RS-232C Communication

6789

1 2 3 4 5 6789

1 2 3 4 5

CONTROL port RS-232C cable (Cross) RS-232C port

of the projector of the computer

- (1) (1) CD

RD (2) (2) RD

TD (3) (3) TD

- (4) (4) DTR

GND (5) (5) GND

- (6) (6) DSR

RTS (7) (7) RTS

CTS (8) (8) DTS

- (9) (9) RI

Connecting the cable

1. Turn off the projector and the computer.

2. Connect the CONTROL port of the projector with a RS-232C port of

the computer by a RS-232C cable (cross). Use the cable that fulfills the

specication shown in the previous page.

3. Turn the computer on, and after the computer has started up turn the

projector on.

Communications setting

19200bps, 8N1

1. Protocol

Consist of header (7 bytes) + command data (6 bytes).

2. Header

BE + EF + 03 + 06 + 00 + CRC_low + CRC_high

CRC_low : Lower byte of CRC ag for command data

CRC_high : Upper byte of CRC ag for command data

3. Command data

Command data chart

byte_0 byte_1 byte_2 byte_3 byte_4 byte_5

Action Type Setting code

low high low high low high

Action (byte_0 - 1)

Action Classication Content

1 SET Change setting to desired value.

2 GET Read projector internal setup value.

4 INCREMENT Increment setup value by 1.

5 DECREMENT Decrement setup value by 1.

6 EXECUTE Run a command.

8755E

RS-232C Communication (continued)

Requesting projector status (Get command)

(1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes)+

‘00H’ +‘00H’) from the computer to the projector.

(2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer.

Changing the projector settings (Set command)

(1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) +

setting code (2 bytes)) from the computer to the projector.

(2) The projector changes the setting based on the above setting code.

(3) The projector returns the response code ‘06H’ to the computer.

Using the projector default settings (Reset Command)

(1) The computer sends the default setting code Header + Command data (‘06H’+

‘00H’ + type (2 bytes) +‘00H’+‘00H’) to the projector.

(2) The projector changes the specied setting to the default value.

(3) The projector returns the response code ‘06H’ to the computer.

Increasing the projector setting value (Increment command)

(1) The computer sends the increment code Header + Command data (‘04H’+

‘00H’+ type (2 bytes) +‘00H’+‘00H’) to the projector.

(2) The projector in creases the setting value on the above setting code.

(3) The projector returns the response code ‘06H’ to the computer.

Decreasing the projector setting value (Decrement command)

(1) The computer sends the decrement code Header + Command data (‘05H’+

‘00H’+ type (2 bytes) +‘00H’ + ‘00H’) to the projector.

(2) The projector decreases the setting value on the above setting code.

(3) The projector returns the response code ‘06H’ to the computer.

When the projector cannot understand the received command

When the projector cannot understand the received command, the error code ‘15H’

is sent back to the computer.

Sometimes the projector cannot properly receive the command. In such a

case, the command is not executed and the error code ‘15H’ is sent back to the

computer. If this error code is returned, send the same command again.

When the projector cannot execute the received command.

When the projector cannot execute the received command, the error code ‘1CH’

+ ‘xxxxH’ is sent back to the computer. When the data length is greater than

indicated by the data length code, the projector ignore the excess data code.

Conversely when the data length is shorter than indicated by the data length

code, an error code will be returned to the computer.

NOTE • Operation cannot be guaranteed when the projector receives an undened

command or data.

• Provide an interval of at least 40ms between the response code and any other code.

• The projector outputs test data when the power supply is switched ON, and when the

lamp is lit. Ignore this data.

• Commands are not accepted during warm-up.

Names Operation Type Header Command Data

CRC Action Type Setting Code

Power Set Turn off BE EF 03 06 00 2A D3 01 00 00 60 00 00

Turn on BE EF 03 06 00 BA D2 01 00 00 60 01 00

Get BE EF 03 06 00 19 D3 02 00 00 60 00 00

(Example return)

00 00 01 00 02 00

(Off) (On) (Cool down)

Input Source Set RGB IN 1 BE EF 03 06 00 FE D2 01 00 00 20 00 00

RGB IN 2 BE EF 03 06 00 3E D0 01 00 00 20 04 00

VIDEO BE EF 03 06 00 6E D3 01 00 00 20 01 00

S-VIDEO BE EF 03 06 00 9E D3 01 00 00 20 02 00

COMPONENT BE EF 03 06 00 AE D1 01 00 00 20 05 00

Get BE EF 03 06 00 CD D2 02 00 00 20 00 00

Error Status Get BE EF 03 06 00 D9 D8 02 00 20 60 00 00

(Example return)

00 00 01 00 02 00 03 00

(Normal) (Cover error) (Fan error) (Lamp error)

04 00 05 00 06 00 07 00

 (Temperror) (Airowerror) (Lamptimeerror) (Coolerror)

08 00 09 00 10 00

(Filter error) (Filter missing error)(Inner Sencer error)

BRIGHTNESS Get BE EF 03 06 00 89 D2 02 00 03 20 00 00

Increment BE EF 03 06 00 EF D2 04 00 03 20 00 00

Decrement BE EF 03 06 00 3E D3 05 00 03 20 00 00

BRIGHTNESS Reset Execute BE EF 03 06 00 58 D3 06 00 00 70 00 00

CONTRAST Get BE EF 03 06 00 FD D3 02 00 04 20 00 00

Increment BE EF 03 06 00 9B D3 04 00 04 20 00 00

Decrement BE EF 03 06 00 4A D2 05 00 04 20 00 00

CONTRAST Reset Execute BE EF 03 06 00 A4 D2 06 00 01 70 00 00

PICTURE MODE Set NORMAL BE EF 03 06 00 23 F6 01 00 BA 30 00 00

CINEMA BE EF 03 06 00 B3 F7 01 00 BA 30 01 00

DYNAMIC BE EF 03 06 00 E3 F4 01 00 BA 30 04 00

BOARD(BLACK) BE EF 03 06 00 E3 EF 01 00 BA30 20 00

BOARD(GREEN) BE EF 03 06 00 73 EE 01 00 BA 30 21 00

WHITEBOARD BE EF 03 06 00 83 EE 01 00 BA30 22 00

Get BE EF 03 06 00 10 F6 02 00 BA 30 00 00

(Example return)

00 00 01 00 04 00 10 00

(Normal) (Cinema) (Dynamic) (Custom)

20 00 21 00 22 00

BOARD(BLACK) BOARD(GREEN) (WHITEBOARD)

GAMMA Set #1 DEFAULT BE EF 03 06 00 07 E9 01 00 A1 30 20 00

#1 CUSTOM BE EF 03 06 00 07 FD 01 00 A1 30 10 00

#2 DEFAULT BE EF 03 06 00 97 E8 01 00 A1 30 21 00

#2 CUSTOM BE EF 03 06 00 97 FC 01 00 A1 30 11 00

#3 DEFAULT BE EF 03 06 00 67 E8 01 00 A1 30 22 00

#3 CUSTOM BE EF 03 06 00 67 FC 01 00 A1 30 12 00

#4 DEFAULT BE EF 03 06 00 F7 E9 01 00 A1 30 23 00

#4 CUSTOM BE EF 03 06 00 F7 FD 01 00 A1 30 13 00

#5 DEFAULT BE EF 03 06 00 C7 EB 01 00 A1 30 24 00

#5 CUSTOM BE EF 03 06 00 C7 FF 01 00 A1 30 14 00

Get BE EF 03 06 00 F4 F0 02 00 A1 30 00 00

RS-232C Communication (continued)

Names Operation Type Header Command Data

CRC Action Type Setting Code

User Gamma Pattern Set Off BE EF 03 06 00 FB FA 01 00 80 30 00 00

9 step grayscale BE EF 03 06 00 6B FB 01 00 80 30 01 00

15 steps grayscale BE EF 03 06 00 9B FB 01 00 80 30 02 00

Ramp BE EF 03 06 00 0B FA 01 00 80 30 03 00

Get BE EF 03 06 00 C8 FA 02 00 80 30 00 00

User Gamma Point1 Get BE EF 03 06 00 08 FE 02 00 90 30 00 00

Increment BE EF 03 06 00 6E FE 04 00 90 30 00 00

Decrement BE EF 03 06 00 BF FF 05 00 90 30 00 00

User Gamma Point2 Get BE EF 03 06 00 F4 FF 02 00 91 30 00 00

Increment BE EF 03 06 00 92 FF 04 00 91 30 00 00

Decrement BE EF 03 06 00 43 FE 05 00 91 30 00 00

User Gamma Point3 Get BE EF 03 06 00 B0 FF 02 00 92 30 00 00

Increment BE EF 03 06 00 D6 FF 04 00 92 30 00 00

Decrement BE EF 03 06 00 07 FE 05 00 92 30 00 00

User Gamma Point4 Get BE EF 03 06 00 4C FE 02 00 93 30 00 00

Increment BE EF 03 06 00 2A FE 04 00 93 30 00 00

Decrement BE EF 03 06 00 FB FF 05 00 93 30 00 00

User Gamma Point5 Get BE EF 03 06 00 38 FF 02 00 94 30 00 00

Increment BE EF 03 06 00 5E FF 04 00 94 30 00 00

Decrement BE EF 03 06 00 8F FE 05 00 94 30 00 00

User Gamma Point6 Get BE EF 03 06 00 C4 FE 02 00 95 30 00 00

Increment BE EF 03 06 00 A2 FE 04 00 95 30 00 00

Decrement BE EF 03 06 00 73 FF 05 00 95 30 00 00

User Gamma Point7 Get BE EF 03 06 00 80 FE 02 00 96 30 00 00

Increment BE EF 03 06 00 E6 FE 04 00 96 30 00 00

Decrement BE EF 03 06 00 37 FF 05 00 96 30 00 00

User Gamma Point8 Get BE EF 03 06 00 7C FF 02 00 97 30 00 00

Increment BE EF 03 06 00 1A FF 04 00 97 30 00 00

Decrement BE EF 03 06 00 CB FE 05 00 97 30 00 00

COLOR TEMP Set LOW BE EF 03 06 00 6B F4 01 00 B0 30 01 00

MIDDLE BE EF 03 06 00 9B F4 01 00 B0 30 02 00

HIGH BE EF 03 06 00 0B F5 01 00 B0 30 03 00

Hi-BRIGHT-1 BE EF 03 06 00 3B F2 01 00 B0 30 08 00

Hi-BRIGHT-2 BE EF 03 06 00 AB F3 01 00 B0 30 09 00

CUSTOM-LOW BE EF 03 06 00 AB F9 01 00 B0 30 11 00

CUSTOM-MID BE EF 03 06 00 5B F9 01 00 B0 30 12 00

CUSTOM-HIGH BE EF 03 06 00 CB F8 01 00 B0 30 13 00

CUSTOM-Hi-BRIGHT-1 BE EF 03 06 00 FB FF 01 00 B0 30 18 00

CUSTOM-Hi-BRIGHT-2 BE EF 03 06 00 6B FE 01 00 B0 30 19 00

Get BE EF 03 06 00 C8 F5 02 00 B0 30 00 00

COLOR TEMPGAIN R Get BE EF 03 06 00 34 F4 02 00 B1 30 00 00

Increment BE EF 03 06 00 52 F4 04 00 B1 30 00 00

Decrement BE EF 03 06 00 83 F5 05 00 B1 30 00 00

RS-232C Communication (continued)

Names Operation Type Header Command Data

CRC Action Type Setting Code

COLOR TEMPGAIN G Get BE EF 03 06 00 70 F4 02 00 B2 30 00 00

Increment BE EF 03 06 00 16 F4 04 00 B2 30 00 00

Decrement BE EF 03 06 00 C7 F5 05 00 B2 30 00 00

COLOR TEMP GAIN B Get BE EF 03 06 00 8C F5 02 00 B3 30 00 00

Increment BE EF 03 06 00 EA F5 04 00 B3 30 00 00

Decrement BE EF 03 06 00 3B F4 05 00 B3 30 00 00

COLOR TEMP

OFFSET R Get BE EF 03 06 00 04 F5 02 00 B5 30 00 00

Increment BE EF 03 06 00 62 F5 04 00 B5 30 00 00

Decrement BE EF 03 06 00 B3 F4 05 00 B5 30 00 00

COLOR TEMP

OFFSET G Get BE EF 03 06 00 40 F5 02 00 B6 30 00 00

Increment BE EF 03 06 00 26 F5 04 00 B6 30 00 00

Decrement BE EF 03 06 00 F7 F4 05 00 B6 30 00 00

COLOR TEMP

OFFSET B Get BE EF 03 06 00 BC F4 02 00 B7 30 00 00

Increment BE EF 03 06 00 DA F4 04 00 B7 30 00 00

Decrement BE EF 03 06 00 0B F5 05 00 B7 30 00 00

COLOR Get BE EF 03 06 00 B5 72 02 00 02 22 00 00

Increment BE EF 03 06 00 D3 72 04 00 02 22 00 00

Decrement BE EF 03 06 00 02 73 05 00 02 22 00 00

COLOR Reset Execute BE EF 03 06 00 80 D0 06 00 0A 70 00 00

TINT Get BE EF 03 06 00 49 73 02 00 03 22 00 00

Increment BE EF 03 06 00 2F 73 04 00 03 22 00 00

Decrement BE EF 03 06 00 FE 72 05 00 03 22 00 00

TINT Reset Execute BE EF 03 06 00 7C D1 06 00 0B 70 00 00

SHARPNESS Get BE EF 03 06 00 F1 72 02 00 01 22 00 00

Increment BE EF 03 06 00 97 72 04 00 01 22 00 00

Decrement BE EF 03 06 00 46 73 05 00 01 22 00 00

SHARPNESS Reset Execute BE EF 03 06 00 C4 D0 06 00 09 70 00 00

PROGRESSIVE Set TURN OFF BE EF 03 06 00 4A 72 01 00 07 22 00 00

TV BE EF 03 06 00 DA 73 01 00 07 22 01 00

FILM BE EF 03 06 00 2A 73 01 00 07 22 02 00

Get BE EF 03 06 00 79 72 02 00 07 22 00 00

VIDEO NR Set LOW BE EF 03 06 00 26 72 01 00 06 22 01 00

MIDDLE BE EF 03 06 00 D6 72 01 00 06 22 02 00

HIGH BE EF 03 06 00 46 73 01 00 06 22 03 00

Get BE EF 03 06 00 85 73 02 00 06 22 00 00

MY MEMORY Load Set 1 BE EF 03 06 00 0E D7 01 00 14 20 00 00

2 BE EF 03 06 00 9E D6 01 00 14 20 01 00

3 BE EF 03 06 00 6E D6 01 00 14 20 02 00

4 BE EF 03 06 00 FE D7 01 00 14 20 03 00

MY MEMORY Save Set 1 BE EF 03 06 00 F2 D6 01 00 15 20 00 00

2 BE EF 03 06 00 62 D7 01 00 15 20 01 00

3 BE EF 03 06 00 92 D7 01 00 15 20 02 00

4 BE EF 03 06 00 02 D6 01 00 15 20 03 00

RS-232C Communication (continued)

Names Operation Type Header Command Data

CRC Action Type Setting Code

ASPECT Set 4:3 BE EF 03 06 00 9E D0 01 00 08 20 00 00

16:9 BE EF 03 06 00 0E D1 01 00 08 20 01 00

14:9 BE EF 03 06 00 CE D6 01 00 08 20 09 00

SMALL BE EF 03 06 00 FE D1 01 00 08 20 02 00

NORMAL BE EF 03 06 00 5E DD 01 00 08 20 10 00

Get BE EF 03 06 00 AD D0 02 00 08 20 00 00

OVER SCAN Get BE EF 03 06 00 91 70 02 00 09 22 00 00

Increment BE EF 03 06 00 F7 70 04 00 09 22 00 00

Decrement BE EF 03 06 00 26 71 05 00 09 22 00 00

OVER SCAN Reset Execute BE EF 03 06 00 EC D9 06 00 27 70 00 00

V POSITION Get BE EF 03 06 00 0D 83 02 00 00 21 00 00

Increment BE EF 03 06 00 6B 83 04 00 00 21 00 00

Decrement BE EF 03 06 00 BA 82 05 00 00 21 00 00

V POSITION Reset Execute BE EF 03 06 00 E0 D2 06 00 02 70 00 00

H POSITION Get BE EF 03 06 00 F1 82 02 00 01 21 00 00

Increment BE EF 03 06 00 97 82 04 00 01 21 00 00

Decrement BE EF 03 06 00 46 83 05 00 01 21 00 00

H POSITION Reset Execute BE EF 03 06 00 1C D3 06 00 03 70 00 00

H PHASE Get BE EF 03 06 00 49 83 02 00 03 21 00 00

Increment BE EF 03 06 00 2F 83 04 00 03 21 00 00

Decrement BE EF 03 06 00 FE 82 05 00 03 21 00 00

H SIZE Get BE EF 03 06 00 B5 82 02 00 02 21 00 00

Increment BE EF 03 06 00 D3 82 04 00 02 21 00 00

Decrement BE EF 03 06 00 02 83 05 00 02 21 00 00

H SIZE Reset Execute BE EF 03 06 00 68 D2 06 00 04 70 00 00

AUTOADJUST Execute BE EF 03 06 00 91 D0 06 00 0A 20 00 00

COLOR SPACE Set AUTO BE EF 03 06 00 0E 72 01 00 04 22 00 00

RGB BE EF 03 06 00 9E 73 01 00 04 22 01 00

SMPTE240 BE EF 03 06 00 6E 73 01 00 04 22 02 00

REC709 BE EF 03 06 00 FE 72 01 00 04 22 03 00

REC601 BE EF 03 06 00 CE 70 01 00 04 22 04 00

Get BE EF 03 06 00 3D 72 02 00 04 22 00 00

COMPONENT Set COMPONENT BE EF 03 06 00 4A D7 01 00 17 20 00 00

SCARTRGB BE EF 03 06 00 DA D6 01 00 17 20 01 00

Get BE EF 03 06 00 79 D7 02 00 17 20 00 00

C-VIDEO FORMAT Set AUTO BE EF 03 06 00 A2 70 01 00 11 22 0A 00

NTSC BE EF 03 06 00 C2 74 01 00 11 22 04 00

PAL BE EF 03 06 00 52 75 01 00 11 22 05 00

SECAM BE EF 03 06 00 52 70 01 00 11 22 09 00

NTSC4.43 BE EF 03 06 00 62 77 01 00 11 22 02 00

M-PAL BE EF 03 06 00 C2 71 01 00 11 22 08 00

N-PAL BE EF 03 06 00 32 74 01 00 11 22 07 00

Get BE EF 03 06 00 31 76 02 00 11 22 00 00

S-VIDEO FORMAT Set AUTO BE EF 03 06 00 E6 70 01 00 12 22 0A 00

NTSC BE EF 03 06 00 86 74 01 00 12 22 04 00

PAL BE EF 03 06 00 16 75 01 00 12 22 05 00

SECAM BE EF 03 06 00 16 70 01 00 12 22 09 00

NTSC4.43 BE EF 03 06 00 26 77 01 00 12 22 02 00

M-PAL BE EF 03 06 00 86 71 01 00 12 22 08 00

N-PAL BE EF 03 06 00 76 74 01 00 12 22 07 00

Get BE EF 03 06 00 75 76 02 00 12 22 00 00

RS-232C Communication (continued)

Names Operation Type Header Command Data

CRC Action Type Setting Code

FRAME LOCK Set TURN OFF BE EF 03 06 00 CB D6 01 00 14 30 00 00

TURN ON BE EF 03 06 00 5B D7 01 00 14 30 01 00

Get BE EF 03 06 00 F8 D6 02 00 14 30 00 00

RGB1 IN-1 Set SYNC ON G OFF BE EF 03 06 00 5E D7 01 00 10 20 02 00

SYNC ON G ON BE EF 03 06 00 CE D6 01 00 10 20 03 00

Get BE EF 03 06 00 0D D6 02 00 10 20 00 00

RGB IN-2 Set SYNC ON G OFF BE EF 03 06 00 A2 D6 01 00 11 20 02 00

SYNC ON G ON BE EF 03 06 00 32 D7 01 00 11 20 03 00

Get BE EF 03 06 00 F1 D7 02 00 11 20 00 00

KEYSTONE V Get BE EF 03 06 00 B9 D3 02 00 07 20 00 00

Increment BE EF 03 06 00 DF D3 04 00 07 20 00 00

Decrement BE EF 03 06 00 0E D2 05 00 07 20 00 00

KEYSTONE VReset Execute BE EF 03 06 00 08 D0 06 00 0C 70 00 00

WHISPER Set NORMAL BE EF 03 06 00 3B 23 01 00 00 33 00 00

WHISPER BE EF 03 06 00 AB 22 01 00 00 33 01 00

Get BE EF 03 06 00 08 23 02 00 00 33 00 00

MIRROR Set NORMAL BE EF 03 06 00 C7 D2 01 00 01 30 00 00

H:INVERT BE EF 03 06 00 57 D3 01 00 01 30 01 00

V:INVERT BE EF 03 06 00 A7 D3 01 00 01 30 02 00

H&V:INVERT BE EF 03 06 00 37 D2 01 00 01 30 03 00

Get BE EF 03 06 00 F4 D2 02 00 01 30 00 00

AUDIO - RGB1 Set TURN OFF BE EF 03 06 00 FE DD 01 00 30 20 00 00

Audio1 BE EF 03 06 00 6E DC 01 00 30 20 01 00

Audio2 BE EF 03 06 00 9E DC 01 00 30 20 02 00

Audio3 BE EF 03 06 00 0E DD 01 00 30 20 03 00

Get BE EF 03 06 00 CD DD 02 00 30 20 00 00

AUDIO - RGB2 Set TURN OFF BE EF 03 06 00 CE DC 01 00 34 20 00 00

Audio1 BE EF 03 06 00 5E DD 01 00 34 20 01 00

Audio2 BE EF 03 06 00 AE DD 01 00 34 20 02 00

Audio3 BE EF 03 06 00 3E DC 01 00 34 20 03 00

Get BE EF 03 06 00 FD DC 02 00 34 20 00 00

AUDIO - Video Set TURN OFF BE EF 03 06 00 02 DC 01 00 31 20 00 00

Audio1 BE EF 03 06 00 92 DD 01 00 31 20 01 00

Audio2 BE EF 03 06 00 62 DD 01 00 31 20 02 00

Audio3 BE EF 03 06 00 F2 DC 01 00 31 20 03 00

Get BE EF 03 06 00 31 DC 02 00 31 20 00 00

AUDIO - S-Video Set TURN OFF BE EF 03 06 00 46 DC 01 00 32 20 00 00

Audio1 BE EF 03 06 00 D6 DD 01 00 32 20 01 00

Audio2 BE EF 03 06 00 26 DD 01 00 32 20 02 00

Audio3 BE EF 03 06 00 B6 DC 01 00 32 20 03 00

Get BE EF 03 06 00 75 DC 02 00 32 20 00 00

AUDIO - Component Set TURN OFF BE EF 03 06 00 32 DD 01 00 35 20 00 00

Audio1 BE EF 03 06 00 A2 DC 01 00 35 20 01 00

Audio2 BE EF 03 06 00 52 DC 01 00 35 20 02 00

Audio3 BE EF 03 06 00 C2 DD 01 00 35 20 03 00

Get BE EF 03 06 00 01 DD 02 00 35 20 00 00

RS-232C Communication (continued)

Names Operation Type Header Command Data

CRC Action Type Setting Code

MUTE Set TURN OFF BE EF 03 06 00 46 D3 01 00 02 20 00 00

TURN ON BE EF 03 06 00 D6 D2 01 00 02 20 01 00

Get BE EF 03 06 00 75 D3 02 00 02 20 00 00

LANGUAGE Set ENGLISH BE EF 03 06 00 F7 D3 01 00 05 30 00 00

FRANÇAIS BE EF 03 06 00 67 D2 01 00 05 30 01 00

DEUTSCH BE EF 03 06 00 97 D2 01 00 05 30 02 00

ESPAÑOL BE EF 03 06 00 07 D3 01 00 05 30 03 00

ITALIANO BE EF 03 06 00 37 D1 01 00 05 30 04 00

NORSK BE EF 03 06 00 A7 D0 01 00 05 30 05 00

NEDERLANDS BE EF 03 06 00 57 D0 01 00 05 30 06 00

PORTUGUÊS BE EF 03 06 00 C7 D1 01 00 05 30 07 00

BE EF 03 06 00 37 D4 01 00 05 30 08 00

BE EF 03 06 00 A7 D5 01 00 05 30 09 00

BE EF 03 06 00 37 DE 01 00 05 30 10 00

BE EF 03 06 00 57 D5 01 00 05 30 0A 00

SVENSKA BE EF 03 06 00 C7 D4 01 00 05 30 0B 00

PУCCKИЙ BE EF 03 06 00 F7 D6 01 00 05 30 0C 00

SUOMI BE EF 03 06 00 67 D7 01 00 05 30 0D 00

POLSKI BE EF 03 06 00 97 D7 01 00 05 30 0E 00

TÜRKÇE BE EF 03 06 00 07 D6 01 00 05 30 0F 00

Get BE EF 03 06 00 C4 D3 02 00 05 30 00 00

MENU POSITION H Get BE EF 03 06 00 04 D7 02 00 15 30 00 00

Increment BE EF 03 06 00 62 D7 04 00 15 30 00 00

Decrement BE EF 03 06 00 B3 D6 05 00 15 30 00 00

MENU POSITION H

Reset Execute BE EF 03 06 00 DC C6 06 00 43 70 00 00

MENU POSITION V Get BE EF 03 06 00 40 D7 02 00 16 30 00 00

Increment BE EF 03 06 00 26 D7 04 00 16 30 00 00

Decrement BE EF 03 06 00 F7 D6 05 00 16 30 00 00

MENU POSITION V

Reset Execute BE EF 03 06 00 A8 C7 06 00 44 70 00 00

RS-232C Communication (continued)

Names Operation Type Header Command Data

CRC Action Type Setting Code

BLANK Set My Screen BE EF 03 06 00 FB CA 01 00 00 30 20 00

ORIGINAL BE EF 03 06 00 FB E2 01 00 00 30 40 00

BLUE BE EF 03 06 00 CB D3 01 00 00 30 03 00

WHITE BE EF 03 06 00 6B D0 01 00 00 30 05 00

BLACK BE EF 03 06 00 9B D0 01 00 00 30 06 00

Get BE EF 03 06 00 08 D3 02 00 00 30 00 00

BLANK On/Off Set TURN OFF BE EF 03 06 00 FB D8 01 00 20 30 00 00

TURN ON BE EF 03 06 00 6B D9 01 00 20 30 01 00

Get BE EF 03 06 00 C8 D8 02 00 20 30 00 00

START UP Set My Screen BE EF 03 06 00 CB CB 01 00 04 30 20 00

ORIGINAL BE EF 03 06 00 0B D2 01 00 04 30 00 00

TURN OFF BE EF 03 06 00 9B D3 01 00 04 30 01 00

Get BE EF 03 06 00 38 D2 02 00 04 30 00 00

My Screen LOCK Set TURN OFF BE EF 03 06 00 3B EF 01 00 C0 30 00 00

TURN ON BE EF 03 06 00 AB EE 01 00 C0 30 01 00

Get BE EF 03 06 00 08 EF 02 00 C0 30 00 00

MESSAGE Set TURN OFF BE EF 03 06 00 8F D6 01 00 17 30 00 00

TURN ON BE EF 03 06 00 1F D7 01 00 17 30 01 00

Get BE EF 03 06 00 BC D6 02 00 17 30 00 00

AUTO SEARCH Set TURN OFF BE EF 03 06 00 B6 D6 01 00 16 20 00 00

TURN ON BE EF 03 06 00 26 D7 01 00 16 20 01 00

Get BE EF 03 06 00 85 D6 02 00 16 20 00 00

AUTO ON Set TURN OFF BE EF 03 06 00 3B 89 01 00 20 31 00 00

TURN ON BE EF 03 06 00 AB 88 01 00 20 31 01 00

Get BE EF 03 06 00 08 89 02 00 20 31 00 00

AUTO KEYSTONE

EXECUTE Execute BE EF 03 06 00 E5 D1 06 00 0D 20 00 00

AUTO KEYSTONE Set TURN OFF BE EF 03 06 00 EAD1 01 00 0F 20 00 00

TURN ON BE EF 03 06 00 7AD0 01 00 0F 20 01 00

Get BE EF 03 06 00 D9 D1 02 00 0F 20 00 00

AUTO OFF Get BE EF 03 06 00 08 86 02 00 10 31 00 00

Increment BE EF 03 06 00 6E 86 04 00 10 31 00 00

Decrement BE EF 03 06 00 BF 87 05 00 10 31 00 00

LAMPTIME Get BE EF 03 06 00 C2 FF 02 00 90 10 00 00

LAMPTIME Reset Execute BE EF 03 06 00 58 DC 06 00 30 70 00 00

FILTER TIME Get BE EF 03 06 00 C2 F0 02 00 A0 10 00 00

FILER TIMEReset Execute BE EF 03 06 00 98 C6 06 00 40 70 00 00

MAGNIFY Get BE EF 03 06 00 7C D2 02 00 07 30 00 00

Increment BE EF 03 06 00 1A D2 04 00 07 30 00 00

Decrement BE EF 03 06 00 CB D3 05 00 07 30 00 00

FREEZE Set NORMAL BE EF 03 06 00 83 D2 01 00 02 30 00 00

FREEZE BE EF 03 06 00 13 D3 01 00 02 30 01 00

Get BE EF 03 06 00 B0 D2 02 00 02 30 00 00

RS-232C Communication (continued)

Names Operation Type Header Command Data

CRC Action Type Setting Code

REMOTE FREQ

NORMAL Set Disable BE EF 03 06 00 FF 3D 01 00 30 26 00 00

Enable BE EF 03 06 00 6F 3C 01 00 30 26 01 00

Get BE EF 03 06 00 CC 3D 02 00 30 26 00 00

REMOTE FREQ HIGH Set Disable BE EF 03 06 00 03 3C 01 00 31 26 00 00

Enable BE EF 03 06 00 93 3D 01 00 31 26 01 00

Get BE EF 03 06 00 30 3C 02 00 31 26 00 00

MY BUTTON-1 Set RGB1 BE EF 03 06 00 3A33 01 00 00 36 00 00

RGB2 BE EF 03 06 00 FA31 01 00 00 36 04 00

COMPONENT BE EF 03 06 00 6A 30 01 00 00 36 05 00

S-VIDEO BE EF 03 06 00 5A32 01 00 00 36 02 00

Video BE EF 03 06 00 AA32 01 00 00 36 01 00

INFORMATION BE EF 03 06 00 FA3E 01 00 00 36 10 00

AUTO KEYSTONE

EXECUTE BE EF 03 06 00 6A 3F 01 00 00 36 11 00

MY MEMORY BE EF 03 06 00 9A3F 01 00 00 36 12 00

PICTURE MODE BE EF 03 06 00 0A3E 01 00 00 36 13 00

FILTER RESET BE EF 03 06 00 3A 3C 01 00 00 36 14 00

Get BE EF 03 06 00 09 33 02 00 00 36 00 00

MY BUTTON-2 Set RGB1 BE EF 03 06 00 C6 32 01 00 01 36 00 00

RGB2 BE EF 03 06 00 06 30 01 00 01 36 04 00

COMPONENT BE EF 03 06 00 96 31 01 00 01 36 05 00

S-VIDEO BE EF 03 06 00 A6 33 01 00 01 36 02 00

Video BE EF 03 06 00 56 33 01 00 01 36 01 00

INFORMATION BE EF 03 06 00 06 3F 01 00 01 36 10 00

AUTO KEYSTONE

EXECUTE BE EF 03 06 00 96 3E 01 00 01 36 11 00

MY MEMORY BE EF 03 06 00 66 3E 01 00 01 36 12 00

PICTURE MODE BE EF 03 06 00 F6 3F 01 00 01 36 13 00

FILTER RESET BE EF 03 06 00 C6 3D 01 00 01 36 14 00

Get BE EF 03 06 00 F5 32 02 00 01 36 00 00

VOLUME-RGB1 Get BE EF 03 06 00 CD CC 02 00 60 20 00 00

Increment BE EF 03 06 00 AB CC 04 00 60 20 00 00

Decrement BE EF 03 06 00 7A CD 05 00 60 20 00 00

VOLUME-RGB2 Get BE EF 03 06 00 FD CD 02 00 64 20 00 00

Increment BE EF 03 06 00 9B CD 04 00 64 20 00 00

Decrement BE EF 03 06 00 4A CC 05 00 64 20 00 00

VOLUME-Video Get BE EF 03 06 00 31 CD 02 00 61 20 00 00

Increment BE EF 03 06 00 57 CD 04 00 61 20 00 00

Decrement BE EF 03 06 00 86 CC 05 00 61 20 00 00

VOLUME-S-Video Get BE EF 03 06 00 75 CD 02 00 62 20 00 00

Increment BE EF 03 06 00 13 CD 04 00 62 20 00 00

Decrement BE EF 03 06 00 C2 CC 05 00 62 20 00 00

VOLUME-Component Get BE EF 03 06 00 01 CC 02 00 65 20 00 00

Increment BE EF 03 06 00 67 CC 04 00 65 20 00 00

Decrement BE EF 03 06 00 B6 CD 05 00 65 20 00 00

RS-232C Communication (continued)

Autres manuels pour ImagePro 8755E

Table des matières

Autres manuels Dukane Projecteur

Dukane

Dukane ImagePro 8956H-RJ Manuel d'installation et d'exploitation

Dukane

Dukane ImagePro 8038 Manuel utilisateur

Dukane

Dukane ImagePro 8755A Manuel utilisateur

Dukane

Dukane ImagePro 8776-W Manuel utilisateur

Dukane

Dukane 8793H Manuel utilisateur

Dukane

Dukane ImagePro 8925H-RJ Manuel utilisateur

Dukane

Dukane 7707 Series Manuel utilisateur

Dukane

Dukane 8755G-RJ Manuel utilisateur

Dukane

Dukane 8788 Manuel utilisateur

Dukane

Dukane 28A680 Instructions de construction

Dukane

Dukane ImagePro 8947 Manuel utilisateur

Dukane

Dukane ImagePro 8053 Manuel utilisateur

Dukane

Dukane ImagePro 8760 Manuel utilisateur

Dukane

Dukane 8928B Manuel utilisateur

Dukane

Dukane Starfire SF3010 Manuel utilisateur

Dukane

Dukane 8970 Manuel utilisateur

Dukane

Dukane 6528 Manuel utilisateur

Dukane

Dukane ImagePro 8776 Manuel du propriétaire

Dukane

Dukane ImagePro 8927HW-RJ Manuel d'installation et d'exploitation

Dukane

Dukane 8755N Manuel utilisateur

Dukane

Dukane 6542W Manuel utilisateur

Dukane

Dukane ImagePro 8762 Document technique

Dukane

Dukane ImagePro 8766 Manuel utilisateur

Dukane

Dukane 8412 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
