INSTALLATION GUIDE

DB3

2015 Lincoln MKZ Hybrid (Smart Key). 403.FORD12 1.60

This product is intended for installation by a professional installer only! Attempts to install this

product by a person other than a trained professional may result in severe damage to a vehicle’s

electrical system and components.

Introduction 3

Vehicle function compatibilities 4

Pre-installation and application warnings 5

Installation 6

Wiring diagram without OEM Remote Start and with T-Harness (THFOD2) 6

Wiring diagram without OEM Remote Start 7

Wiring diagram with OEM Remote Start and with T-Harness (THFOD2) 8

Wiring diagram with OEM Remote Start 9

Locating components in the vehicle 10

Vehicle connections 11

Module programming 13

Push-to-Start (PTS) vehicles 13

Connecting the module 14

LED diagnostics and troubleshooting 15

Soft reset 17

Hard reset 17

Feature programming 18

Feature and option list 19

Limited one year consumer warranty 20

Quick reference guide 21

Contents

3403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)

Introduction

DB3 is an all-in-one door lock and override module.

Warning!

This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs

Mobile application for smartphones. Refer to “Connecting the module” for more information.

4403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)

Vehicle function compatibilities

This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.

Parking Lights Control

Door Lock Control

Door Unlock

Control of aftermarket alarm with OEM remote

* Fuel Level

* Odometer

Immobilizer Bypass-Data No Key Req'd

Remote Start Ready

Remote Start Takeover

SmartStart

Tach / RPM Output

Entry Monitoring ALL Door Pins

Entry Monitoring Hood Pin

Entry Monitoring Trunk/Hatch Pin

Factory Alarm Trigger Monitoring

Brake Status (foot brake)

Ignition Status

5403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)

Pre-installation and application warnings

START HERE This section highlights important information for this speciﬁc ﬁrmware and will assist in pricing accordingly, as

well as bringing awareness to any operational or vehicle limitations.

Compatibilities and Requirements

T-Harness

compatible THFOD2

AUX

Keys required for

programming 1Keys required

for operation 0

Vehicle Takeover Refer to the Quick Reference Guide section for more details.

Firmware notes

Manual transmission: Not compatible with vehicles equipped with a manual transmission.

Factory hood pin: In vehicles not equipped with a Factory Hood Pin, must permanently ground the vehicles N.C. OEM Hood Pin

input for successful operation. See Directechs for hood pin location.

Note: Does not apply to vehicles with a (-) Hood pin such as the 2017+ F-250 - F-450.

Pit Stop: The vehicle pit stop/idle mode feature is not available in this ﬁrmware.

The optional Plug & Play THFOD2 T-Harness is sold separately

The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.

All T-Harness wires not listed in the diagram are not required for the installation.

All connectors are displayed from the wire side (unless speciﬁed otherwise).

Refer to the "Vehicle connections" following the installation diagram.

Conditions and Limitations

This installation enables the OEM remote starter and the remote start system will not work in the following conditions:

The ignition is on.

The alarm system is triggered.

The doors/hood are open.

The transmission is not in Park (P).

The vehicle battery voltage is too low.

The service engine light is on. Note: Any stored DTC code errors will prevent vehicle from remote starting (no visual lights on dash).

RS Features: The following remote starter features can be conﬁgured via the information display:

Climate control

Heated seats / steering wheel

Runtime (for best results, program the remote starter runtime to match the OEM setting)

Remote Starter enable/disable

Footnotes

[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if

not supported in data.

6403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).

1412

10 42

Wiring diagram without OEM Remote Start and with T-Harness (THFOD2)

CUT

210

311

412

513

614

715

Headlight Switch

Type 1

4-pin

connectors

Type 2

NOT USED

(-) Parking Lights Output: Brown/Red

Parking Lights Interr. (conn. side): Orange/Red

Parking Lights Interr. (veh. side): Yellow/Red

(+) Ignition Status Output: Gray/Black: 7

Parking Light

Interrupt: Pin 4

(+) Ignition Status Input

(+) 12V(+) 12V Input

Gateway Module

(on OBDII Connector or right of steering column)

(-) Parking Lights: Gray

or Yellow, pin 11

(-) Ground

D2D

only

T-Harness THFOD2

(optional)

Remote Start Safety

Override Switch

White/Black N.C.

Do not

connect

D2D Port

XKD2D65

(-) Trunk Release Output: Black/White: 1

Refer to

‘Vehicle connections’

for wire and connector

details.

(-) Hood Input

Hood Pin

7403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).

153

164

175

219

197

208

2311

1412

10 42

Wiring diagram without OEM Remote Start

CAN 3 High: Tan/Black: 3

CAN 1 High: Orange/Green: 5

CAN 3: Low: Tan: 4

CAN 1 Low: Orange/Brown: 6

(-) Ground

(+) 12V Input

(-) Parking Lights Output: Brown/Red:12

Parking Lights Interr. (conn. side): Orange/Red:10

Parking Lights Interr. (veh. side): Yellow/Red:11

Parking Light

Interrupt:

Pin 4

CUT

210

311

412

513

614

715

Headlight Switch

CAN 1 High:

White/Blue or Blue, pin 20

CAN 3 Low: Pin 17

CAN 3 High: Pin 18

CAN 1 Low:

White, pin 19

(+)12V: Pin 24

(-) Ground: Pin 14

(-) Parking Lights:

Gray or Yellow,

pin 11

Gateway Module

(on OBDII Connector or

right of steering column)

(+) Ignition Status Output: Gray/Black: 7

(+) Ignition Status Input

D2D Port

XKD2D65

(-) Trunk Release Output: Black/White: 1

Refer to

‘Vehicle connections’

for wire and connector

details.

(-) Hood Input

Hood Pin

8403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).

Wiring diagram with OEM Remote Starter and with T-Harness (THFOD2)

CUT

210

311

412

513

614

715

Headlight Switch

Type 2

4-pin

connectors

Type 1

NOT USED

(-) Parking Lights Output: Brown/Red

Parking Lights Interr. (conn. side): Orange/Red

Parking Lights Interr. (veh. side): Yellow/Red

T-Harness THFOD2

(optional)

(+) Ignition Status Output: Gray/Black: 7

(-) Trunk Release Output: Black/White: 1

Parking Light

Interrupt:

Pin 4

(-) Ground

(+) Ignition Status Input

(+) 12V(+) 12V Input

Remote Start Safety

Override Switch

White/Black N.C.

Gateway Module

(on OBDII Connector or right of steering column)

(-) Parking Lights:

Gray or Yellow, pin 11

D2D

only

Do not

connect

D2D Port

XKD2D65

Refer to

‘Vehicle connections’

for wire and connector

details.

(-) Hood Input

Hood Pin

9403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).

153

175

186

2210

208

1412

10 42

Wiring diagram with OEM Remote Start

CAN 2 High: Tan/Black: 3

CAN 1 High: Orange/Green: 5

CAN 2 Low: Tan: 4

CAN 1 Low: Orange/Brown: 6

(-) Ground

(+) 12V Input

(-) Parking Lights Output: Brown/Red:12

Parking Lights Interr. (conn. side): Orange/Red:10

Parking Lights Interr. (veh. side): Yellow/Red:11

Parking Light

Interrupt:

Pin 4

CUT

210

311

412

513

614

715

Headlight Switch

CAN 1 High:

White/Blue or Blue, pin 20

CAN 2 Low: Pin 22

CAN 2 High: Pin 23

CAN 1 Low:

White, pin 19

(+)12V: Pin 24

(-) Ground: Pin 14

(-) Parking Lights:

Gray or Yellow,

pin 11

Gateway Module

(on OBDII Connector or

right of steering column)

(+) Ignition Status Output: Gray/Black: 7

(+) Ignition Status Input

D2D Port

XKD2D65

(-) Trunk Release Output: Black/White: 1

Refer to

‘Vehicle connections’

for wire and connector

details.

(-) Hood Input

Hood Pin

10 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)

Locating components in the vehicle
