JL- HARNESS

USER MANUAL

JL-HARNESS

Thank you for choosing the DS18 JL-HARNESS for your factory radio.

This harness installation kit will allow you to add an amplifier under the

passenger seat for the DS18 JL-SBAR and also amplify the dashboard

speakers (optional), it also comes ready for the LED-BTC lights module and

the audio signal module V4HL.V2.

WHAT IS INCLUDED:

• Harness kit OFC with all factory style connectors and terminals

• Fuse Holder Mini-ANL 150A

WHAT YOU WILL NEED:

• Any 4, 5 or 6 channels amplifier

• DS18 Smart Line Output Conversion Module (V4HL.V2).

• LED RGB Control module (LED-BTC).

• Soundbar for Jeep JL / JLU / JT (JL-SBAR).

• 4 x 8” Speakers (NXL-8 recommended).

• 4 x 1.75” Tweeters (PRO-TW4L recommended).

• Optional DS18 Dash enclosure upgrade with 6” Neo Mid-Range (JP6).

• Optional DS18 Dash Tweeter upgrade using PRO-TWR3 ring adapter

and PRO-TWN4 or similar.

**ATTENTION**

Installation of mobile audio and video components requires experience with

a variety of mechanical and electrical procedures. Although this manual

provides general installation and operation instructions, it does not show the

exact installation methods for your vehicle. If you do not have the required

knowledge and experience to successfully complete the installation, consult

an authorized dealer about professional installation service.

Please visit DS18.tools for a full installation video

Specially designed for Jeep:

JEEP JL/JLU/jt SoundBar

Wiring Harness Kit - Installation

Radio side Installation

using Factory OEM Radio (Without PREMIUM/ALPINE Sound System)

A - Connect the DS18 T-Harness

connector between the factory

radio unit and the radio harness.

SOUNDBAR

PIN CONNECTOR

HI/LO V4HL.V2LED-BTC

AMP

JEEP RADIO

FUSE HOLDER

BATTERY

FACTORY RADIO

HARNESS

DS18 T-HARNESS

RADIO

FACTORY

RADIO

DS18 HARNESS (RADIO SIDE)

SPEAKER /

SIGNAL CONNECTOR D

**ATTENTION** Disconnect the negative post (Ground) of the battery before you

start the installation. This helps avoid airbags coding and malfunctions, codes

module malfunction or any electrical issues

Ampliﬁer Side Installation

6 CHANNEL AMPLIFIER (Sold separately)

APP ON/OFF

(SWITCH)

CONSTANT

ACC/REMOTE ON

TO LED BTC

JL-HARNESS

LED-BTC

(Sold separately)

V4HL.V2

(Sold separately)

A. RGB Wire: connect this RGB wire to the LED-BTC module matching the

color wires as described in the picture (Red: Red, Yellow: Green, White: Blue,

Black: Black).

B. Black Wire: Negative (ground) to the LED-BTC module.

C. Blue Wire: this is the signal to turn on the LED-BTC module, connect this to

the Red (acc) wire of the module.

D. Red Wire: this is the constant +12v from the battery to the LED-BTC

module, connect this to the Yellow wire of the module.

1 - "Front” amplifier audio signal connector: connect this using the supplied

RCA connector and connect this to the amplifier CH1 and Ch2 RCA input.

(Using front speaker upgrade)

“Rear” Amplifier Audio Signal Connector: connect this using the supplied

RCA connector and connect this using “Y” RCA splinter to the amplifier CH3

to CH6 RCA input. (Using a 6CH amplifier with front speaker upgrade)

2 - Speaker harness: Connect the Front Speaker Harness to the “Front”

output amplifier channels: White: CH1(+), White/Black: CH1(-), Gray:

CH2(+), Gray/Black: CH2(-) and Connect the Soundbar speaker harness to

the channels 3 to 6 of the amplifier: White: CH3(+), White/Black: CH3(-),

Gray: CH4(+), Gray/Black: CH4(-), Green: CH5(+), Green/Black: CH5(-),

Violet: CH6(+), Violet/Black: CH6(-).

3 - Amplifier Power wires, Red: Positive from the battery, Black: Negative

Ground, Blue: Remote turn-on.

4 - Smart Line Output Conversion Module: this is a Plug and Play connector

using this module (V4HL.V2). This module converts the speaker signal from

the factory radio to a low-level audio signal for the amplifier, this also has a

speaker emulator that enables the signal output of the factory amplifier and

provides the Remote turn-on for the amplifier and LED Module.

Ampliﬁer Side Installation

**ATTENTION** Disconnect the negative post (Ground) of the battery before you

start the installation. This helps avoid airbags coding and malfunctions, codes

module malfunction or any electrical issues

FACTORY RADIO

HARNESS

DS18

T-HARNESS

RADIO

FACTORY

RADIO

DS18 HARNESS

(RADIO SIDE)

SPEAKER /

SIGNAL CONNECTOR

FROM RADIO SIDE

WHITE

WHITE / BLACK

GRAY

GRAY / BLACK

WHITE

WHITE / BLACK

GRAY

GRAY / BLACK

HARNESS SIDE

NOTE: If you use 4 or 5 Channels

amplifier without upgrading the

front speaker you will need to

bypass the “Front” signal. Use only

the “Rear” signal to JL-SBAR or

subwoofer channels.

Cut the wires: White CH1(+),

White /Black CH1(-), Gray CH2(+)

and Gray/Black CH2(-) from each

Harness side speaker/signal

connector and connect each same

color together using crimp wire

connectors:

SoundBar Side

1 2

RGB BADGE

SPEAKERS

TWEETERS

RGB WIRE

CONNECTOR

SPEAKERS, RINGS

TWEETERS, RGB LIGHTS

JL-HARNESS

Soundbar Side

A - Sound Bar Connector: this goes outside the soundbar and allows us to

connect and disconnect it for any service, speaker replacement or

facilitate the installation.

B - RGB LED light wire: connect this to each RGB LED lightings such

as speakers, rings, grills, tweeters, and DS18 Badge used for the

Soundbar.

Black: +12V, Red: Red color (-), Green: Green color (-), Blue:

Blue color (-).

C - Speaker Wires: connect these wires to each speaker in the soundbar

like this:

Speaker 1 and Tweeter 1 connected in parallel to the wire: White: (+),

White/Black: (-)

Speaker 2 and Tweeter 2 connected in parallel to the wire: Green: (+),

Green/Black: (-)

Speaker 3 and Tweeter 3 connected in parallel to the wire: Gray: (+),

Gray/Black: (-)

Speaker 4 and Tweeter 4 connected in parallel to the wire: Violet: (+),

Violet/Black: (-)

*Always use the bass blocker (filter) on each tweeter to avoid burning it.

FINAL STEP

1. Run the positive power wire to the front battery under the hood, you can

use the existent drain caps on the floor in the seat area to pass through

the wire and route it to the battery

2. Secure the wire use zip-ties to the chassis or factory harness nearby and

keep it far away from the header / exhaust.

3. Connect it on the Positive (+) terminal of the battery and secure the fuse

holder in an accessible area using screws or zip-ties.

4. Once all is connected, put back the seat and make sure all connectors

are plugged-in so you can re-connect the negative post (Ground) of

the battery.

5. Turn on the Radio and check sound making sure that all speakers are

playing, then adjust the amplifier’s gain and crossover point to your

preference.

6. Enjoy your new DS18 JL-HARNESS.

FOR MORE INFORMATION

PLEASE VISIT

DS18.COM

We LIKE IT LOUD
