Diskashur iStorage Manuel utilisateur

User
Guide
Remember to save your PIN in a safe
place. If lost or forgotten, there is no way
to access the drive.
If you are having difculty please refer
to the complete user’s manual which is
loaded on your diskAshur PRO drive and
is also available at iStorage’s website:
www.istorage-uk.com/support
PRO
®

Table of Contents
About the diskAshur PRO 4
Package contents 4
diskAshur PRO - Connections 5
Before you begin 5
Connecting diskAshur PRO 5
Connecting with the USB Y-Cable 6
diskAshur PRO Keypad Panel 7
First Time Use 7
Locking the Drive 8
Unlocking the Drive 8
Admin Mode 8
Changing the Admin PIN 8
Adding a new User PIN 9
Deleting the User PINs 9
Changing the User PIN 9
Setting the Unattended Auto Lock Feature 10
diskAshur PRO Brute Force Protection 11
Setting a Self-Destruct PIN 12
Performing a Complete Re-Set 12
Initializing and formatting the diskAshur PRO after a reset 13
Hibernating or Logging off from the OS 14
diskAshur PRO Setup for Mac OS 15
Troubleshooting 16
Technical Support 18
Warranty and RMA information 18

Copyright © iStorage Limited, Inc 2013. All rights reserved.
Windows is a registered trademark of Microsoft Corporation.
All other trademarks and copyrights referred to are the property of their
respective owners.
Distribution of modied versions of this document is prohibited without
the explicit permission of the copyright holder.
Distribution of the work or derivative work in any standard (paper) book
form for commercial purposes is prohibited unless prior permission is
obtained from the copyright holder.
DOCUMENTATION IS PROVIDED AS IS AND ALL EXPRESS OR
IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT,
ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH
DISCLAIMERS ARE HELD TO BE LEGALLY INVALID

4
About the diskAshur PRO
Package contents
• diskAshur PRO drive with
integrated USB 3.0 cable
• Travel pouch
• USB Y-cable
• Quick Start Guide
Looking for the highest level of
security for your data while utilizing
the fastest USB 3.0 speeds?
Look no further than the
diskAshur PRO 140-2 Validated
Drive, certied and tested to NIST
FIPS 140-2 Level 2 requirements
and with the fastest speeds of
iStorage’s Secure Drive line.
Sporting an easy-to-use keypad
design that is impervious to dust
and grit, with a software free setup
and operation, the diskAshur PRO
enables you to access the drive
simply and easily with your own
unique PIN. And with a super fast
integrated USB 3.0 cable, you can
access your data faster than ever
before.
diskAshur PRO
Quick Start Guide
1
2
3
4
3
1
2
SHIFT button
UNLOCK button
LED Indicator lights
4
LOCK button
When you rst plug in the
diskAshur PRO, the unit will do
a self-test to verify all security
components are working properly.
The LEDs will go through 3 test
stages RED, GREEN, and BLUE.
This will be followed by three
GREEN ashes on a successful
test. Any test failure will leave the
unit in an interoperable state with
the RED LED ashing.
First Time Use
Before the drive can be used, the Admin PIN MUST be set. The LED will display Solid
BLUE and Solid GREEN to indicate the diskAshur PRO is waiting for a PIN to be set.
To Set-up the Admin PIN:
1. Press UNLOCK + 9. The LED will change to Solid BLUE and Blinking GREEN.
2. Enter the new Admin PIN and press UNLOCK key. If accepted the GREEN LED
will ash for 3 short blinks, then return to Solid BLUE and Blinking GREEN.
3. Re-enter the Admin PIN and press the UNLOCK key. If accepted the GREEN
LED will be Solid for 3 seconds.
4. LED will then turn BLUE and remain in Admin mode for 30 seconds or if the
LOCK key is pressed, will return the drive to a standby state.
5. The Admin PIN is now set and will allow access to the drive or the Admin features.
6. To UNLOCK the drive, exit Admin by pressing the LOCK button. Then enter the
new PIN and press UNLOCK.
*Note: PINs must be a minimum length of 7 maximum 16 digits.
Cannot contain all consecutive numbers (2345678 or 9876543)
Cannot contain all same number (1111111)
The SHIFT key can be used for additional combinations.
SHIFT + 1 are a separate value than just 1.
TM
PRO
®

5
diskAshur PRO - Connections
Before you begin
Be sure to review the following information before you begin to use
diskAshur PRO.
Attention: Use only the included cables with your diskAshur PRO.
You might damage the drive if you use a cable not included with the
diskAshur PRO.
diskAshur PRO is designed for portable use without an AC power adapter
and in most cases will be able to power on a single USB port. In the event
that diskAshur PRO is unable to power on a single USB connection, use
the included USB Y-cable. The diskAshur PRO is not self-powered and
requires connection to a USB port to perform all operations.
Connecting diskAshur PRO
1. Attach the integrated USB cable of the diskAshur PRO drive to an
available USB port on your computer, as shown below.
NOTE: While diskAshur PRO will work with any USB port, for the
fastest speeds connect to a USB 3.0 port on your computer.
2. At least one of the diskAshur PRO LEDs should turn on, indicating that
it is receiving power.
If none of the LEDs turn
on or the drive locks when
writing to the disk, use the
included USB Y-cable.
Refer to directions on the
following page
About the diskAshur PRO

6
Connecting with the USB Y-Cable
If none of the diskAshur PRO LEDs power on a single USB connection,
use the included USB Y-cable.
1. Attach diskAshur PRO’s integrated USB cable to the female connector of
the USB Y-cable.
2. Connect the two male USB connectors to two available USB ports on
your computer.
3. At least one of the diskAshur PRO’s LEDs should turn on, indicating that
the diskAshur PRO is powered.

7
1
2
3
43
1
2
SHIFT button
UNLOCK button
LED Indicator lights
4
LOCK button
When you rst plug in the FIPS
diskAshur PRO drive, the unit will
do a self-test to verify all security
components are working properly.
The LEDs will go through 3 test
stages RED, GREEN, and BLUE.
This will be followed by three
GREEN ashes on a successful
test. Any test failure will leave the
unit in an interoperable state with
the RED LED ashing.
First Time Use
Before diskAshur PRO can be used, the Admin PIN MUST be set. The LED will display
Solid BLUE and Solid GREEN to indicate diskAshur PRO is waiting for a PIN to be set.
To Set-up the Admin PIN:
1. Press UNLOCK + 9. The LED will change to Solid BLUE and Blinking GREEN.
2. Enter the new Admin PIN and press UNLOCK key. If accepted the GREEN LED
will ash for 3 short blinks, then return to Solid BLUE and Blinking GREEN.
3. Re-enter the Admin PIN and press the UNLOCK key. If accepted the GREEN
LED will be Solid for 3 seconds.
4. LED will then turn BLUE and remain in Admin mode for 30 seconds or if the
LOCK key is pressed, will return the drive to a standby state.
5. The Admin PIN is now set and will allow access to the drive or the Admin features.
6. To UNLOCK the drive, exit Admin by pressing the LOCK button. Then enter the
new PIN and press UNLOCK.
Requirements for Admin, User and Self-Destruct PIN:
PINs must be a minimum length of 7 maximum 16 digits.
Cannot contain all consecutive numbers (2345678 or 9876543)
Cannot contain all same number (1111111)
The SHIFT key can be used for additional combinations.
SHIFT + 1 are a separate value than just 1.
diskAshur PRO Keypad Panel
TM
PRO
®

8
Locking the Drive
To lock the drive, press the LOCK button.
If data is still being written to the drive, diskAshur PRO will wait until all data has been written
to the drive and then it will lock automatically.
Note: The diskAshur PRO will not be recognized by the operating system in the standby state.
Admin Mode
To enter the Admin Mode, do the following:
1. Attach the USB cable to an available USB port on your computer. The diskAshur PRO
goes into the Standby Mode after the self-check, and the LED turns RED.
2. Press and hold UNLOCK + 0 for ve seconds until the LED ashes RED.
This indicates that you can enter the Admin PIN.
3. Enter the Admin PIN and press the UNLOCK button.
4. The drive is in Admin Mode when the LED has changed to BLUE.
Changing the Admin PIN
You can change the Admin PIN by doing the following:
1. Enter Admin Mode (UNLOCK + 0 for ve seconds. Enter Admin PIN and press UNLOCK).
2. Press and hold UNLOCK + 9 until the LED turns to Solid BLUE and Blinking GREEN.
3. Enter the new PIN and press UNLOCK (The PIN must be a minimum of 7 digits and a
maximum of 16 digits). The LED ashes GREEN three times, then returns to Solid BLUE
and Blinking GREEN.
4. Re-enter the new Admin PIN and press UNLOCK. The LED stays solid GREEN for
two seconds and then solid BLUE indicating that the Admin PIN has been changed
successfully.
Unlocking the Drive
To unlock the drive:
Enter either a User PIN or Admin PIN and press the UNLOCK button.
Note: The diskAshur PRO cannot be recognized by the operating system in the standby state.

9
Adding a new User PIN
Deleting the User PINs
You can delete ALL User PINs by doing the following:
1. Enter the Admin Mode (UNLOCK + 0 for ve seconds. Enter Admin PIN and press UNLOCK).
2. Press and hold 7 + 8 + UNLOCK for ve seconds until the LED ashes GREEN three
times and then changes to BLUE / RED alternating.
3. Press and hold 7 + 8 + UNLOCK a second time for ve seconds until the LED goes on
solid GREEN for two seconds and then back to solid BLUE, this indicates that the User
PINs were deleted successfully.
Changing the User PIN
You can change the User PIN by doing the following:
1. Unlock the drive by inputting your User PIN and pressing the UNLOCK button.
2. Press and hold UNLOCK + 1 until the LED ashes RED.
3. Enter your current PIN and press UNLOCK.
The LED will be Solid BLUE and Solid GREEN.
4. Enter the new PIN and press UNLOCK (The PIN must be a minimum of 7 digits and
a maximum of 16 digits). The LED will ash GREEN three times, then returns to Solid
BLUE and Blinking GREEN.
5. Re-enter the new User PIN and press UNLOCK. The LED stays solid GREEN
indicating that the User PIN has been changed successfully.
1. Enter the Admin Mode (UNLOCK + 0 for ve seconds. Enter Admin PIN and press UNLOCK).
2. Press and hold UNLOCK + 1 until the LED turns to Solid BLUE and Blinking GREEN.
3. Enter a User PIN and press UNLOCK (a minimum of 7 digits and a maximum of 16 digits).
The LED ashes GREEN three times, then returns to Solid BLUE and Blinking GREEN.
4. Re-enter the new User PIN and press UNLOCK. If the LED stays solid GREEN for two
seconds and then solid BLUE, the User PIN was successfully added.

10
Setting the Unattended Auto Lock Feature
To protect against unauthorized access if the drive is unlocked and unattended,
diskAshur PRO can be set to automatically lock after a pre-set amount of time. In
its default state, the diskAshur PROUnattended Auto Lock feature is turned off. The
Unattended Auto Lock can be set to activate after 5, 10 or 20 minutes.
To set the Unattended Auto Lock please uses the following steps:
1. Enter the Admin mode by pressing and holding UNLOCK + 0 for ve seconds until
the LED ashes RED. This indicates that you can enter the Admin PIN.
2. Enter the Admin PIN and press UNLOCK. The drive is in Admin Mode when the LED
has changed to solid BLUE.
3. Once in Admin mode, press UNLOCK + 6. The LED should start ashing RED and
BLUE intermittently.
4. Press one of the numbers below that corresponds to amount of time you would like
the drive to lock after no activity:
1=5 minutes
2=10 minutes
3=20 minutes
0=OFF
The Default is OFF for this feature.
5. After you have input the number, the LED should ash GREEN 3 times to indicate
that you have successfully set the Unattended Auto Lock feature.
Ce manuel convient aux modèles suivants
1
Table des matières
Manuels Stockage populaires d'autres marques

Spectra Logic
Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic
Panasonic LKM-F931-1 Manuel utilisateur

Tabernus
Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor
Rocstor COMMANDER 3F series Manuel utilisateur

HP
HP P9000 Manuel utilisateur

Western Digital
Western Digital Ultrastar Data60 Manuel utilisateur
