DoCash Golf Manuel utilisateur

User Manual

Руководство по эксплуатации

Automatic Currency Detector

Автоматический детектор

подлинности банкнот

DoCash Golf

РУССКИЙ

ENGLISH

Table of contents

1. Safety regulations

2. Design

3. Using the machine

3.1. Power

3.2. Switching on

3.3. Function setting

3.4. Inserting the banknotes correctly

3.5. Report

4. Daily maintenance

5. Troubleshooting

6. Software updating

7. Transport and storage

8. Complete set

9. Warranty

10. Technical features

DoCash Golf 2www.docash.de

1. Safety regulations

The information about available notes can be

provided by the manufacturer.

Do not operate the product in areas with high

temperature or high humidity since it may

cause the unit to malfunction.

Do not disassemble this product. Incorrect re-

assembly can cause electric shock. Take it to

qualify personnel if repair is required.

Before turning on the power, please make sure

that there are no objects obstructing the

operation of the rollers and wheels.

Unplug this product from the outlet before

cleaning. Do not use liquid cleaners or aerosol

cleaners. Use a damp cloth for cleaning the

cover.

DoCash Golf 3www.docash.de

Thank you for choosing DoCash equipment.

DoCash is a wide r ange of special cash handling equipment for

retail trade and financial organizations. DoCash is a brand for

simple and reliable banknote and coin counters, universal and

automatic currency detectors, vacuum packaging machines,

shredders, etc. You will find any further information at

www.docash.de

Purpose

DoCash Golf – reliable and practical currency detector, which

allows to differ the genuine banknote from a counterfeit one.

Detector supports various currencies detection and genuineness

checking of every main machine-readable security feature. The

final approval on genuineness must come from an expert in person.

Declaration of Conformity

The counter conforms to the following safety requirements:

General - GOST IEC 60950-1-2011,

Electromagnetic compatibility - GOST R 51318.22-2006.

TR TS 004/2011 «Low-voltage equipment safety»;

TR TS 020/2011 «Electromagnetic compatibility of technical

means».

This manual contains information that is actual for the moment of

publishing, and may not contain the latest changes.

The manufacturer may change machine’s specifications and control

algorithms.

DoCash Golf 4www.docash.de

2. Design

Front Side

1. LCD Display Screen

2. Currency Input Slot

3. CLEAR / DIRECTION Key

(Press and hold this key to

change passing direction)

4. REPORT/CURRENCY Key

(Press and hold this key

to change currency setting)

Bottom and Back side

1. Battery Cover

2. USB Port for Software Update

3. DC9V Power Input Socket

4. Power Switch

5. Currency Exit Slot

DoCash Golf 5www.docash.de

1 2 3 4 5

DoCash Golf 6www.docash.de

3. Using the machine

3.1. Power

Connect the power device (from 110V to 220V) to the machine

with DC9V power slot.

Lithium accumulator (optional): Fully charged accumulator

allows the machine to work without connection to the power

source.

3.2.Switching on

The machine will conduct a self-

check at start-up. The Value display

and Sheets display will show 0. The

counterfeit detection function

(CFD) and currency selection

(CURRENCY) are activated

along with the machine starting up, as it is shown on the picture.

The function of accumulative counting (ADD) is activated by

pressing and holding CLEAR/DIRECTION key along with the

machine turning on. The display will show ADD as an indication

for activation of this function.

3.3. Function Setting

Currency Settings: Press and hold the REPORT/CURRENCY

key for 3 seconds can change the detecting currency. The

currency will change from RUB, EUR, USD or other cur rency.

CAUTION

This function is available only for multi-currency devices.

Currency passing Direction: Press and hold the CLEAR/

DIRECTION key for 3 seconds to change the cur rency

passing direction.

The Direction symbol will change between “ ” and “ ”.

This direction means that genuine notes exit from the

Currency exit slot, and counterfeit notes exit from the

Currency input slot.

This direction means that both genuine and counterfeit notes

exit from the Currency input slot.

3.4. Inserting the banknotes correctly

Please, put the notes inside the detector carefully as it is

shown on the picture 1. The machine will not check the note

and respond with an error message, if the note is not put

correctly.

Banknotes of any orientation must be placed near the left side, as

it show on picture 1.

Pictures 2 and 3 show the wrong way of putting the note into the

machine.

Banknote must be carefully pressed with a long side to the left

side of the input section and smoothly inserted along the

parallel machine position.

DoCash Golf 7www.docash.de

DoCash Golf 8www.docash.de

2 3

√

After a note was inserted, the detecting system will check it and

then alert the user with an audible signal, indicating whether the

banknote is genuine one or fake one.

DoCash Golf 9www.docash.de

Suspicious or counterfeit notes will be rejected with two beeps

and the display will show the error code.

 The genuine note data will be added into the Val ue and

Sheets parameters. The summary of Val ue and Sheets

will be shown at the end of the checking procedure.

Number of notes

(Sheets)

Value of notes

(Value)

Press “CLEAR/DIRECTION” key to erase the detected and saved

Valu e иSheets parameters.

3.5. Report

Press “REPORT/CURRENCY” key for the detailed report about

checked notes. The information about a number of notes with

preset denomination will be shown as Sheets parameter data

according to Denomination parameter.

For RUB notes the following order of denomination selection

and showing is set and used:

“5000→1000→500→100→50→10→5000”.

The number of 5000 RUB

notes

5000 RUB denomination

Press “CLEAR/DIRECTION” to finish the procedure.

DoCash Golf 10 www.docash.de

4. Daily maintenance

Open the top cover upward. Use a soft brush to clear the sensors.

Top Cover
