DURKOPP ADLER 581 Manuel d'utilisation

581

Additional Instructions

Fitting the sewing lamp

Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents,

including extracts, is prohibited without the written approval in advance of Dürkopp Adler AG.

IMPORTANT

READ CAREFULLY BEFORE USE

KEEP FOR FUTURE REFERENCE

Table of Contents

Additional Instructions 581 - 00.0 -02/2015 1

1 Components in the parts set.....................................................3

2 Fitting the sewing lamp..............................................................4

2.1 Removing components.................................................................5

2.2 Fitting the housing with printed circuit board................................7

Table of Contents

2Additional Instructions 581 - 00.0 -02/2015

Components in the parts set

Additional Instructions 581 - 00.0 - 02/2015 3

1 Components in the parts set

The parts set 0580 101644 is intended for class 581 machines.

Before fitting, check that the scope of delivery of the parts set is correct.

Fig. 1: Parts set

Part no. Quantity Designation

0791 581716 EN 1Additional instructions

0580 101610 1Housing

9352 000020 6Clamping disk

9850 580007 1Printed circuit board

Fitting the sewing lamp

4Additional Instructions 581 - 00.0 - 02/2015

2 Fitting the sewing lamp

In order to be able to fit the parts set, you must remove the existing

components.

When doing so, comply with the following

Sequence:

1. Remove the clamping plates.

2. Remove the finger protection.

3. Detach the housing.

4. Detach the head cover.

5. Remove the head cover.

6. Remove the housing.

Now you can fit the new housing with the printed circuit board.

WARNING

Risk of electric shock from live parts!

Dangerous injuries to life and limb possible.

The sewing light may only be fitted by qualified

specialists.

Switch off the machine and unplug the power plug.

Make sure the power plug cannot be

unintentionally reinserted.

Fitting the sewing lamp

Additional Instructions 581 - 00.0 - 02/2015 5

2.1 Removing components

A description of how to remove the clamping plates is provided in the

Operating Instructions.

To remove the other components:

Step

1. Remove the screws (2).

2. Remove the finger protection (1).

Fig. 2: Removing the finger protection

3. Remove 3 screws (3) (width across flats 3) from the housing for the

drive belts (4).

Fig. 3: Detaching the housing

(1) - Finger protection (2) - Screws

(3) - Screws (4) - Housing

②

①

④

③

Fitting the sewing lamp

6Additional Instructions 581 - 00.0 - 02/2015

4. Loosen the screws on the head cover (5).

5. Remove the head cover (5).

6. Remove the housing for the drive belts (4).

Fig. 4: Removing the head cover

(5) - Head cover

⑤

Fitting the sewing lamp

Additional Instructions 581 - 00.0 - 02/2015 7

2.2 Fitting the housing with printed circuit board

Step

1. Place the housing (1) with preassembled printed circuit board under

the sewing head.

Fig. 5: Housing with printed circuit board

2. Connect the X411 cable (3) to the tab connector of the printed circuit

board (2).

Fig. 6: Connecting the cable

3. Secure the housing with the 3 screws (2.1Removingcomponents,

pg. 5).

(1) - Housing (2) - Printed circuit board

(3) - X411 cable

①

②

③

Fitting the sewing lamp

8Additional Instructions 581 - 00.0 - 02/2015

4. Retighten the head cover.

5. Fit the finger protection.

6. Insert the clamping plates (see Operating Instructions).
