LINK MASTER
1. Introduction
1.1. About the LINK Master
Thank you for purchasing this House of DURATECH product. To ensure proper operation,
please read this manual carefully before using the device. After reading this manual, be
sure to keep it for future reference.
The LINK Master is a pre-wired central electrical hub, linking all technical pool-related
devices. It makes complex swimming pool installations easier to install and connect.
Making it possible for different devices to work together without adding dedicated cabling
between these devices.
House of DURATECH devices are automatically recognized and set by default. You also
have the possibility to add and connect Multi-Brand devices.
The LINK Master is equipped with multiple ‘smart’ input and output connections for your
pool devices. Giving you full access to the DuraLinkTM connected range of products.
Connect the LINK Master to the internet and it will automatically connect to the Dura-
Cloud App and Portal for easy configuration and operation of the different devices.
The LINK Master ensures efficient and safe operation of your pool.
Be aware that the LINK Master is an exact and sensitive system that must always be
handled with care. During installation, the regulations and provisions applicable for the
country and site of installation must be respected.
8
1.2. Box content
Check that the following parts are supplied with the product.
- 1 x Cabinet
- 1 x Wall mounting plate
- 2 x Cabinet door triangle keys
- 1 x Quick guide
- 1 x Fixing set (screws, plugs)
- 1 x Antenna
DLM-600
9
1.3. Keypad
High level overview of the LINK Master and the two keypads that are inside.
DLM 600
10
1.3.1. Controller keypad
Manual button Filling button Aux button Cover button
Used for switching between
manual and automatic mode.
Used for enabling/disabling
the filling mode of the pool.
Used for turning Auxiliary port
on or off.
This button will open/close
the pool cover
DuraLink button Heating button Sensors button Relay A button
Used for enabling/disabling
discovery mode.
Used for turning the heat
pump on or off.
Used for turning the sensors
on or off.
(By default this led is on.)
Used for activating your
Relay A function. (→
2.2.3.)
Cleaning button Filtration button Lights button Relay B button
Used for enabling/disabling
cleaning mode for the pool
Used for turning the filtration
pump on or off.
Used for turning the pool lights
on or off.
Used for activating your
Relay B function (→ 2.2.3.)
1.3.2. Gateway keypad
On/Off button Cloud LED
This button will turn on/off the
gateway.
This led will be on if your
LINK Master has an internet
connection.
DuraLink LED Direct Wifi button
This led will blink if it receives
a wireless DuraLink message.
This button will enable
an access point on your
gateway.
Owner button
This button is used to
become owner in the Dura-
Cloud App (→ 2.2.2.2.)
