DZOFILM TANGO ZOOM Manuel utilisateur

TANGO ZOOM LENS

USER’S MANUAL

󴝬󰶱󳰛󱄷󱋸󳁆󵑼󱡔󰺟󳑈󴬔󲔮󰶆



󳑕󱺑󵑼󱡔

CINE LENS

Introduction ...................................................................................1

Safety Notes..................................................................................1

Lens Parts ..................................................................................... 2

Lens Control.................................................................................. 3

Flange Back Adjustment............................................................ 5

1. Method One.......................................................................... 5

2. Method Two ......................................................................... 6

PL Mount Assembly Instruction...............................................10

EF Mount Assembly Instruction............................................... 11

Speciﬁcation................................................................................12

After-sales Service .....................................................................13

The Name and Content of Hazardous Substances.............15

Contents

Click to go





Search keyword









Note

















         



         

        



Introduction

Safety Notes















































Lens Parts





















































Focus Control

Rotate the focus ring to increase or decrease the focus distance.



Lens Control

Focus Ring

Zoom Control

Rotate the zoom ring to zoom out, increasing the area visible in the frame

or zoom in on the subject so that it ﬁlls a larger area in the frame.

Zoom Ring



Aperture Control





Flange Back Ring

Aperture Ring

Flange Back Adjustment

Rotate the ﬂange back adjustment ring to adjust the ﬂange back distance to

keep the focusing marks accurate.

Note：Adjustable ﬂange back range ±0.2mm

Rotate the aperture ring to enlarge or reduce the diameter of the aperture,

adjusting the brightness of the image and the bokeh effect of the subject's

background.

1. Method One

1.1 Preparation

1.2 Flange Back Adjustment













           



Step Two : 

Step Three :



Step One : 



Step One : 



Step Two : 









Note :

You can download and print the chart on “DZOFILM website-Support

-Download Center-Tool-Star Chart” For Adjusting Back Flange

(Click to jump to the website）

Flange Back Adjustment



2. Method Two

2.1 Preparation

Note: The adjustable ﬂange back range of Method One is ±0.2mm, if

this range is exceeded, use Method Two.

Note: You can download and print the chart on “DZOFILM website-Sup-

port-Download Center-Tool-Star Chart” For Adjusting Back Flange

(Click to jump to the website）

Note: About the shooting distance in Step Four:

① Tango Zoom 18-90mm needs setting at 1.5m or 7 ft;

② Tango Zoom 65-280mm needs setting at 3.5m or 11 ft.

Step Three : Repeat step One and Two until without moving the

focusing ring, the wide-angle end and telephoto end are both in sharp

focus and the focusing scales are accurate . This means the lens is

parfocal. Then tighten the headless screw on the ﬂange back

adjustment ring in the clockwise direction to complete the ﬂange back

adjustment.

Step One :

Ready your subject. You can use a "Star Chart", or other

high-resolution black-and-white objects;

Step Two :

Attach the lens to the camera;

Step Three :

Select the maximum aperture (wide open);

Step Four :

Set the object 1.5m away from the camera sensor plane,

and adjust it to the center of the whole image.

Back to Contents

Note :

If the focus ring is changed durning adjusting, please start from the

ﬁrst step.

2.2 Flange Back Adjustment

S2S1.



Step One :





S1

Step Two :





S2

Step Three :

S2  S1S2S1



Step Four :

1-2S2=S1





Tango Zoom 18-90mm（Metric）

     90mm        

  1.5m (S1)  

   18mm        

 1.3m (S2).S2<S1.

0.13mm 

  18mm90mm

1.5m



1.5m





1.5m


