPS-Mounted Bypass Switch Installation 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MBM/PDM Setup 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Wiring the MBM/PDM 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Maintenance Bypass Switch Operation 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance Bypass Startup 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Transferring the Load to Maintenance Bypass 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Returning the Load to Normal Mode 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TABLE OF CONTENTS

EATON Powerware®9155 UPS-Mounted Bypass Switch (8–15 kVA) User's Guide S164201644 Rev A www.eaton.com/powerquality

EATON Powerware®9155 UPS-Mounted Bypass Switch (8–15 kVA) User's Guide S164201644 Rev A www.eaton.com/powerquality 1

Chapter 1 Introduction

The Maintenance Bypass Module (MBM) and Power Distribution Module (PDM) are

designed to work with an 8–15 kVA Powerware®9155 uninterruptible power system

(UPS). Both modules provide a Make-Before-Break (MBB) wrap-around bypass for

UPS maintenance or service without shutting down the load. The PDM also comes

equipped with several different types of output receptacles.

Safety Warnings

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

This manual contains important instructions that you should follow during installation and maintenance of

the UPS and batteries. Please read all instructions before operating the equipment and save this manual for

future reference.

DANGER

This UPS contains LETHAL VOLTAGES. All repairs and service should be performed by AUTHORIZED

SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS inside the UPS.

WARNING

SThis UPS contains its own energy source (batteries). The UPS output may carry live voltage even when

the UPS is not connected to an AC supply.

STo reduce the risk of fire or electric shock, install this UPS in a temperature and humidity controlled,

indoor environment, free of conductive contaminants. Ambient temperature must not exceed 40°C

(104°F). Do not operate near water or excessive humidity (95% maximum).

STo reduce the risk of fire, connect only to a circuit provided with 100 amperes maximum branch circuit

overcurrent protection in accordance with the National Electrical Code, ANSI/NFPA 70.

SOutput overcurrent protection and disconnect switch must be provided by others.

INTRODUCTION

EATON Powerware®9155 UPS-Mounted Bypass Switch (8–15 kVA) User's Guide S164201644 Rev A www.eaton.com/powerquality

Consignes de Sécurité

CONSIGNES DE SÉCURITÉ IMPORTANTES

CONSERVER CES INSTRUCTIONS

Ce manuel comporte des instructions importantes que vous êtes invité à suivre lors de toute procédure

d'installation et de maintenance des batteries et de l'onduleur. Veuillez consulter entièrement ces

instructions avant de faire fonctionner l'équipement et conserver ce manuel afin de pouvoir vous y reporter

ultérieurement.

DANGER!

Cet onduleur contient des TENSIONS MORTELLES. Toute opération d'entretien et de réparation doit être

EXCLUSIVEMENT CONFIÉE A UN PERSONNEL QUALIFIÉ AGRÉÉ. AUCUNE PIÈCE RÉPARABLE PAR

L'UTILISATEUR ne se trouve dans l'onduleur.

AVERTISSEMENT!

SCette onduleur possède sa propre source d'alimentation (batteries). Il est possible que la sortie de

l'onduleur soit sous tension même lorsque l'onduleur n'est pas connectée à une alimentation CA.

SPour réduire les risques d'incendie et de décharge électrique, installer l'onduleur uniquement à

l'intérieur, dans un lieu dépourvu de matériaux conducteurs, où la température et l'humidité ambiantes

sont contrôlées. La température ambiante ne doit pas dépasser 40 °C. Ne pas utiliser à proximité d'eau

ou dans une atmosphère excessivement humide (95 % maximum).

SAfin de réduire les risques d'incendie, n'effectuez le raccordement qu'avec un circuit muni d'une

protection de surintensité du circuit de dérivation maximum de 100 ampères conformément au Code

Électrique National (National Electrical Code) des États-Unis ANSI/NFPA 70.

SLa protection de surintensité de sortie ainsi que le sectionneur doivent être fournis par des tiers.

INTRODUCTION

EATON Powerware®9155 UPS-Mounted Bypass Switch (8–15 kVA) User's Guide S164201644 Rev A www.eaton.com/powerquality 3

Advertencias de Seguridad

INSTRUCCIONES DE SEGURIDAD IMPORTANTES

GUARDE ESTAS INSTRUCCIONES

Este manual contiene instrucciones importantes que debe seguir durante la instalación y el mantenimiento

del SIE y de las baterías. Por favor, lea todas las instrucciones antes de poner en funcionamiento el equipo y

guarde este manual para referencia en el futuro.

PELIGRO

Este SIE contiene VOLTAJES MORTALES. Todas las reparaciones y el servicio técnico deben ser efectuados

SOLAMENTE POR PERSONAL DE SERVICIO TÉCNICO AUTORIZADO. No hay NINGUNA PARTE QUE EL

USUARIO PUEDA REPARAR dentro del SIE.

ADVERTENCIA

SEste SIE contiene su propia fuente de energía (baterías). La salida del SIE puede transportar voltaje

activo aun cuando el SIE no esté conectado con una fuente de CA.

SPara reducir el riesgo de incendio o de choque eléctrico, instale este SIE en un lugar cubierto, con

temperatura y humedad controladas, libre de contaminantes conductores. La temperatura ambiente no

debe exceder los 40°C. No trabaje cerca del agua o con humedad excesiva (95% máximo).

SPara reducir el riesgo de incendio, realice la conexión únicamente hacia un circuito que cuente con un

máximo de 100 amperios de protección contra sobrecorriente de circuito derivado, de acuerdo con el

Código Eléctrico Nacional, ANSI/NFPA 70.

SLa protección contra sobrecorriente de salida y el conmutador de desconexión debe suministrarse por

parte de terceros.

INTRODUCTION

EATON Powerware®9155 UPS-Mounted Bypass Switch (8–15 kVA) User's Guide S164201644 Rev A www.eaton.com/powerquality
