INFRARED THERMOMETER
DH-IF-THERMO
Description
The Dromex® infrared hand held thermometer is light weight and designed to
scan the forehead individuals for the monitoring and detection of elevated body
temperatures, without direct personal contact. This thermometer also measures
the temperature of objects.
The Dromex thermometer features the following:
• An automatic high temperature warning alarm, which sirens when
measurements are above 38˚C.
• High sensor quality which gives a temperature result in ONE second.
• An LED luminous display function, suitable for measuring at night (also
prevents disturbance for babies).
• One key operation.
• Has a large memory capacity that stores up to 32 measurements, ideal for
monitoring of children and sick patients.
This scanner is suitable for use when conducting temperature checks used by
hospitals, offices, airports, at home and mobile screenings.
Special Instructions
• Always read instructions before use.
• Always use a clinical thermometer when high accuracy body temperature
measurements are required.
• Always use a clinical thermometer to verify any abnormal temperature
measurements.
• For the most accurate results, readings should be conducted at ambient
room temperature of 10 to 40˚C (50 to 140˚F). If the surrounding
temperature is lower than 10˚C or higher than 40˚C, measurement accuracy
is not assured.
• Make sure the skin is dry and that no hair interferes with the measurement.
• Do not immerse the thermometer in water.
• Avoid touching and/or scratching the infrared sensor lens.
• Clean the lens area by gently blowing with compressed air and use a damp
swab to wipe the lens. Do not use any solvents to clean the lens.
• Actual conditions of use cannot be directly simulated in a test environment
therefore it is the responsibility of the end user and not the manufacturer or
supplier to determine the scanners suitability for the intended use.
Instructions for use
Measurements Notes
• If the thermometer has been stored in a cold or hot environment, allow at
least 30 minutes for the unit to acclimate to room temperature before taking
measurements.
• To prevent transmission of disease, avoid direct contact with the skin.
• After heavy exercise always wait at least 10 minutes before taking forehead
temperature readings.
•Temperature Mode settings
• With the meter ON, press“Mode”button for three seconds until to “F-1”
shown to enter the long term calibration drift correction mode. On entering
the mode, the previous temperature correction factor will appear on the
display. To make a correction, measure a known, fixed temperature source.
Enter the correction mode and press the + or - buttons to change the
correction value and minimize the difference in readings. Repeat and adjust
the correction value as needed until the measurement on the meter
matches the known temperature. The mode is applied to Body Temp.
• Press the“Mode”button a second time “F-2”shown to set the alarm
temperature limit. Press the + or - buttons to change the value.
The mode is applied to Body Temp.
• Press the“Mode”button a third time “F-3” shown to set the °C/°F temperature
units. The temperature units °C or °F will be shown. Press the + or - buttons
to change the unit.
• Press the“Mode”button a forth time “F-4” shown to set the backlit status.
Press the + or - buttons to switch from ON to OFF.
• Press the“Mode”button a fifth time “F-5” shown to set the laser status.
Press the + or - buttons to switch from ON to OFF.
Notice: Only when the laser head installed.
DH-IF-THERMO
About 1 second later, when the beep
sounds, it indicates the body
temperature has been measured. The
result of the measurement is displayed
on the screen
(red, yellow, green).
Mode Function “+” “-” Default Remark
F-1
F-2
F-3
F-4
F-5
Save Save and automatic shut off
Setting Deviation
Value
Setting Alarm Value
Setting
Measurement Unit
Backlit ON/OFF
Laser setting
Increase
0.1°C
Decrease
0.1°C 0°C Body mode available
Effective Range: ±2°C
Body mode available
Effective Range: 37.0~42.5°C
Increase
0.1°C
Decrease
0.1°C 38.0°C
F°C °C °C
On OnOff
On OffOff Only when the
laser head installed
•Body Temperature Measurement
Please note that the forehead/temples must be free from sweat and
cosmetics and that taking vasoconstrictive medication and skin irritations
can distort the result when measuring temperature on the forehead.
• Press the trigger to switch the thermometer on with one beeper. The device
performs a brief self test: all elements of the display are shown for approx.
1 second. Following a successful self test with backlit (Red-Orange-Green),
• Press the“B/O” button for“Body temp”for accurate measurements in the
range of 32.0 to 42.9°C (89.6 to 109.2°F).
• Hold the meter by its handle and point it toward the surface to be measured.
Measurement distance should be <2.5cm(<1 in ).
• Press the trigger to take a temperature reading. The temperature reading
appears in the display.
If the F-4 MODE of backlit & “ / ”button voice ON & F-3 MODE set alarm
temperature 38.0°C:
Temperature (°C)
T<32.0
32.0≤T≤37.5
37.6≤T≤37.9
38.0≤T≤42.9
T>42.9
Temperature (°F)
T<89.6
89.6≤T≤99.5
99.7≤T≤100.2
100.4≤T≤109.2
T>109.2
Fever Teller
Green
Green
Orange
Red
Red
Beep
Three beeps
One beep
One beep
Ten Rapid beebs
Three beeps
Notice: Red Backlit is followed alarm temperature limit (Fever alarm).
• Release the trigger and the reading will hold for approximately 15 seconds
after which thermometer will automatically shut off.
Note: Before shutting off, you can take further measurement.
• If the temperature goes above 109.2°F or 42.9°C,“Hi” will appear in the
display.
If the temperature goes below 89.6°F or 32.0°C,“Lo” will appear in the
display.
High fever
Red
backlight
Low fever
Yellow
backlight
Normal
Green
backlight
