Draytek Vigor2762n Manuel utilisateur

Vigor2762 Series

ADSL2/2+ & VDSL2 Router

Quick Start Guide

Version: 1.1

Firmware Version: V3.8.8

(For future update, please visit DrayTek web site)

Date: March 19, 2018

Intellectual Property Rights (IPR) Information

by copyright. No part may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language without written permission

from the copyright holders.

Trademarks The following trademarks are used in this document:

Microsoft is a registered trademark of Microsoft Corp.

Windows, Windows 95, 98, Me, NT, 2000, XP, Vista, 7, 8 and Explorer are

trademarks of Microsoft Corp.

Apple and Mac OS are registered trademarks of Apple Inc.

Other products may be trademarks or registered trademarks of their

respective manufacturers.

Safety Instructions and Approval

Safety

Instructions

Read the installation guide thoroughly before you set up the router.

The router is a complicated electronic unit that may be repaired only be

authorized and qualified personnel. Do not try to open or repair the

router yourself.

Do not place the router in a damp or humid place, e.g. a bathroom.

Do not stack the routers.

The router should be used in a sheltered area, within a temperature

range of 0 to +40 Celsius.

Do not expose the router to direct sunlight or other heat sources. The

housing and electronic components may be damaged by direct sunlight

or heat sources.

Do not deploy the cable for LAN connection outdoor to prevent

electronic shock hazards.

Keep the package out of reach of children.

When you want to dispose of the router, please follow local regulations

on conservation of the environment.

Warranty

We warrant to the original end user (purchaser) that the router will be free

from any defects in workmanship or materials for a period of two (2) years

from the date of purchase from the dealer. Please keep your purchase receipt

in a safe place as it serves as proof of date of purchase. During the warranty

period, and upon proof of purchase, should the product have indications of

failure due to faulty workmanship and/or materials, we will, at our discretion,

repair or replace the defective products or components, without charge for

either parts or labor, to whatever extent we deem necessary tore-store the

product to proper operating condition. Any replacement will consist of a new

or re-manufactured functionally equivalent product of equal value, and will

be offered solely at our discretion. This warranty will not apply if the product

is modified, misused, tampered with, damaged by an act of God, or subjected

to abnormal working conditions. The warranty does not cover the bundled or

licensed software of other vendors. Defects which do not significantly affect

the usability of the product will not be covered by the warranty. We reserve

the right to revise the manual and online documentation and to make changes

from time to time in the contents hereof without obligation to notify any

person of such revision or changes.

Declaration of Conformity

Hereby, DrayTek Corporation declares that the radio equipment type Vigor2762 is in compliance with

Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the following internet address:

http://www.draytek.com.tw/ftp/Vigor2762/Document/CE/

Manufacturer: DrayTek Corp.

Address: No. 26, Fu Shing Road, HuKou Township, HsinChu Industrial Park, Hsin-Chu County,

Taiwan 303

Product: Vigor2762 Series

Frequency Information for Europe area:

2.4G WLAN 2412MHz - 2472 MHz, max. TX power: 19.98dBm *1

5G WLAN 5180MHz - 5700 MHz, max. TX power: 27.00dBm *2

Requirements in AT/BE/BG/CZ/DZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/

CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/

UK/HR. 5150MHz~5350MHz is for indoor use only.

(*1: for 2.4G WLAN model; *2: for 5G WLAN model)

This product is designed for DSL, POTS and 2.4GHz /5GHz WLAN network throughout the EC region.

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) This device may accept any interference received, including interference that may cause

undesired operation.

RF Exposure Warning

This equipment must be installed and operated in accordance with provided instructions and the

antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20

iii

cm from all persons and must not be co-located or operating in conjunction with any other antenna or

transmitter. End-users and installers must be provided with antenna installation instructions and

transmitter operating conditions for satisfying RF exposure compliance.

Caution

Any changes or modifications not expressly approved by the grantee of this device could void the

user's authority to operate the equipment.

The antenna/transmitter should be kept at least 20 cm away from human body.

More update, please visit www.draytek.com.

1. Introduction........................................................................................................... 1

2. Package Content .................................................................................................. 2

3. Panel Explanation................................................................................................. 3

4. Hardware Installation ........................................................................................... 5

4.1 Network Connection................................................................................................................... 5

4.2 Wall-Mounted Installation........................................................................................................... 6

5. Software Configuration........................................................................................ 7

6. Customer Service............................................................................................... 12

Be a Registered Owner.................................................................................................................. 12

Firmware & Tools Updates............................................................................................................. 12

The Vigor2762 series are the routers with high speed in data transmission through

DSL port and LAN ports.

DrayTek launches Vigor2762 series – high speed router, perfectly complied with

VDSL2 environment including Vigor2762n (2.4GHz), Vigor2762ac (2.4GHz/5GHz)

and Vigor2762Vac (2.4GHz/5GHz with VoIP feature) for speed-wanted customers.

With high throughput performance and secured broadband connectivity provided

by Vigor2762 series, you can simultaneously engage these bandwidth-intensive

applications, such as high-definition video streaming, online gaming, and

Internet telephony / access.

Vigor2762 supports VPN tunnel(s) using advanced protocols such as IPSec/PPTP

(for remote dial-in only) with AES/3DES for encryption and MD5/SHA-1 for

authentication.

Through the central management for multiple access points, Vigor router can set

wireless profile in advance and apply to the access point managed easily and

conveniently.

In addition, Vigor2762 series supports two USB interfaces for connecting USB

printer to share the printer or USB storage device for sharing files and 3G/4G

backup services.

Take a look at the package content. If there is anything missed or damaged,

please contact DrayTek or dealer immediately.

Vigor router

Quick Start Guide

RJ-45 Cable (Ethernet)

RJ-11 to RJ-11 Cable (Annex A)

RJ-11 to RJ-45 Cable (Annex B)

RJ-45 to RJ-45 Cable (Annex B)

Antenna (for “n” or “ac” model)

The type of the power adapter depends on the country that the router will be

installed. * The maximum power consumption is 17-23 Watt.

UK-type Power Adapter

EU-type Power Adapter

USA/Taiwan-type Power Adapter

AU/NZ-type Power Adapter

LED Status Explanation

Blinking The router is powered on and running normally.

(Activity) Off The router is powered off.

On The phone connected to this port is off-hook.

Off The phone connected to this port is on-hook.

(for “V” model) Blinking A phone call comes.

On (Green)

The wireless access point is ready.

Blinking

(Green) The data is transmitting via wireless connection

based on the rate of 2.4GHz.

Blinking

(Orange) Blinks with one second cycle for two minutes.

The WPS function is active.

(Wireless LAN

On/Off/WPS)

Off The wireless access point is turned off.

On (Green)

The wireless access point is ready.

Blinking

(Green) The data is transmitting via wireless connection

based on the rate of 5GHz.

(Wireless LAN

On/Off/WPS) Blinking

(Orange) Blinks with one second cycle for two minutes.

The WPS function is active.

On A USB device is connected and active.

(USB) Blinking The data is transmitting.

On The DSL port is connected.

Blinking

(Slowly) The router is ready.

(DSL)

Blinking

(Quickly) The router is trying to connect to Internet.

On The LAN port is connected.

Blinking The data is transmitting.

~ Off The LAN port is disconnected.

(LAN1/2/3/4)

Interface Description

WLAN

ON/OFF/WPS WLAN On - Press the button and release it within 2 seconds. When

the wireless function is ready, the green LED will be on.

WLAN Off - Press the button and release it within 2 seconds to turn

off the WLAN function. When the wireless function is not ready, the

LED will be off.

WPS - When WPS function is enabled by web user interface, press

this button for morethan 2 seconds to wait for client’s device making

network connection through WPS.

Factory Reset Restore the default settings.

Usage: Turn on the router (ACT LED is blinking). Press the hole and

keep for more than 5 seconds. When you see the ACT LED begins to

blink rapidly than usual, release the button. Then the router will

restart with the factory default configuration.

USB1~USB2 Connector for a USB device (for 3G/4G USB Modem or printer).

GigaLAN1~LAN4 Connectors for local networked devices.

DSL Connector for accessing the Internet.

Phone2/Phone1

(for “V” model) Connector of analog phone for VoIP communication.

I / O Power Switch.

PWR Connector for a power adapter.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Draytek Routeur réseau

Draytek

Draytek Vigor 2620 Series Manuel utilisateur

Draytek

Draytek Vigor2920n Manuel utilisateur

Draytek

Draytek Vigor 2927 Series Manuel utilisateur

Draytek

Draytek VigorSwitch G1260 Manuel utilisateur

Draytek

Draytek Vigor 2750 Series Manuel utilisateur

Draytek

Draytek Vigor 2762 Series Manuel utilisateur

Draytek

Draytek Vigor 2700Ge/e Manuel utilisateur

Draytek

Draytek VigorBX 2000 Series Manuel utilisateur

Draytek

Draytek Vigor2762 series Manuel utilisateur

Draytek

Draytek Vigor2915 Series Manuel utilisateur

Draytek

Draytek VigorPro 5510 Series Manuel utilisateur

Draytek

Draytek Vigor3910 Series Manuel utilisateur

Draytek

Draytek Vigor2912 Series Manuel utilisateur

Draytek

Draytek Vigor 2925 Series Manuel utilisateur

Draytek

Draytek Vigor2926L Manuel utilisateur

Draytek

Draytek Vigor 2132 Series Manuel utilisateur

Draytek

Draytek VigorBX 2000 Series Manuel utilisateur

Draytek

Draytek Vigor 2700Ge/e Manuel utilisateur

Draytek

Draytek Vigor 3300 Series Manuel utilisateur

Draytek

Draytek Vigor2500 series Manuel utilisateur

Draytek

Draytek Vigor2766 Manuel utilisateur

Draytek

Draytek Vigor 2950 Manuel utilisateur

Draytek

Draytek Vigor2133 Vac Manuel utilisateur

Draytek

Draytek VigorPro 5500 Guide de référence

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
