E-Broh Spuma Li Manuel d'instructions
1
Manual for quick start
Manual for electrical motorcycles SPUMA li.
MANEBROH003-EN
2
3
Notice for user
Warnings
1. Please read carefully this Manual before using the motorcycle for a correct use.
2. Check please carefully whether parts are complete as indicated in the Manual of the product before your ride for the sake of safety.
3. Please follow trafc laws. Slow down on rainy or snowy days, on slippery roads.
4. The scooter Ebroh can operate on rainy or snowy days, on slippery roads. Increase the braking distance for the sake of safety.
5. Do not dismantle the scooter on your own.
6. Please contact the after-sales service for replacement or purchase of original parts.
7. Do not lend your Spuma Li to those who can´t operate an Ebroh scooter for the safety of the others and for preventing unnecessary
damage to your scooter.
8. Please keep this Manual and the Guarantee Card properly.
9. Do not connect nor disconnect the battery when the switch is on.
1. 1. Rider and passenger
Spuma Li is not designed for a ride of more than 2 persons.
2. 2. Road conditions
Spuma Li is only suitable for riding on asphalt.
3. 3. Please read carefully this Maintenance Manual.
Warning: failure to follow the instructions herein may lead to serious casualties.
Caution: Failure to follow the instructions herein may lead to personal injury or damage of parts.
Note: Provide useful information.
4. This product Manual should be deemed as a permanent document of Spuma Li scooter. If this scooter is transferred to others, this Manual
should be handed over to the new owner as well. Without the written consent of the Company Ebroh, reproduction or reprint of any part of
this Manual is prohibited.
4
1. Using safety clothes is very important. Use a quality safety helmet.
2. Know your Spuma Li. Your riding skills and mechanical knowledge are the basis for safe riding. You are advised to practice your riding on
open, quiet roads, and to know the mechanical performance and operation methods at rst.
3. Be aware of your riding skills. Always ride the scooter within your skill range. Knowing your riding skills and the operation methods of the
scooter will prevent accidents.
4. Pay attention on our driving. It should be noted that the braking distance on rainy days should be twice of that on sunny days. Always avoid
the roads with paint markers, manhole covers and oil stains to prevent slipping. Pay extra attention when riding through railway crossings,
iron fences and bridges. Slow down if road conditions are unclear.
5. Do not use the high beam light indiscriminately.
Continuous use of the high beam light on urban roads and pedestrian roads may disturb the visibility of the drivers and pedestrians and affect
normal, safe driving. Do not use the high beam light when the road is well lighted.
6. Do not make or receive calls while riding.
Making or receiving calls while riding is one of the main reasons for inattention and will easily cause accidents. Please stop the scooter before
you make or receive calls.
7. Do not change the lane indiscriminately.
Changing the lane indiscriminately is one of the main reasons of accidents. When you need to change the lane, remember to switch on the turn
indicator rst. Check the scooters approaching for behind and change the lane when it´s safe.
Safety notes
5
Contents
1. Notice for User.................................................................................................................................................................................................................................................................................... 3
2. Cautions .................................................................................................................................................................................................................................................................................................. 3
3. Safety Notice....................................................................................................................................................................................................................................................................................... 4
4. Parts Information............................................................................................................................................................................................................................................................................. 6
5. Operational Guide for Ebroh scooter Spuma Li.................................................................................................................................................................................................... 8
6. Dos and Don´ts in Riding.............................................................................................................................................................................................................................................................13
7. Maintenance, Repair and Storage ....................................................................................................................................................................................................................................15
8. Guarantee Policy.............................................................................................................................................................................................................................................................................. 19
9. Technical Information .................................................................................................................................................................................................................................................................. 20
6
19
PARTS INFORMATION
1. Head light led
2. Front shock absorber.
3. Battery
4. Rear carrier
5. Rear light.
6. Intermittent Back Indicator led.
7. Motor brushless
8. Intermittent Front Indicator led
9. Back Reector (LR)
10. Brake levers (LR)
11. Support Side Stand.
12. Front disc brake.
13. Central easel
14 Rear tyre
15 Front tyre
16 Mirrors.
17 Rear fender.
18 Stand of switch.
19 Plug for battery charging.
7
Según modelo
1. Left turn 7. Battery percentage.
2. Right turn 8. Throttle handle failure.
3. High beam light 9. Brake fault.
4. Stop or parking indicator (according to model) 10. Motor fault.
5. Gear shift indicator. (according to model) 11. Low battery warning (<10%)
6. Total of kilometres travelled. 12. Battery charge status indicator
Indicador de batería H-L barra vertical de la izquierda
1. 81-100%: ve lines. 5. 11%-20%: one line
2. 61-80%: four lines. 6. 6%-10%: ash line.
3. 41-60%: three lines. 7. 0%-5%: non line.
4. 21-40%: two lines.
Display information
8
Start the scooterOpen the trunk
Lock the
steering
handlebar
Open the trunk
O
On
Insert the key into the lock hole and
turn it.
Apagado y encendido para abrir y
bloquear el maletero.
Turn to to lock the steering
handlebar.
Operational Guide
9
Operational Guide
Left Combination
High/Low Beam Light: Press the upper part to turn on the high beam light; press
the lower part to turn on the low beam light.
Turn Indicator: Push the button left to turn on the Left Turn (2) Indicator; push the
button right to turn on the Right Turn Indicator. Press the button to reset the
Left/Right Turn.
High/Low Beam Light
High Beam Light
Low Beam Light
Press the button to reset/switch
off.
Push the button left/right to turn
on the Left/Right Turn Indicator.
Turn Indicator
Horn.
10
Right Combination
Double ash. Parking
light
Motor Switch.
Reverse Gear.
Steering Handlebar
Front Brake.
Change.
Maintenance switch
(upon model)
Operational Guide
