Doro PhoneEasy 312ci Manuel utilisateur
PhoneEasy
312ci
English
Français
Español
Italiano
λληνικά
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
Telephone line socket
Handset hook
Keypad
Handset cord socket
Handset volume
Recall
Call memory / OK/ OK
Delete
Mains adapter socket
Ring volume
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Speed dial keys
Phone book
Ring melody
Ring tone
Speaker volume
Speakerphone
UP/DOWN
New call indicator
Ringer indicator
11.
12.
13.
14.
15.
16.
17.
18.
19.
English
1
2
3
4
5
6
7
8
19
18
17
16
15
14
13
9
10
11
12
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
1
English
Description
Doro PhoneEasy 312ci
Doro PhoneEasy 312ci can be used as a desktop or wall-mounted
telephone. Enhanced ring volume and visual call indication make
this telephone well suited for people with hearing difficulties.
The extra-large keypad and easy to read display with large
characters make the telephone easy to use even with impaired
eyesight.
The built-in phonebook can store up to 30 names and numbers.
Three one touch memory keys can be programmed for frequently
used numbers or emergency numbers. A call memory logs the 15
most recently incoming and outgoing calls.
A speakerphone function allows you to talk hands-free with the
simple press of a button.
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
2
English
Installation
Connection
Connect the curly cord to the handset and to socket marked
yon the telephone.
Connect the telephone line cord to a network wall socket and
to the Ksocket on the back of the telephone.
Lift the handset and listen for the dial tone.
Batteries
Four AA alkaline batteries are needed for the call memory and
speakerphone. When
BATT. LOW
is displayed, replace all 4
batteries. Use only AA alkaline batteries of good quality.
Note!
Before installing or changing the batteries, make sure that
the telephone is not connected to the telephone network.
Disconnect the telephone line cord.
Remove the battery cover.
Insert the batteries ensuring correct battery polarity is
observed.
Replace the battery cover and reconnect the telephone line
cord.
1.
2.
3.
1.
2.
3.
4.
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
3
English
Basic setup
Before using the telephone the first time, the following basic
settings should be made.
After confirming a setting, the next setting is automatically
displayed. The setup mode will automatically time out after
30 seconds of inactivity. You can exit setup mode anytime by
pressing .
Time and date
If the phone has not been setup, the display clock will show
00:00
when the batteries are installed.
Press and hold *for about 5 seconds until the hour flashes.
Use v / Vto change the value and confirm with .
Repeat steps 1–2 to set the minutes, day and
month.
Display language
When the date has been set,
ENGLISH
is displayed. You can now
choose between 8 display languages:
English - Français - Español - Italiano
Deutsch - Nederlands - Polski - Svenska
Use v / Vto select the desired language, and confirm
with .
Display contrast
-2- CONTRAST
is displayed.
Use v / Vto select a suitable display contrast setting (1–4),
and confirm with .
1.
2.
3.
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
4
English
Key tone
KEYT. ON
is displayed. You can select if a tone should be heard
when a key is pressed.
Use v / Vto set key tone ON/OFF, and confirm with .
Flash time
-100- FLASH
is displayed.
Use v / Vto set the flash key time (100/300/600 ms), and
confirm with .
100 is the standard setting for most countries.
300 for France/Portugal.
Call indicator
LED OFF
is displayed.
Use v / Vto enable/disable the LED indicator for new calls,
and confirm with .
Tone/pulse
TONE
is displayed.
Use v / Vto select either tone or pulse dialling mode, and
confirm with .
Note!
If you are unsure of which dialling mode to use, select TONE
as this works in most locations.
Basic setup of the telephone is now completed.
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
5
English
Wall mounting
The telephone can be wall mounted by using the included wall
mount bracket and two screws (not included).
Warning!
Make sure that no cables, water pipes or gas pipes are
located inside the wall before drilling into it.
Drill two holes in the wall, corresponding to the holes in the
wall mount bracket.
Insert the screws, allowing them to project ~5 mm out from
the wall.
Unplug and remove the handset.
Fit the guide tabs (A) on the bracket into the slots (B) on the
back of the telephone, then slide the bracket upwards until it
snaps into place.
B
A
1.
2.
3.
4.
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
6
English
Position the telephone so that the screws on the wall fit into
the slots in the bracket, then slide the telephone downwards
until it is hanging on the screws.
Remove the handset hook (C) by pushing it upwards, and
insert it in the reversed position so that the small tab (D)
protrudes. The hook will now keep the handset in the cradle
when the phone is wall mounted.
C
D
C
Reconnect the handset and place it in the cradle.
Note!
If the phone is to be used as a desktop phone again,
remember to reverse the position of the handset hook.
5.
6.
7.
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
7
English
Operation
Making a call
Normal dialling
Lift the handset.
Dial the desired telephone number using the keypad.
Hang up the handset to terminate the call.
Speakerphone
The speakerphone function allows you to make a call without
using the handset.
Note!
The speakerphone only works if batteries are installed.
Press sto activate the speakerphone. The LED next to the
key will light up.
Dial the desired telephone number using the keypad.
Press sagain to terminate the call.
Lift the handset to switch from speaker to handset during a call.
Pre-dialling
The pre-dialling function allows you to enter and change a
number before it is dialled.
Enter the desired telephone number using the keypad.
Press to delete the last entered digit.
Lift the handset or press sto dial the number.
Hang up the handset or press sto terminate the call.
1.
2.
1.
2.
1.
2.
3.
Now available to purchase from www.M2Cshop.com
Now available to purchase from www.M2Cshop.com
8
English
Quick redial
Lift the handset or press s.
Press to redial the last dialled number.
Dialling numbers in the call memory
Press to display the most recent call.
Use v / Vto scroll through the last 15 incoming and
outgoing calls.
= Incoming call
= Outgoing call
Lift the handset or press s to dial the displayed number.
Speed dial (one-touch dialling)
Press one of the speed dialling keys A–C. The stored
telephone number is displayed.
Lift the handset or press sto dial the number.
Hang up the handset or press sto terminate the call.
Dialling numbers in the phone book
Press b to open the phone book.
Use v / Vto browse through the phone book, or enter the
first character in the name to quickly find an entry.
Lift the handset or press sto dial the number.
Answering
Lift the handset to answer an incoming call, or press sto
answer using the speakerphone.
1.
2.
1.
2.
3.
1.
2.
3.
1.
2.
3.
