Please read this instruction manual carefully before installation and first

use, and store it in a safe place. If you pass on the product to another

person, hand over this instruction manual along with it.

Contents

1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

4 Target group for this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

7 Installing and connecting the DC kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

8 Using the DC kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

9 Maintaining and cleaning the DC kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

10 Rectifying faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

12 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

DC-Kit1--IO-16s.book Seite 5 Dienstag, 21. März 2017 2:05 14

Explanation of symbols DC-Kit1

1 Explanation of symbols

2 General safety instructions

The manufacturer accepts no liability for damage in the following cases:

•Faulty assembly or connection

•Damage to the product resulting from mechanical influences and excess voltage

•Alterations to the product without express permission from the manufacturer

•Use for purposes other than those described in the operating manual

2.1 General safety

!WARNING!

•Observe the safety instructions in the installation and operating man-

ual for the components supplied and your Dometic roof air

conditioner.

•Use the device only as intended.

•People whose physical sensory or mental capacities prevent them

from using this device safely should not operate it without the

supervision of a responsible adult.

•Electrical devices are not toys!

Always keep and use the device out of the reach of children.

DANGER!

Safety instruction: Failure to observe this instruction will cause fatal or

serious injury.

WARNING!

Safety instruction: Failure to observe this instruction can cause fatal or

serious injury.

NOTICE!

Failure to observe this instruction can cause material damage and impair

the function of the product.

NOTE

Supplementary information for operating the product.

DC-Kit1--IO-16s.book Seite 6 Dienstag, 21. März 2017 2:05 14

DC-Kit1 General safety instructions

•Children must be supervised to ensure that they do not play with the

device.

•Maintenance and repair work may only be carried out by qualified

personnel who are familiar with the risks involved and the relevant reg-

ulations.

2.2 Safety when installing and repairing

!WARNING!

•Installing and repairing the device may only be performed by qualified

personnel who are familiar with the risks as well as the guidelines and

safety precautions to be applied.

2.3 Safe operation

•Only operate the system if you are certain that all the housings and

cables are not damaged.

•The 12 V connection cables are designed for high levels of current. Do

not make any changes to the cable. If necessary, get a specialist to do

this for you.

•Make sure the air inlets and outlets of the device are not covered.

•Ensure good ventilation. The inverter produces dissipated heat which

has to be diverted.

•Always disconnect the power supply when working on the device.

WARNING!

Note the following basic safety information when using electrical

devices to protect against:

•Electric shock

•Fire hazards

•Injury

DC-Kit1--IO-16s.book Seite 7 Dienstag, 21. März 2017 2:05 14

Scope of delivery DC-Kit1

3Scopeofdelivery

Before starting the system, check that all the parts belonging to the scope of delivery

are present.

4 Target group for this manual

The installation information in this manual is only intended for qualified personnel at

workshops, who are familiar with the guidelines and safety precautions to be applied

during the installation of vehicle accessory parts.

All other chapters are intended for the users.

5 Intended use

The DC-Kit1 extension kit (rwef. no. 9100300003) is suitable for equipping the

CA1000 and FJ1100 Dometic roof air conditioner for 12 V g driving operation.

Quantity Description Ref. number

1 Charging current distributor ECL-76 9600000483

1 Inverter with priority circuit PP1002 9600000022

1 Sensing cable for CA1000 4441300084

1 Connection cable

Black supply line (16 mm², 1.5 m long)

Red supply line (16 mm², 1.5 m long)

9600000270

1 Sensing cable for FreshJet/FreshLight 4441300221

1 Inverter adapter 9103530084

1 Remote control for the inverter MCR9 9600000091

1 Installation and operating manual 4445101952

DC-Kit1--IO-16s.book Seite 8 Dienstag, 21. März 2017 2:05 14

DC-Kit1 Technical description

6 Technical description

The DC-Kit1 extension kit enables Dometic roof air conditioners to be used in vehi-

cles with 12 Vg. The extension kit consists of the following components:

•The ECL-76 charging current distributor with low voltage protection regulates

the power distribution between the starter battery, supply battery and light-

machine. This prevents the battery and the electronics in the vehicle from over-

•The PP1002 inverter supplies the roof air conditioner with the required input

voltage of 230 Vw. The inverter generates the 230 V input voltage from the 12 V

on-board electricity supply in the vehicle.

The accompanying remote control can switch the inverter on and off.

The integrated priority circuit can be used for distributing the voltage in the

vehicle with two available power sources. If a mains voltage and voltage created

by the inverter (vehicle battery) are both connected to the device, the use of the

mains voltage has priority. If the only voltage available is that generated by the

inverter, the power supply from the battery is used. This ensures that the limited

power of the battery is not used unnecessarily.

•The inverter adapter ensures that the condenser fan for the roof air conditioner

can control the speed.

7 Installing and connecting the DC kit

NOTICE!

The DC kit may only be installed by a qualified workshop.

The following information is intended for specialists who are familiar with

the guidelines and safety precautions to be applied.

NOTICE!

Observe the information in the installation and operating manuals when

installing the components supplied

•PP1002 inverter

•Inverter adapter

•MCR9 remote control

•ECL-76 charging current distributor

and for your Dometic roof air conditioner

•CA1000

•FJ 1100

DC-Kit1--IO-16s.book Seite 9 Dienstag, 21. März 2017 2:05 14

Installing and connecting the DC kit DC-Kit1

Note the following safety instructions during installation:

Observe the following safety instructions for the electrical connections:

Observe the following instructions when selecting the location for installing the

components:

•Make sure the cables are of the correct length.

•Choose a well-ventilated installation location near the supply battery.

7.1 Preparing the installation

➤Disconnect the following voltage supplies in the vehicle:

– Positive battery terminal

– External voltage supply

NOTICE!

•Note the location of wiring harnesses, wiring and other components

within the installation area.

•Install the DC kit using the following instructions. Improper installa-

tion of the DC kit can put the safety of the user at risk and lead to

irreparable damage to the DC kit or other devices.

•Disconnect all power supply lines to the individual components and

the roof air conditioner.

NOTICE! Risk of short circuit!

•First, disconnect the 230 V external power supply to the caravan.

•Disconnect the earth connection to the supply battery.

•Disconnect the connection to the starter battery.

•If you have to feed cables through metal walls or other walls with

sharp edges, use ducts or tubes to prevent damage.

•Do not lay cables which are loose or bent next to electrically

conductive material (metal).

•Fasten the cables securely.

•Ensure the 12 V cables are especially well-protected.

•Check whether you need to fit any additional fuses.

•Do not pull on the cables.

•Do not lay the 230 V mains cable and the 12/24 V DC cable in the

same duct.

•Lay the cables so that they cannot be tripped over or damaged.

DC-Kit1--IO-16s.book Seite 10 Dienstag, 21. März 2017 2:05 14

Table des matières

Langues :

Autres manuels Dometic Climatiseur

Dometic

Dometic FreshJet FJX4 1500M Manuel utilisateur

Dometic

Dometic IBIS4 Series Manuel utilisateur

Dometic

Dometic Royale Penguin 610115.411 Manuel

Dometic

Dometic FreshJet FJX4333EEH Manuel utilisateur

Dometic

Dometic AirCon ASC 1000 Manuel utilisateur

Dometic

Dometic B1600PLUS Manuel utilisateur

Dometic

Dometic B3300 Series Manuel

Dometic

Dometic FRESHLIGHT FL1600 Manuel utilisateur

Dometic

Dometic DLU Manuel utilisateur

Dometic

Dometic RTX1000 Manuel utilisateur

Dometic

Dometic Scania RTX2000 Manuel utilisateur

Dometic

Dometic Harrier Plus HP36H401RI Manuel utilisateur

Dometic

Dometic SPX1200T Manuel utilisateur

Dometic

Dometic FreshJet FJX 7 Series Manuel utilisateur

Dometic

Dometic COOLAIR SP950I Manuel utilisateur

Dometic

Dometic Blizzard NXT H541815A Manuel utilisateur

Dometic

Dometic FJ 2200 Manuel utilisateur

Dometic

Dometic MCS T6 Manuel utilisateur

Dometic

Dometic 641415.30 series Manuel utilisateur

Dometic

Dometic FRESHLIGHT FL1600 Manuel utilisateur

Dometic

Dometic 640315 Series Manuel utilisateur

Dometic

Dometic FreshJet FJ 1500E Manuel utilisateur

Dometic

Dometic SUPERCOOLER RC 4000 Manuel utilisateur

Dometic

Dometic FreshJet3000 Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
