8. You will hear the special dialling tone indicating that
programming mode is active.
You can now enter the parameter codes to change the
relevant features of your distybox300.
Let’s say, for example, you want to use your distybox300 on
a base station with an ISDN telephone connection. Activate
programming mode as described above in points 1– 8 and
then proceed as follows:
1. Enter the programming code for ”Connection to an ISDN/
analogue Line”: 04
2. To activate the feature, enter: #0
3. You will hear a positive acknowledgement tone, followed
by the special dialling tone once more. The feature is now
active.
Setting parameters in programming mode
Not all the features offered by the distybox300 are
supported by every DECT/GAP base station. Refer to the
operating manual for your base station to clarify which
features you can use.
Programming mode needs to be activated before this pa‑
rameter can be set. The function‑programming process is
concluded by entering # and conrmed by the positive
acknowledgement tone. You will then hear the
special dialling tone once more, which means that you can
continue programming other functions. With the exception of
programming points 90, 91 and 99, the change is effective
without having to restart the distybox300.
If an invalid value is entered during programming, a negative
acknowledgement tone is sounded, the procedure is cancelled
and you will hear the special dialling tone once more.
NOTE
EXAMPLE
If during programming no input is made for one minute, the
procedure is cancelled and you will hear the special dialling
tone again.
Programming mode can be exited at any time by replacing
the handset; the distybox300 will then be returned to normal
mode.
Function Parameter Other input
code
Manual registration 1 Base PIN #
of the distybox300
The base station PIN needs to be entered to register the
distybox300. A PIN with 0 to 8 digits will be accepted by the
distybox300. After entering #you will hear the positive
acknowledge tone. Leave the handset off hook and wait
until you hear again the special dial tone, which means that
the registration is completed. If the registration process has
not been completed successfully within approx. 3 minutes,
crosscheck the settings of the base station and try again.
Access to programming mode can be protected using the
four‑digit PIN.
Connection to 40 0 #
an ISDN/analogue
line
This setting has to be used if your base station is connected
to an ISDN phone line. Send Keypad Information, while
connection Keypad information will be suppressed, so it is
possible to transmit DTMF signals.
40 1 #
Suppress Keypad Information: This setting has to be used if
your base station is connected to an analogue phone line.
