Directed AS-RFK2300 Manuel utilisateur

Two-Way FM LED Remote System

INDUSTRY CANADA USER NOTICE:

Operation is subject to the following two conditions: (1)thisdevice may notcause interference,and (2) this

device must accept anyinterference,including interference that maycause undesiredoperationof the device.

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that

the equivalent isotropically radiated power(EIRP) is not more than that required for successful communication.

NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized

modifications to thisequipment. Such modificationscould void the user's authorityto operate the equipment.

AS-RFK2300

User Guide

Designed & engineered in Canada

Available functionalities depend on vehicle. Consult your dealer for more information.

P.2 User Guide

Note: Some functionalities and behaviours may not be available on certain vehicles. See

dealer for available options.

Table of Contents

Government Regulations........................................................................................................3

Using the Remote Control......................................................................................................4

Vehicle Presets (only with remote starter)............................................................................4

Heater..................................................................................................................................4

Windshield Wipers, Radio & Headlights..............................................................................4

Remote-Starting your Vehicle (only with remote starter)....................................................5

Remote-Starting...................................................................................................................5

Driving Off............................................................................................................................5

Remote System Features........................................................................................................5

Remote Door Locks.............................................................................................................5

Remote Trunk Release........................................................................................................5

Idle Mode (only with remote starter)....................................................................................5

Panic Mode..........................................................................................................................6

Feature Confirmation Chart....................................................................................................6

AUX 1 & AUX 2....................................................................................................................6

Vehicle Status Request...........................................................................................................6

Status Request When the Engine IS NOT Running............................................................6

Status Request When the Engine is Running .....................................................................7

Troubleshooting Poor Transmission Range........................................................................7

Abridged Command Table......................................................................................................8

User Guide P.3

Government Regulations

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

This device complies with the Industry Canada Radio Standards Specification RSS 210. Its use is

authorized only on a no-interference, no-protection basis; in other words, this device must not be

used if it is determined that it causes harmful interferences to services authorized by IC. In

addition, the user of this device must accept any radio interface that may be received, even if this

interference could affect the operation of the device.

Warning! Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate this device.

P.4 User Guide

Using the Remote Control

Your remote system is equipped with a 5-button multi-channel remote control. The functions of the

transmitter are as follows:

LOCK (LED 1): Locks the

doors.

UNLOCK (LED 2):

Unlocks the doors.

TRUNK (LED 3): Opens

the TRUNK. START (LED 4): Remote

starts the engine.

SHIFT

: This button

serves as a second function

button. In combination with the

other four buttons, this button

allows to assign different

functions to those buttons.

N.B.: Pressing then the LOCK button will activate the AUX 1 output.

Pressing then the UNLOCK button will activate the AUX 2 output.

Vehicle Presets (only with remote starter)

Heater

When leaving the vehicle it is recommended to preset the accessory controls in preparation for the

next remote start. Settings for the blower motor (fan), front and rear, should not be left on HIGH. It

is recommended to leave the settings on LOW or MEDIUM instead.

Windshield Wipers, Radio &Headlights

Certain vehicles require the radio and / or windshield wipers and / or headlights circuits to become

energized while running under remote start. When leaving the vehicle you must ensure that the

windshield wipers and headlights switches are OFF. Leaving the headlights switch ON in certain

types of vehicles could cause them to remain ON even after remote starter shutdown, resulting in a

dead battery.

User Guide P.5

Remote-Starting your Vehicle (only with

remote starter)

Remote-Starting

Press the button for approximately 1 second. The remote will beep once to inform you that the

vehicle has received your signal. Approximately 5 seconds later, the engine will start. The remote

will confirm the remote starter’s activation by beeping 3 times.

If your vehicle does not start at the first attempt, the system will shut down, wait a few seconds and

try to start the engine again.

Driving Off

With the vehicle running under remote control, press the button to disarm and unlock the

doors. Enter the vehicle and do the following:

•Turn the ignition key to the IGNITION ON (RUN) position. (Do not turn the key to the CRANK

position while the engine is running.)

•Press the brake pedal to disengage the remote starter unit.

You are now ready to drive off.

Remote System Features

Remote Door Locks

To LOCK your doors:

1. Press and hold the button for approx. 1 sec.

2. The remote will beep once to confirm locking of the doors and, if OEM available, arming

the alarm.

To UNLOCK your doors:

1. Press and hold the button for approx. 1 sec.

2. The remote will beep twice to confirm unlocking of the doors and, if OEM available,

disarming the alarm.

Remote Trunk Release

If your vehicle has the Remote Trunk Release option, you can open the trunk by pressing

the button until the remote beeps once.

Idle Mode (only with remote starter)

Convenience feature (compatible bypass module only): Idle Mode allows you to keep the

engine running and the doors locked while you stop, for example, at a convenience store or for a

short delivery.

This feature allows you to let the remote starter take over control of the vehicle (i.e. no Key in the

Ignition Switch) while the engine is running.

P.6 User Guide

Proceed as follows to set the system to Idle Mode:

1. With the engine running, make sure to release the brake pedal and press the button

on the transmitter until the parking lights come ON.

2. Remove the ignition key from the ignition switch.

The engine will continue running.

3. Exit the vehicle and close all doors, hood and trunk.

4. Press the button to lock the doors and to arm the OEM style alarm if available.

Panic Mode

In an emergency situation, you can activate panic mode by pressing and holding the

button for more than 3 seconds, until the horn starts honking. If the vehicle is running

remotely, the engine will shutdown automatically before setting off the horn. You can stop the horn

by pressing:

(This will unlock your doors and deactivate panic mode).

Note: Panic Mode will automatically shut down after 30 sec.

Feature Confirmation Chart

Feature

LED #1

LED #2

LED #3

LED #4

Beep(s)

Lock 3 flashes X X X 1

Unlock X 3 flashes X X 2

Trunk X X 3 flashes X 1

Start X X X 3 flashes 1

Running X X X 3 flashes 3

Stop X X X 3 flashes 2

AUX 1 & AUX 2

Note: These Auxiliary outputs can be used for many different applications

Sliding door(s):

These commands allow you to control most of the vehicle’s accessories depending on what was

connected during the installation (headlights, defroster, sliding door, etc.). For more information,

check with your technician.

Vehicle Status Request

The status request feature allows the user to see the status of the vehicle i.e.: if the doors are

locked or unlocked, etc. The following charts indicate the confirmation sequences.

To retrieve the vehicle status:

Press and release the button then press and release the button (there will be a beep).

The transmitter will then flash the sequence of LED’s depending if the vehicle’s doors are locked or

unlocked.

Status Request When the Engine IS NOT Running

STATUS

SEQUENCE

LED #1

LED #2

LED #3

LED #4

Beep(s)

Lock

3 flashes

Unlock

3 flashes

User Guide P.7

Status Request When the Engine is Running

When the vehicle doors are locked:

LED # 1 will flash 3 times to denote that the vehicle’s doors are locked.

When the vehicle doors are unlocked:

LED # 2 will flash 3 times to denote that the vehicle’s doors are unlocked.

RUN TIME Beep(s) LED #1 LED #2 LED #3 LED #4

If there ismore than 3/4 of

run time cycle 3 ON for 1 sec ON for 1 sec ON for 1 sec ON for 1 sec

If there ismore than half of

run time cycle 3 ON for 1 sec ON for 1 sec ON for 1 sec X

If there ismore than 1/4 of

run time cycle 3 ON for 1 sec ON for 1 sec X X

If there islessthan 1/4 of

run time cycle 3 ON for 1 sec X X X

Troubleshooting Poor Transmission Range

Many factors may affect the operating range of the transmitter. Some of these are:

•The condition of the battery in the transmitter.

•The operating environment (for example: downtown radio-frequency noise, airports, cellular

phone towers…).

•Metal: any type of metal will affect operating range. This includes the vehicle itself.

•The shape of the vehicle can affect range as well (vans in general have less range).

•The shape of the roof and A-pillars brings about considerable radio-frequency deflection (in

this case, the signal from the remote control). As a result, the direction in which the vehicle is

facing in relation to the remote control can affect the range. Straight on (standing in front of

the vehicle) generally gives you the greatest range; the second best performance is from the

back. Using the remote control from either side of the vehicle will usually give the lowest

range.

•The range will be significantly lower in a crowded parking lot than in open space.

•Always hold the transmitter high, approximately at shoulder height.

•The operating range will be somewhat lower on vehicles equipped with an aftermarket or

factory alarm.

P.8 User Guide

Abridged Command Table

Note: Some functionalities and behaviours may not be available on certain vehicles. See

dealer for available options.

Command Sequence



Lock



Unlock



Trunk



Start



Stop



AUX 1 then

AUX 2 then

Panic Mode Hold

( to cancel)

Idle Mode

Whenengine is running through ignition :

II. Remove the key

III. Close all doors

IV.



Arming OEM alarm (see dealer)



Disarming OEM alarm (see dealer)



Priority door access (see dealer)

Unlocking all doors (see dealer) x2

Status request then

Table des matières

Autres manuels Directed Démarreur à distance

Directed

Directed PS-3655EFM Manuel utilisateur

Directed

Directed 4113, 1-button series Manuel utilisateur

Directed

Directed 4115V Manuel utilisateur

Directed

Directed XPRESSSTART ONE Guide d'installation

Directed

Directed XPRESSSTART ONE Manuel utilisateur

Directed

Directed Smart Start ASRF-1510 Manuel utilisateur

Directed

Directed Xpresskit DBALL2 Manuel utilisateur

Directed

Directed SmartStart DSM200 Series Manuel utilisateur

Directed

Directed Clifford 4205X Manuel utilisateur

Directed

Directed SMARTSTART ASRA-2510 Manuel utilisateur

Directed

Directed Xpresskit DBALL2 Manuel utilisateur

Directed

Directed PS-3180E Manuel utilisateur

Directed

Directed Xpresskit DBALL2 Manuel utilisateur

Directed

Directed AS-1774 Manuel utilisateur

Directed

Directed SmartStart ASRF-3510 Manuel utilisateur

Directed

Directed XPRESSSTART ONE Manuel utilisateur

Directed

Directed AS-RFK1710 Manuel utilisateur

Directed

Directed Clifford 4706X Manuel utilisateur

Directed

Directed Python 4115P Manuel utilisateur

Directed

Directed Autostart Signature Series Manuel utilisateur

Directed

Directed Xpresskit DBALL2 Manuel utilisateur

Directed

Directed DS4+ Manuel utilisateur

Directed

Directed SmartStart 5000-series Manuel utilisateur

Directed

Directed 2102T Manuel utilisateur

Manuels Démarreur à distance populaires d'autres marques

AstroStart

AstroStart 803U Manuel utilisateur

Durite

Durite 0-649-20 Manuel

EINHELL

EINHELL BT-PS 1000 Manuel

Linear

Linear ACCESS AK-21 Caractéristiques techniques

Soundstream

Soundstream TARANTULA RS.2 Manuel utilisateur

Jaycar Electronics

Jaycar Electronics MB3752 Manuel utilisateur

Ultra Start

Ultra Start 72 Series Manuel utilisateur

ADS

ADS FLASHLOGIC FLRSVW1 Manuel utilisateur

Selecta

Selecta JS012 Manuel utilisateur

Black Widow Security

Black Widow Security BW RAS 400 Manuel utilisateur

Vector

Vector Power City DK080706 Supplément

Code Alarm

Code Alarm CA-535 Manuel utilisateur

Ozito

Ozito OJS-800 Manuel utilisateur

Profi-Partner

Profi-Partner 46387 Manuel utilisateur

EZ STARTER

EZ STARTER EZ-45 Manuel utilisateur

Viper

Viper 4204 Manuel utilisateur

Essex Electronics

Essex Electronics KE-1701 Manuel utilisateur

EINHELL

EINHELL EGS 3600 Manuel
