Rosé
User‘s Guide
2
Battery case
USB-Type C
Code key pad
Fingerprint sensor
Outside Lever
Inside Lever
Reset button
3
1 2
Mark the holes on the door according to
the template, and then drill the holes.
Install the latch and fasten it with screws.
Install the strike and fasten them with
screws.
Installation Instructions
1. There are two 6 to 10 digit master codes in the Rosé lock.
2. There are 200 user ngerprints/codes available on the Rosé lock.
3. User codes can be 6 to 10 digits.
4. The lock is powered by 3 AAA alkaline batteries (included).
A USB-Type C port is at the end of the outside handle for emergency power supply.
5. The Rose lock has three possible modes:
Standard mode: single code/ngerprint needed to unlock
Passage mode: outside lever unlock for free access
Dual user mode: two codes or ngerprints needed to unlock
Rosé
Digital Door Lock
4
43
5 6
Screw the two (2) posts (groove side)
onto the small black screws attached to
the inside face of the outside lever.
Place the outside lever onto the door
ensuring posts go through latch.
x3
x2
Place the inside lever onto the door.
Line up holes with posts, then using
the two (2) screws provided, secure the
inside and outside levers onto the door.
Note: Do not overtighten the screws.
Use the screw driver provided to unscrew
the battery cover located in the inside
handle. Then install the batteries
(negative terminal going rst).
Cover the batteries.
With door open try to unlock the lock and
make sure the installation was successful.
In factory default mode, the lock will
unlock with any code or any nger print.
CODE
x2
Screw holes
AAA
5
1. Register Master Codes
• Wake up the key pad by touching any of
the numbers. Press * and then #
• Audible message - “enter a new master
user information”
• Enter a new 6 to 10 digit master code
• Press #
• Audible message - “enter it again”
• Enter the new master code again
• Press #
• Audible message - “successful”
• Press * to exit the menu
Step 1
1.1 Register Master Code for a brand new lock or after factory reset
The following procedure is only required when the Rosé lock is brand new or after the lock
has been factory reset.
Note: The programming of user codes or ngerprints cannot be made until a new master code
has been created.
Note: Keep the door open while master codes are being created.
Step 2
MASTER
CODE
6
1.2 Register Second Master Code (optional)
• Wake up the key pad by touching any of
the numbers. Press * and then #
• Audible message - “enter the master user
information”
• Enter the master code created in step 1.1
• Press #
• Audible message - “1 add admin”
• Press 1 for master code registration”
• Audible message - “enter the lock information”
• Enter a new 6 to 10 digit master code,
and conrm with #
• Audible message - “enter it again”
• Enter the new 6 to 10 digit master code,
and conrm with # to nish
• Press * twice to leave the menu
You have to register a master code in the
lock rst, so that you can register the user
codes in the lock.
Once the operation is nished, please try to
unlock the lock to conrm the operation is
successful.
NEW
CODE
MASTER
CODE
Step 1 Step 2
Step 3 Step 4
Step 5
1. Register Master Codes
Note: Keep the door open while master codes are being created.
NEW
CODE
7
2. Register Users
Once the operation is nished, please try
to unlock the lock using the added nger to
conrm the operation is successful.
If a wrong nger print is placed 5 times in a
row the lock will go into lockout mode for 5
minutes.
2
• Wake up the key pad by touching any of
the numbers. Press * and then #
• Audible message - “enter the master user
information”
• Enter the 6 to 10 digit master code
• Press #
• Audible message - “2 add user”
• Press 2 for user registration
• Audible message - “enter the lock
information”
• A. Place the nger on the sensor
B. Audible message - “enter again”
C. Remove nger
• Repeat steps A,B & C six times until audible
message is heard
• Audible message - “successful”
• Press * twice to leave the menu
x6
Please make sure a master code is registered in the lock.
Step 1 Step 2
Step 3 Step 4
2.1 Register User Fingerprint
MASTER
CODE
8
User codes can be 6 to 10 digits.
Once the operation is nished, please try to
unlock the lock using a code to conrm the
operation is successful.
If a wrong code is entered 5 times in a
row the lock will go into lockout mode for 5
minutes.
2
• Wake up the key pad by touching any of
the numbers. Press * and then #
• Audible message - “enter the master user
information”
• Enter the 6 to 10 digit master code
• Press #
• Audible message - “2 add user”
• Press 2 for user registration
• Audible message - “enter the lock information”
• Enter the new user code and press #
• Audible message - “enter it again”
• Enter the new user code and press # to
register
Audible message - “successful”
• Press * twice to leave the menu
Please make sure a master code is registered in the lock.
CODE
Step 1 Step 2
Step 3 Step 4
2. Register Users
2.2 Register User Codes
MASTER
CODE
9
To delete all users follow
on page 11
To delete a single user follow
on page 10
3. Delete User Codes and Fingerprints
Please make sure the master code is registered in the lock.
• Wake up the key pad by touching any of
the numbers. Press * and then #
• Audible message - “enter the master user
information”
• Enter the 6 to 10 digit master code
• Press #
• Audible message - “3 delete user”
• Press 3 to delete user codes/ngerprints
3
Step 1 Step 2
Step 3
Step 4
Step 5
MASTER
CODE
10
• Audible message - “1 to delete a single
user”
• Audible message - “delete user, enter the
lock information”
1
• Place the nger on the sensor to delete
the nger print
• Audible message - “delete user, press # key
to conrm”
• Press # to conrm
• Audible message - “successful”
• Press * three times to leave the menu
Step 4a
CODE
3. Delete User Codes and Fingerprint continued...
Use this option to delete a single user
Delete a single user code
• Enter the user code and press # to delete it
• Audible message - “delete user, press # key
to conrm”
• Press # to conrm
• Audible message - “successful”
• Press * three times to leave the menu
Note: Go to step
4a to delete single user or
4b to delete single ngerprint
Step 4
Step 4b Delete a single ngerprint
