6EATON FT1455-L3 Hand Launcher Operating Instructions E-HOAI-CC003-E May 2015
Nozzle and projectile selection chart
Figure 10
Figure 11
**Use larger recommended Eaton Projectiles when
cutting hose with an abrasive wheel. The above sizes are
recommendations. Due to different types of fittings, and the
amount ofcontamination in the line, the size projectile may need
to be adjusted.
Recommnedation for Hoses
Nominal Daimeter
Inches mm Nozzle Part # Cleaning projectile part #
3/16 05 FT1455-N-H06 FT1355-H-06
¼ 06 FT1455-N-H06 FT1355-H-10 or FT1355-H-12
5/16 08 FT1455-N-H08 FT1355-H-12 or FT1355-H-14
3/8 10 FT1455-N-H10 FT1355-H-14 or FT1355-H-16
½ 13 FT1455-N-H13 FT1355-H-18 or FT1355-H-20
5/8 16 FT1455-N-H16 FT1355-H-22
¾ 19 FT1455-N-H19 FT1355-H-26
1 25 FT1455-N-H25 FT1355-H-33 or FT1355-H-36
1-1/4 32 FT1455-N-H32 FT1355-H-40 or FT1355-H-45
1-1/2 38 FT1455-N-H38 FT1355-H-50 or FT1355-H-55
2 50 FT1455-N-H50 FT1355-H-60 or FT1355-H-65
2-1/2 63 FT1455-N-U55 FT1355-H-75
3 76 FT1455-N-U55 FT1355-H-85
3-1/2 89 FT1455-N-U55 FT1355-H-100
4 102 FT1455-N-45
4-1/2 114 FT1455-N-45
Recommendations for hose assemblies with ORS ttings
ORS
tting
dash
size Nozzle Part #
Cleaning Projectile
Part #
-4 FT1455-4FFORX FT1355-H-06 OR FT1355-H-07
-6 FT1455-N-H06 FT1355-H-12
-8 FT1455-N-H10 FT1355-H-16
-10 FT1455-N-H13 FT1355-H-22
-12 FT1455-N-H16 FT1355-H-26
-16 FT1455-N-H19 FT1355-H-33
-20 FT1455-N-H25 FT1355-H-40
Recommendations for projectiles for hose assemblies
with JIC ttings
JIC Fitting
dash Size Nozzle Part #
Cleaning Projectile
part #
-4 FT1455-J-06 FT1355-H-06 OR FT1355-H-07
-6 FT1455-J-10 FT1355-H-12
-8 FT1455-J13 FT1355-H-16
-10 FT1455-J16 FT1355-H-22
-12 FT1455-J-19 FT1355-H-26
-16 FT1455-J-25 FT1355-H-33
-20 FT1455-J-32 FT1355-H40
-24 FT1455-J-38 FT1355-H-50
-32 FT1455-J-50 FT1355-H-60
Figure 13
Recommendations for hose assemblies with
code 61 or 62 anges
Code 61 or 62
ange dash Size Nozzle Part #
Cleaning Projectile
part #
-8 FT1455-H-10 FT1355-H-16
-10 FT1455-H-13 FT1355-H-22
-12 FT1455-H-16 FT1355-H-26
-16 FT1455-H-19 FT1355-H-33
-20 FT1455-H-25 FT1355-H-40
-24 FT1455-H-32 FT1355-H-50
-32 FT1455-H-38 FT1355-H-60
Figure 12
