Doro PHONEEASY 410GSM Manuel utilisateur

Doro PhoneEasy®410gsm

20 17

English

Attaching a lanyard

to the phone

1. Loudspeaker

2. Display

3. Left soft key

4. Call key

5. 1/ Voice mail

6. Numeric keypad

7. Microphone

8. #/ Silent mode /

ABC/abc/123

9. End call/Power on/off

10. Arrow keys

11. Right soft key

12. For lanyard attaching

13. Charging contacts, for use

with charging stand (not

included)

14. Led light (new message/

missed call)

15. Led light (charging in

progress)

16. Emergency call key

17. Charging socket

18. Headset socket

19. Battery cover

20. Side key +

21. Side key -

1. Haut-parleur

2. Afcheur

3. Touche contextuelle gauche

4. Touche Appel

5. 1/ Messagerie vocale

6. Clavier numérique

7. Microphone

8. # / Modication du prol /

ABC/abc/123

9. Fin d’appel/Marche/Arrêt

10. Touches de direction

11. Touche contextuelle droite

12. Tour de cou

13. Contacteur pour support

chargeur (à utiliser avec la

base de chargement)

14. Témoin lumineux (Nouveau

message / Appel en abscence)

15. Témoin lumineux (chargement)

16. Touche Appel d’urgence

17. Trappe batterie

18. Prise pour casque

19. Prise pour chargeur

20. Touches latérales (volume +)

21. Touches latérales (volume -)

Français

Fixation d’un cordon

pour le téléphone

English

Contents

Installation .................................... 3

Installing the SIM card and battery.................. 3

Charging .................................... 4

Operation...................................... 5

Activating the phone ............................ 5

Making a call ................................. 6

Making a call from the Phonebook .................. 6

Receiving a call ............................... 6

Volume control ................................ 6

Display Symbols ................................. 7

Additional Functions.............................. 8

Call options .................................. 8

Call waiting .................................. 9

Call information ............................... 9

Call log ..................................... 9

Phonebook .................................. 10

Silent...................................... 12

Headset .................................... 12

SOS calls ................................... 13

Emergency Call key ............................ 14

Alarm...................................... 15

Games ..................................... 15

Calendar ................................... 16

Calculator................................... 16

FM radio ................................... 17

Text input................................... 19

SMS Messaging ................................ 20

Creating and sending SMS....................... 20

Incoming SMS (Inbox).......................... 21

Outgoing SMS (Outbox) ......................... 21

English

Settings...................................... 23

Time and date................................ 23

Tone settings (rings & tones) ..................... 24

Silent...................................... 25

User setup .................................. 26

Bluetooth ................................... 28

Block function ............................... 29

Emergency .................................. 29

Voice mail .................................. 30

Speed dial .................................. 31

Call setup................................... 32

SMS settings ................................ 34

Network setup ............................... 35

Services .................................... 36

Security .................................... 36

Master Reset ................................ 37

Master Clear ................................. 37

Troubleshooting ................................ 38

Safety Instructions .............................. 40

Disclaimer and Limitation of Liability ................. 46

Care and Maintenance ........................... 48

Warranty and Technical Data ....................... 50

English

Installation

Note!

Turn off the phone and disconnect the charger before

removing the battery cover.

Installing the SIM card and battery

The SIM card holder is located behind the battery.

1. Remove the battery cover by pressing it gently down and

sliding away from the emergency call key.

2. Remove the battery if it is already installed.

3. Press lightly on the cardholder and gently slide it towards the

emergency call key.

4. The SIM card holder can now be folded into an upright

position.

5. Placing the SIM-card on the marked area of the

compartment. Make sure that the SIM card’s contacts are

facing downwards and that the cut-off corner is placed

accordingly with the marked area. See picture. Take care not

to scratch or bend the contacts on the SIM card.

6. Fold the SIM-card holder down and gently slide it away from

the emergency call key until it “clicks” into place.

7. Insert the battery by sliding it into the battery compartment

with the contacts facing towards the emergency call key.

8. Replace the battery cover until it “clicks” into place.

English

Charging

Warning!

Only use batteries, charger and accessories that have been

approved for use with this particular model. Connecting other

accessories may be dangerous and may invalidate the phone’s

type approval and guarantee.

When the battery is running low, is displayed and a warning

signal is heard. To charge the battery, connect the mains adapter

to a wall socket and to the charging socket y.

is displayed briey when the charger is connected to the

phone, and when it is disconnected.

The battery charge indicator will be animated while charging. It

takes approximately 3 hours to fully charge the battery.

is displayed on the screen when charging is completed. If the

phone is turned off when the charger is connected to the phone

only the battery charge status indicator will be shown in the

display.

Note!

To save power the LCD backlight goes off after a short while

but the phone is still charging. Press any key to illuminate the

display.

Full battery capacity will not be reached until the battery has

been charged 3–4 times.

Batteries degrade over time, which means that call time and

standby time will normally decrease with regular use.

Save energy

When you have fully charged the battery and disconnected the

charger from the device, unplug the charger from the wall outlet.

Phone indicators

When 5 ash you have a new message or a missed call.

When ] ash the battery is running low.

English

Operation

Activating the phone

Press and hold the red button on the phone to turn it on/off.

It takes several seconds so keep holding until you hear the sound.

The following messages may be displayed:

SIM card missing or

incorrectly inserted.

SIM card damaged or not

valid.

If the SIM card is valid but protected with a PIN code (Personal

Identication Number), PIN: is displayed.

Enter the PIN code and press OK ( upper left corner of

keypad).

Delete with Clear ( upper right corner of keypad).

Note!

If PIN and PUK codes were not provided with your SIM card,

please contact your network operator.

Trials: # shows the number of PIN attempts left. When no

more attempts remain, SIM blocked is displayed. The SIM

card must now be unlocked with the PUK code (Personal

Unblocking Key).

1. Enter the PUK code and conrm with OK.

2. Enter a new PIN code and conrm with OK.

Setting the language, time and date

The default language is determined by the SIM card. See Settings

on how to change language, time and date.

English

Making a call

1. Enter the phone number. Delete with Clear.

2. Press qto dial. Press Abort to cancel dialing.

3. Press Lto end the call.

Note!

When making international calls, press *twice for the

international prex "+". Always use ”+” before the country

code for best operation.

Making a call from the Phonebook

1. Press Name to open the Phonebook.

2. Use the arrow keys /to scroll through the

Phonebook, or quick search by pressing the key

corresponding to the rst letter of the entry, see Text input.

3. Press Call to dial the selected entry, or press Back to return

to standby mode.

Receiving a call

1. Press qto answer, or press Silent to switch off the ring

signal and then Reject to reject the call (busy signal).

Alternatively, press Lto reject the call directly.

2. Press Lto end the call.
