Valued Customer,

Thank you and congratulations for purchasing a Dimplex

electric stove. Over the years, valuable memories will

occur around the warmth and comfort of your stove.

Thank you for allowing our product to be the backdrop

for those special moments.

Serial Number

Model Number

Part Number

Owner’s Manual

Model Numbers:

DS5598

SS5800PB

DS5804

DS5603

DS5804CM

QUICK REFERENCE GUIDE



following:





check, follow the instructions for replacing

the light bulbs under the maintenance

section of this manual)

2. The heater in your stove may emit a slight,



normal condition caused by the initial heating of

internal heater parts.

3. The information regarding the model of your

stove can be found on the rating plate located

on the top or the back of the stove.

4. If you have any technical questions or concerns

regarding the operation of your stove, or

require service contact Dimplex North America

customer service at 1-888-DIMPLEX



to the point of purchase.

CONTENTS

Important Instructions . . . . . . . . . . . . . . . .PAGE 4

Model and Serial Number Information. . . .PAGE 6

Stove Installation . . . . . . . . . . . . . . . . . . .PAGE 7

Operation..........................PAGE 7

Maintenance .......................PAGE 9

Warranty .........................PAGE 12

IMPORTANT INSTRUCTIONS

Please Retain This User’s Guide For Future Reference

When using electrical appliances, basic precautions should always be followed



following:

1. Read all instructions before using the stove.

2. The heater is hot when in use. To avoid burns, do not let bare skin touch

hot surfaces. The trim around the heater outlet becomes hot during heater

operation. Keep combustible materials, such as furniture, pillows,

 

the front of the unit.

CAUTION: High Temperature, keep electrical cords, drapery, and

other furnishings at least 3FT (0.9m) from the front of the heater and

away from the side and rear.

3. Extreme caution is necessary when any heater is used by or near children

or invalids and whenever the unit is left operating and unattended.

4. Always unplug the stove when not in use.

5. Do not operate any unit with a damaged cord or plug, or if the heater has

malfunctioned, or if the stove has been dropped or damaged in any

manner. Return heater to authorized service facility for examination,

 

6. Do not use outdoors.

7. The stove is not intended for use in bathrooms, laundry areas and similar

indoor locations. Never locate heater where it may fall into a bathtub or

other water container.

8. Do not run the cord under carpeting. Do not cover cord with throw rugs,

 

not be tripped over.

 

outlet.

 

 

heater.

 

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER-SERVICEABLE PARTS INSIDE

manner. Do not use on soft surfaces, like a bed, where openings may

become blocked.

12. All electrical heaters have hot and arching or sparking parts inside. Do not

 

 

13. Do not modify the Stove. Use it only as described in this manual. Any

 

 

14. To reduce the risk of electric shock, this appliance has a polarized plug

 

 

 

outlet. Do not change the plug in any way. Avoid the use of an extension

 

use an extension cord, the cord must be No. 14 AWG minimum size and

rated no less than 1875 Watts.

15. Do not burn wood or other materials in the stove.

16. Do not strike the clear door panel.

 

required.

18. Always use properly grounded, fused and polarized outlets.

 

or relocation of the unit.

20. When transporting or storing the unit and cord, keep in a dry place, free

from excessive vibration and store so as to avoid damage.

SAVE THESE INSTRUCTIONS

!NOTE: Procedures and techniques that are considered important enough

to emphasize.

CAUTION: Procedures and techniques which, if not carefully followed, will

result in damage to the equipment.

WARNING: Procedures and techniques which, if not carefully followed, will

 

!NOTE: This equipment has been tested and found to comply with the

limits for Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

· Reorient or relocate the receiving antenna.

· Increase the separation between the equipment and the receiver.

· Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

· Consult the dealer or an experienced radio/TV technician for help.





interference that may cause undesired operation of the device.

Model and Serial Number Information

If you have any questions about our products please have the model

and serial numbers available upon calling Dimplex customer service.

To locate the model and serial number labels see below igure 1).

Part Number

Serial Number

Figure 1

Model Number

!NOTE: A 15 Amp, 120 Volt circuit is required. A dedicated circuit is

preferred but not essential in all cases. A dedicated circuit will be

required if, after installation, the circuit breaker trips or fuse blows

on a regular basis when the heater is operating. Additional

appliances on the same circuit may exceed the current rating of the

circuit breaker.

WARNING: Ensure the power cord is not installed so that it is

pinched or against a sharp edge and ensure that the power cord

is stored or secured to avoid tripping or snagging to reduce the risk

 

Construction and electrical outlet wiring must comply with local

building codes and other applicable regulations to reduce the risk of

 

Do not attempt to wire your own new outlets or circuits. To reduce

 

licensed electrician.

Stove Installation

1.

operating instruction section).

Plug the unit into a 15 Amp/120 Volt outlet. If the cord does not2.

reach, you may use an extension cord rated for a minimum of 1875

Watts.

Operation

To access the controls go to the back of



A. Three Position On/Off Switch

The switch has two On positions marked with

“-” and “=”. The “-” position is for manual

operation. In this position, the built-in remote

control is bypassed.

The “=” position is for operating the unit with the

provided remote control. When in “=” position the unit is operated with

the ON and OFF buttons of the remote control.

Figure 2 A

B C

When the switch is in the center position the unit is off.

B. Heater On/Off Switch

The Heater On/Off Switch supplies power to the heater fan and the

heater element.

C. Heater Thermostat Control



thermostat control clockwise all the way to turn on the heater. When

the room reached the desired temperature, turn the thermostat knob

counter clockwise until you hear a click. Leave in this position to

maintain the room temperature at this setting. For additional heat, turn

clockwise until you hear the click again and the heater will turn on. To

turn the heater off, switch the Heater On/Off Switch to the Off position.

!NOTE: When the heater is switched On, the heater fan will

operate. The heater element may or may not be on, depending on

 

Resetting The Temperature Cutoff Switch

Should the heater overheat, an automatic cut out will turn the heater

off and it will not come back on without being reset. It can be reset by

switching the Main On/Off Switch to Off and waiting 5 minutes before

switching the unit back on.

CAUTION: If you need to continuously reset the heater, unplug the

 

Remote Control



!NOTE: 

remote control setting.







Battery Replacement

To replace the battery:

1. Slide battery cover

open on the hand held

 

2. Correctly install one

 

the battery holder.

3. Close the batter cover.

Maintenance

WARNING: Disconnect

power before attempting any maintenance or cleaning to reduce the

 

Light Bulb Replacement



bulbs to avoid accidental burning of skin.

Light bulbs need to be replaced when you notice a dark section of





embers.

Tool Requirements: Phillips screw driver

Helpful Hints

It is a good idea to replace all light bulbs at one time if they are close to

the end of their rated life. Group replacement will reduce the number

of times you need to open the unit to replace light bulbs.

Upper Light Bulb Requirements





Upper Bulb Replacement

1. Open door by pulling the handle.

Button

Battery

Cover

OFF

Button

Battery

Figure 3

2. Locate the upper bulb bracket.

Bend light retainer bracket3.

down.

Locate and remove the light4.

bulb.

Insert new bulb.5.

Bend light retainer bracket6.

back into its original position.

Close the door.7.

Lower Light Bulb Requirements



or candelabra bulbs with an E-12



Lower Bulb Replacement

Open door by pulling the handle.1.

Remove the screw from the log set located in the center of the2.

ember bed and remove the log set from the unit.

3.

replacement.

4.

5.

6.

Replace the log set retaining screw into the ember bed.7.

Close the door.8.

Glass Cleaning

The clear door is cleaned in the factory during the assembly operation.

During shipment, installation, handling, etc., the clear door may collect

dust particles, these can be removed by dusting lightly with a clean dry

cloth.



with a damp cloth. The clear door should be completely dried with a

lint free cloth to prevent water spots. To prevent scratching, do not use
