SERVICE MANUAL

FOR

COMPACT STOVE

Model CS1205

7400290000R02

CS1205

Table of Contents

OPERATION ............................................................................................................................. 2

REPLACEMENT PARTS........................................................................................................... 4

WIRING DIAGRAM ................................................................................................................... 5

TO REPLACE LIGHT BULBS.................................................................................................... 6

TO REPLACE LAMPHOLDERS................................................................................................ 7

TO REPLACE ON/OFF AND HEATER SWITCHES ................................................................. 8

TO REPLACE HEATER ASSEMBLY........................................................................................ 9

TO REPLACE TERMINAL BLOCK.......................................................................................... 10

TO REPLACE FLAME MOTOR/FLAME ROD......................................................................... 11

TO REPLACE THE POWER CORD........................................................................................ 12

TROUBLESHOOTING GUIDE................................................................................................ 13

CS1205

OPERATION

Compact Stove Controls

A. Main on/off switch

1. The fireplace has a manual power ON/OFF switch located on the lower right side of

the stove.

2. To operate, press the switch to turn the unit on or off

B. Low Heat Switch

Press this switch to turn the stove to low heat.

C. High Heat Switch

Press this switch to turn the stove to high heat.

RESETTING THE TEMPERATURE CUTOFF SWITCH

Should the heater overheat, an automatic cut out will turn the heater off and it will not

come back on without being reset. It can be reset by switching the MAIN ON/OFF

SWITCH to OFF and waiting 5 minutes before switching the unit back on.

CAUTION

If you need to continuously reset the heater, unplug the unit and call Dimplex North

America Limited at 1-888-346-7539.

CS1205

REPLACEMENT PARTS

COMPACT STOVE, DIMPLEX

PART NO. 6902340100

REPLACEMENT PART REPLACEMENT PART NO.

1. Log Set Assembly 0477850100RP

2. Flame Motor 120V 2000210200RP

3. Heater Assembly (comes with cutout) 2200491000RP

4. Main On/Off Switch 2800070700RP

5. Heater Switch 2800070200RP

6. Cord Set 120V 4100090103RP

(When 4100090103RP is gone use 4100090201RP)

7. Moulded Lampholder 4200121000RP

8. Flame Rod 5900250100RP

9. Mirror 5900530200RP

10.Foot 0477830159RP

11.Terminal Block 4000070100RP

12.Capacitor 2300030100RP

CS1205

WIRING DIAGRAM

CS1205

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

Light bulbs need to be replaced when you notice a dark section of the flame. There are

four bulbs under the log set which generate the flames and embers.

It is a good idea to replace all of the light bulbs at one time if they are close to the end of

their rated life. Group replacement will reduce the number of times you need to open

the unit to replace the light bulbs.

TO REPLACE LIGHT BULBS

1. Remove the 5 fastening screws from the back access panel and remove the panel.

2. Examine the bulb to determine if replacement is required.

3. Unscrew the bulb counter clockwise.

4. Insert and install the new bulb.

5. Re-secure the access panel to the unit.

LIGHT BULB REQUIREMENTS

Quantity of 1 clear chandelier or candelabra bulbs with an E-12 (small) socket base,

60 watt rating.

CS1205

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

TO REPLACE LAMPHOLDERS

1. Remove the light access panel from the bottom of the rear panel of the stove.

2. Remove the light bulb from the socket by turning counter clockwise.

3. Turn the stove over onto its top.

NOTE: A protective barrier between the top of the unit and your work surface is

suggested, (i.e. cloth, cardboard, thick plastic) to avoid scratching the finished

surface of the stove.

4. Remove the 5 screws which secure the bottom heater cover to the fireplace: 2 at the

front and 3 at the back.

5. Lift the heater assembly and cover off the body of the stove and turn sideways

resting it against the legs of the unit, exposing the light harness/socket assembly

and terminal block.

6. Cut the plastic wire-ties which secure the wires to the base of the stove.

7. Remove the blue and white wires from the terminal block by loosening the screw in

the associated terminal to release each wire, noting their original locations.

8. Remove the screw which secures the lampholder to the base of the fireplace.

9. With a flat head screwdriver, push the lampholder sideways to allow mounting tab to

release so that it can be pushed through the opening in the base of the stove.

10.Through the access panel in the back, pull the original lampholder and the wire

leads out of the stove.

11.Through the same location feed the new lampholder back into the base of the stove.

12.Secure the socket with the original screw.

13.Insert the wires into the terminal block following the original configuration and tighten

the terminal screws to secure the wires into position.

14.Re-assemble the covers and the light bulb in reverse order as described above.

NOTE: When securing the bottom panel to the fireplace, take care that no wires are

in the way of the heater fan and are not caught or pinched between the cover and

the stove.

CS1205

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

TO REPLACE ON/OFF AND HEATER SWITCHES

1. Turn the stove over and place it top down.

2. Remove the bottom heater assembly cover being careful not to damage any of

the wiring.

3. Remove the 4 heater retaining screws from the bottom of the heater assembly

cover and move the heater to gain access to the switch connections.

4. Locate the switch to be replaced mounted on heater assembly cover and

disconnect the wiring clips and connections noting their original locations.

5. Depress the retainer clips on the rear of the switch and push the switch out of the

rear of the cover.

CS1205

If unit was operating prior to servicing allow at least 10 minutes for light bulbs and

heating element to cool off to avoid accidental burning of skin.

Disconnect power before attempting any maintenance or cleaning to reduce the risk of

electric shock or damage to persons.

TO REPLACE HEATER ASSEMBLY

1. Turn the stove over and place it top down.

2. Remove the bottom heater assembly cover being careful not to damage any of the

wiring.

3. Remove the 4 heater retaining screws from the bottom of the heater assembly cover

and move the heater to gain access to the heater connections being careful not to

damage any of the wiring.

4. Disconnect the 2 heater switch leads from the heater.

5. Remove the wire nut and disconnect the thermal cut-out wire.

6. Remove the 2 mounting brackets from the bottom of the old heater and install them

on the new heater.

7. Reassemble in the reverse order as above.
