Instruction manual
Ranos dB 1 / Ranos dB 2
For firmware version 3.2.0 or higher
Thank you for choosing Dutch Sensor Systems. Please
read the manual thoroughly before bringing this device
into service. If the device was damaged in transit,
do not install or use it and contact your dealer.
To all residents of the European
Union Important environmental
information about this product
This symbol on the device or the
package indicates that disposal of
the device after its lifecycle could
harm the environment. Do not
dispose of the unit (or batteries) as
unsorted municipal waste; it should
be taken to a specialized company
for recycling. This device should be
returned to your distributor or to a
local recycling service. Respect the
local environmental rules.
If in doubt, contact your local
waste disposal authorities.
Page 2 of 56
Table of contents
4Safety Instructions
5General Guidelines
6Precautions
7About this manual
8Marking
10 Specications
18 General description
21 Parts and functions
22 Description of measurement quantities
23 Power
28 Parts and accessories
30 Optional parts and accessories
34 Mounting options and measurement accuracy
35 Acoustic calibration using sound calibrator
37 Connect App: software installation
and connection via USB
39 Connect App: working principles
41 Connect App: “Ranos settings” page
47 Connect App: “Ranos live” page
53 Connect App: “Ranos info” page
54 Connect App: “Ranos calibration” page
55 Dimensions in mm
Page 3 of 56
This device is not suited for children under
the age of 16, and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning the use of the device
in a safe way and understand the hazards involved.
Children shall not play with the device. Cleaning
and user maintenance shall not be made by
children without supervision.
Batteries are electrochemically live at all times.
Do not short circuit the battery terminals. Inspect
the battery consignment for signs of transport
damage. Ensure the consignment has all items
listed on the delivery note or invoice, i.e. batteries,
cables, shrouds etc. While unpacking each battery,
take care not to drop anything on the terminals.
Inspect each battery for physical damage such
as cracks or distortion of the case and terminals.
Safety Instructions
!
-+
Page 4 of 56
•
Familiarise yourself with
the functions of the device
before actually using it.
•
Allmodicationsofthe
device are forbidden for safety
reasons. Damage caused by user
modicationstothedeviceisnot
covered by the warranty.
•
Only use the device for its intended
purpose. Using the device in an
unauthorised way will void the
warranty.
•
Damage caused by disregard of
certain guidelines in this manual
is not covered by the warranty and
the dealer will not accept respon-
sibility for any ensuing defects
or problems.
General Guidelines
•
Neither Dutch Sensor Systems
B.V. nor its dealers can be held
responsible for any damage (extra-
ordinary, incidental or indirect) –
ofanynature(nancial,physical...)
arising from the possession,
use or failure of this product.
•
Due to constant product
improvements, the actual product
appearancemightdierfromthe
shown images.
•
Product images are for
illustrative purposes only.
•
Keep this manual for future
reference.
Page 5 of 56
•
Do not use screws of any other type
or length from what is supplied.
•
Install all rubber caps or connectors
during outdoor use. All parts are
rated IP67 or better, but only when
mated to a connector or cap.
•
TurnotheRanosdBbefore
storage.
•
When storing the Ranos dB for a
longer period of time, make sure
the battery is fully charged and
check the battery charge once
every month.
•
When disconnecting cables,
always grasp the plug and
do not pull the cable.
Precautions
•
When transporting the Ranos dB,
especially with the battery
installed, use an appropriate
case or packaging.
•
Do not clean the Ranos dB
using solvents or chemicals.
•
Take care that no electrically
conductive objects are left inside
of the Ranos dB.
•
Dispose of the unit and of batteries
only according to national and local
regulations at the place of use.
Page 6 of 56
•
The instructions in this manual
apply to the Dutch Sensor Systems
Ranos dB 1 and Ranos dB sound
levelmeterswithrmware3.2.0
or higher.
•
The user manual, calibration
manuals and additional
information can be downloaded
from the support section at:
iotsoundsensor.com
About this manual
Page 7 of 56
Marking
Examples of CE Marking - Ranos dB
Model RanosdB1-V3.0.3
Serial no 123456
Applicable standard AccuracyaccordingtoIEC61672-1:2014en,performanceclass1
Power rating 5VDC,60mAmax.
IP rating IP67
Frequency range LoRa863-870MHzGNSS1571-1606MHz
Manufacturer Dutch Sensor Systems B.V. - Antennestraat 66, Almere, NL
Model RanosdB-V3.0.3
Serial no 123456
Applicable standard AccuracyaccordingtoIEC61672-1:2014en,performanceclass2
Power rating 5VDC,60mAmax.
IP rating IP67
Frequency range LoRa863-870MHzGNSS1571-1606MHz
Manufacturer Dutch Sensor Systems B.V. - Antennestraat 66, Almere, NL
Page 8 of 56
Model RanosdB1-V3.0.3
Serial no 123456
Applicable standard AccuracyaccordingtoIEC61672-1:2014en,performanceclass1
Power rating 5VDC,60mAmax.
IP rating IP67
Frequency range LoRa902-928MHzGNSS1571-1606MHz
Manufacturer Dutch Sensor Systems B.V. - Antennestraat 66, Almere, NL
Model RanosdB-V3.0.3
Serial no 123456
Applicable standard AccuracyaccordingtoIEC61672-1:2014en,performanceclass2
Power rating 5VDC,60mAmax.
IP rating IP67
Frequency range LoRa902-928MHzGNSS1571-1606MHz
Manufacturer Dutch Sensor Systems B.V. - Antennestraat 66, Almere, NL
Page 9 of 56
The highlights of the Ranos dB
•
Two models are available, the
RanosdB1andtheRanosdB2.
TheRanosdB1meetsIEC61672-
1:2014Class1specicationsand
theRanosdB2meetsIEC61672-
1:2014Class2specications.
•
Equipped with a solar panel,
has LoRa connectivity and
works100%autonomously.
•
Lightweight housing
waterproof.
•
GPS on board.
•
Easy to operate from
any cloud platform.
•
Data visualization via DSS
Dashboard+ that seamlessly
integrates with the Ranos dB.
•
Dynamicrangeof40-120dB(A)
andaDSPsamplerateof48kHz.
•
Detachable microphone that
can be mounted at any desired
location.
•
LoRa network settings by the
DSS Connect App (Android).
General description
Discover the Ranos dB
Page 10 of 56
