Dji PHANTOM 4 PRO+ Manuel utilisateur

Contents

Using this manual 2

Legends 2

Read Before the First Flight 2

Watch the Tutorial Videos 2

Download the DJ GO 4 App 2

Download the DJ Assistant 2 2

Product Prole 6

ntroduction 6

Features Highlights 6

nstalling the Aircraft 6

Aircraft Diagram 8

Remote Controller Diagram 8

Aircraft 13

Flight Controller 13

Flight Mode 13

Flight Status ndicator 14

Return to Home (RTH) 15

ntelligent Flight Mode 19

Vision System and nfrared Sensing System 27

Flight Recorder 30

Attaching and Detaching the Propellers 30

DJ ntellige t Flight Battery 31

Remote Controller 36

Remote Controller Prole 36

Using the Remote Controller 36

Remote Controller Status LED 41

Linking the Remote Controller 42

Camera and Gimbal 45

Camera 45

Gimbal 47

www.carlosmendoza.com.mx

DJI GO 4 App 49

Equipment 49

Editor 52

SkyPixel 52

Me 52

Flight 54

Flight Environment Requirements 54

Flight Limits and No Fly Zones 54

Preight Checklist 57

Calibrating the Compass 57

Auto Takeoff and Auto Landing 58

Starting/Stopping the Motors 5

Stop the Motor Mid ight 60

Flight Test 60

Appendix 62

Specications 62

Upgrading the Firmware 64

ntelligent Flight Mode 65

After Sales nformation 66

Compliance nformation 66

www.carlosmendoza.com.mx

Product Prole

This section introduces the Phantom 4

Pro / Pro+ and lists the components of

the aircraft and remote controller.

www.carlosmendoza.com.mx

Product Profile

Phantom 4 Pro / Pro+ Use Manua

[10 Camera Settings Dial

Turn the dial to adjust camera settings.

(Only functions when the Remote Controller

is connected to a mob le device running

the DJI GO 4 app.)

[11 ntelligent Flight Pa se Button

Press once to allow the aircraft to exit from

TapFly, ActiveTrack and other intelligent

ight mod s.

[5 Battery Level LEDs

Displays the battery level of the Remote

Controller.

[6 Status LED

Displays the Remote Controller's system status.

[7 Power Button

Used to turn the Remote Controller on and off.

[8 RTH LED

Circular LED around the RTH button displays

RTH status.

[9 Speaker

Audio output.

[14] [13]

[11]

[12]

[19]

[18]

[21]

[20]

[10]

[15]

[16]

[17]

[12 Shutter Button

Two-stage button, press to take a photo.

[13 Sleep/Wake Button

Press to sleep/wake the screen, press and

hold to restart.

[14 Microphone

[15 Flight Mode Swi ch

Switch be we n P-mode, S-mode, and

A-mode.

[16 V deo Recording Button

Pre s to start recording video. Press again

to stop recording.

[ 7 Gimbal Dial

Use this dial to control the tilt of the gimbal.

[18 Micro USB Port

Upgrading the aircraft by connecting to

the remote controller using the USB OTG

cable.

[19 Micro SD Card Slot

Provide extra storage space for the display

device, maximum supporting 128 GB.

[20 HDM Port

Output HDMI video signal.

[21 USB Port

USB device support.

[22]

[24]

[23]

[22 C1 Button

Customizable through the DJI GO 4 app.

[23 C2 Button

Customizable through the DJI GO 4 app.

[24 Power Port

Connect to the Charger to charge the

battery of the Remote Controller.

www.carlosmendoza.com.mx

Product Profile

Phantom 4 Pro / Pro+ Use Manua

Phantom 4 Pro (Mode : GL300F)

[1 Antennas

Relays aircraft control and video signal.

[2 Mobile Device Holder

Securely mounts your mobile device to the

remote controller.

[1]

[2]

[3]

[4]

[5]

[7]

[8]

[6]

[3 Control Stick

Controls the orientation and movement of the

aircraft.

[4 Return Home (RTH) Button

Press and hold the button to initiate Return to

Home (RTH).

[5 Battery Level LEDs

Displays the battery level of the remote

controller.

[6 Status LED

Displays the remote controller's system status.

[7 Power Button

Used to tur the remote controller on and off.

[8 RTH LED

Circ lar LED around the RTH button displays

RTH status.

[9 Camera Settings Dial

Turn the dial to adjust camera settings.

(Only functions when the remote controller is

connected to a mobile device ru ning the DJI

GO 4 app.)

[10 ntelligent Flight Pause Button

Press once to allow the aircraft to exit from

TapFly, ActiveTrack and other intelligent ight

modes.

[11 Shutter B tton

Two-stage button, press to take a photo.

[12 Flight Mode Switch

Switch between P-mode, S-mode, and

A-mode.

[13 Video Recording Button

Press to start recording video. Press again to

stop recording.

[14 Gimbal Dial

Use this dial to control the tilt of the gimbal.

[15 Micro USB Port

Reserved port.

[16 USB Port

Connection to mobile device for DJI GO 4 app.

[10]

[11]

[15] [16]

[9]

[12]

[13]

[14]

www.carlosmendoza.com.mx
