Drift X3 Quick Guide
Thank you for purchasing the Drift X3, the Lightweight wearable
camera for hands-free video recording
CUSTOMER SUPPORT
Download the full manual and check our official website for firmware
updates, customer support, and info on all of our products.
https://driftinnovation.com/
If you have any suggestions, comments or concerns; please contact
our customer support team at:
WARRANTY
Warranty does not apply if the product is damaged due to physical
abuse, mishandling, accident, fire, frostbite, water damage, negligence
or failure to follow the supplied operating instructions. For more
information on warranty, see:
https://driftinnovation.com/warranty
2
Camera Specification
Video Conference Call 1080P@30
Video Recording 1080P@30FPS
720P@30FPS
Video Format MP4(H.264)
Photo JPEG
Field Of View 120° Wide Angle
Sensor type 4MP CMOS
Build-in Noise Reducing Microphone
Internal/External Speaker
Input Micro USB port, External Power
& Speaker through TRRS Audio Jet
Memory Micro SD, SDHC, SDXC, up to 128GB
Wi-Fi 2.4 & 5.8G
Bluetooth BT4.0
Weather Resistant
Weight 97g
3
Package Contents
1. Drift X3 2. Bluetooth Earbud 3. Micro USB Cable
4. Head Strap 5. User Manual
4
About Your Camera
Power & Mode button
Wi-Fi button
Record Button
Status LED
Wi-Fi LED
Battery LED
5 Pin Micro USB Port
Micro SD Card Slot
TRRS Audio Jet for
External Power & Speaker
Memory Card and USB Cover
A
B
C
D
E
F
G
H
I
J
H
D
J
G
C
I
E
F
A
B
5
Wearing Steps
1. Adjust head strip to the most comfortable size for yourself.
2. Wear the head strip on your head and make sure the Velcro
side facing forward.
3. Put your X3 camera on the head strip and make sure camera
attached to the Velcro solidly, the surface of button and micro
SD card slot should face to the ground
6
Initial Setup
Open the Memory Card/USB Cover.
1. Insert a Class 6 or higher microSD/HC/XC card (up to 128GB).
Format before first usage.
2. Connect the camera via a micro USB cable to a powered USB port,
charge the battery for 3 hours before first use.
3. Close the Memory card/USB cover and now you are ready to go!
2 3
1
4
7
Getting Started
Reset Your Camera
POWER ON/OFF
1. Press and hold the button to power on your X3.
2. Status LED is Green in color, indicating video mode.
3. The camera is now ready to record video or take photos.
4. To power off, press and hold the button for 3 seconds
If your camera becomes unresponsive, press and hold the button
for 20s to reset it.
MODE NAVIGATION
To change the current camera recording mode, press the
button to toggle between Video and Photo mode
VIDEO MODE
(Green LED) Press the button to start recording. The Status
8
Turn On/Off Wi-Fi
LED will flash red to indicate recording. Press the button again to
stop recording.
PHOTO MODE
(Yellow LED) The camera will capture still image when the
button is pressed, and the status LED will flash red once when a photo
is captured.
Press the button once to turn on Wi-Fi on your X3, press the [Wi-Fi]
button again to turn Wi-Fi off.
Wi Fi password is "1234567890" by default, you can modify it through
Drift Life App once connected.
Tip: In case you forgot the new password, press and hold the button and
then press the button to start the camera, Wi-Fi password will be reset to
default.
9
Camera Settings
Wi-Fi 2.4G/5.8G
Change Password xxxxxxxxxx
Field Of View 120°/90°
Exposure -2/-1/0/1/2
Bitrate High/Mid/Low
Filter Normal/Vivid/Low Light
ISO 100/200/400/800/Auto
Mic Sensitivity 0/1/2/3/4/5
Speaker Volume Off/Low/Mid/High
LED Status Indicator On/Off
Date 01/01/2021
Language English/Chinese
Restore Default On/Off
Format Micro SD On/Off
Serial Number XXXX
Firmware Version x.x.x.x
In order to setup your X3, install the Drift Life App on your mobile
phone and connect it with your X3 to access the following settings.
