Dimplex BLF7451 Manuel utilisateur
Owner’s Manual
Model
BLF7451
7214000100R03
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this replace. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.
To view the full line of Dimplex products, please visit
www.dimplex.com
2 www.dimplex.com
Table of Contents
Always use a qualied technician or
service agency to repair this replace.
!NOTE: Procedures and
techniques that are considered
important enough to emphasize.
CAUTION: Procedures and
techniques which, if not carefully
followed, will result in damage to
the equipment.
WARNING: Procedures and
techniques which, if not carefully
followed, will expose the user to
the risk of re, serious injury, or
death.
Welcome & Congratulations ...................3
IMPORTANT INSTRUCTIONS .................4
Quick Reference Guide ......................6
Fireplace Installation ........................7
Site Selection ................................. 7
For Bathroom Use .............................. 7
Wiring ....................................... 8
Surface Mount Installation .......................10
Flush Mounted Installation - 2x8 Framing ............12
Front Glass Installation ......................... 13
Operation ................................14
Maintenance ..............................17
Warranty .................................18
Technical Support ..........................20
3
Welcome & Congratulations
Thank you and congratulations for purchasing an electric replace from
Dimplex. Please use our convenient online registration page to record
your model and serial numbers for future reference at
www.dimplex.com/register
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
for Troubleshooting and Technical Support
OR Toll-Free 1-888-346-7539
Please visit our website for operating hours
In order to better serve you, please have your model and serial number
ready or register your product online before calling (See above)
Serial Number
Label Rating Label with
Model Number
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in
a possible electric shock, re hazard and will void the warranty.
4 www.dimplex.com
When using electrical appliances,
basic precautions should always
be followed to reduce the risk of
fire, electric shock, and injury to
persons, including the following:
① Read all instructions before
installing or using this electric
replace.
② This replace is hot when in
use. To avoid burns, do not let
bare skin touch hot surfaces.
The trim around the heater
outlet becomes hot during
heater operation.
DANGER: High temperatures
may be generated under
certain abnormal conditions.
Do not partially or fully cover
or obstruct the front of this
heater.
③Extreme caution is necessary
when any heater is used by
or near children or invalids
and whenever the unit is left
operating and unattended.
④Young children should be
supervised to ensure that they
do not play with the appliance.
IMPORTANT INSTRUCTIONS
⑤ The appliance is not intended
for use by young children
or inrmed persons without
supervision.
⑥Do not operate the unit after
it malfunctions. Disconnect
power at the service panel
and contact Dimplex Technical
Service for service
1-888-346-7539.
⑦ Do not use outdoors.
⑧Never locate replace where it
may fall into a bathtub or other
water container.
⑨ To disconnect the replace,
turn the controls o, then
disconnect the circuit at the
main disconnect panel.
⑩ Do not locate the heater
immediately below a xed
socket-outlet.
⑪Do not insert or allow foreign
objects to enter any ventilation
or exhaust opening as this
may cause an electric shock
or re, or damage to the
heater.
⑫ To prevent a possible fire,
do not block air intakes or
exhaust in any manner.
5
SAVE THESE INSTRUCTIONS
⑬ All electrical heaters have hot
and arcing or sparking parts
inside. Do not use in areas
where gasoline, paint, or
ammable liquids are used or
stored.
⑭Use this heater only as
described in this manual. Any
other use not recommended
by the manufacturer may
cause re, electric shock or
injury to persons.
⑮Do not burn wood or other
materials in the electric
replace.
⑯ Do not strike the replace
glass.
⑰ Always use a certied
electrician should new circuits
or outlets be required.
⑱ Disconnect all power supply
before performing any
cleaning, maintenance or
relocation of the unit.
⑲When transporting or storing
the unit and cord, keep in a
dry place, free from excessive
vibration and store so as to
avoid damage.
WARNING: Remote control
contains small batteries.
Keep away from children.
If swallowed, seek medical
attention immediately.
WARNING: Do not install
battery backwards, charge, put
in re or mix with used or other
battery types - may explode or
leak causing injury.
!NOTE: Changes or
modications not expressly
approved by the party
responsible for compliance
could void user's authority to
operate the equipment.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICABLE PARTS INSIDE
IMPORTANTINSTRUCTIONS
6 www.dimplex.com
Quick Reference Guide
Figure 1
1. The electrical information
regarding your electric replace
can be found on the rating label
located on the front of the unit,
behind the glass.
Please use our convenient online
registration page to record your
model and serial numbers for future
reference at
www.dimplex.com/register
2. If you have any technical
questions or concerns regarding
the operation of your electric
replace, or require service
contact customer service at
1-888-346-7539.
3. For dimensions of your replace,
refer to Figure 1.
[7.1 in.]
467 mm
[18.4 in.]
1883 mm [74.1 in.]
493 mm
[19.4 in.]
187 mm
[7.3 in.]
1844 mm [72.6 in.]
7
Site Selection
Review and consider all of the
following conditions before installation:
• Dimensions of the unit: 74.1 in.
(1883 mm) x 19.4 in. (494 mm)
• For surface installation, the unit
requires a minimum of 2 wall
studs in order to ensure secure
installation. For other installation
methods, suitable framing is
required.
There are two possible mounting
methods:
• Surface mount (pg. 10);
• Flush mount (pg. 11).
WARNING:
The top of the
replace is to be installed at least
4" (10.2 cm) from the ceiling.
CAUTION: Ensure installation
does not allow replace to be in
direct contact with building vapor
barrier or insulation and meets all
local building code.
!NOTE: A dedicated, properly
fused 15 Amp circuit is required,
rated for the appropriate voltage
(120V, 240V).
WARNING: Construction and
electrical outlet wiring must
comply with local building codes
and other applicable regulations
to reduce the risk of re, electric
shock and injury to persons.
Fireplace Installation
WARNING: To reduce the risk of
re, do not store or use gasoline
or other ammable vapors or
liquids in the vicinity of the heater.
1. Select a location that is not
susceptible to moisture and is
away from drapes, furniture and
high trac.
2. Unpack the replace, front glass
and hardware from the box and
remove all packaging materials
before installation.
3. Store the replace in a safe, dry
and dust free location until you
are ready to install the replace.
For Bathroom Use
If this unit is installed in a bathroom
it must be protected by a GFI
receptacle or circuit. If receptacle is
used it must be readily accessible.
To prevent electrical shock this unit
is an electrical appliance that is NOT
watertight and must be installed as to
prevent water from entering unit. This
must be installed away from showers,
tubs, etc. Never locate replace
where it may fall into a bathtub or
other water container.
8 www.dimplex.com
Fireplace Installation
Wiring
WARNING: To reduce the risk
of re, electric shock or injury to
persons, always use a licensed
electrician.
WARNING: Ensure that the circuit
on which the replace is to be
installed has the power cut o at
the service panel until installation
is complete.
1. Carefully remove the electrical
cover bracket from the back of the
replace by removing the three
retaining screws. (Figure 2)
2. Leaving a minimum of 3 in. (7.6
cm) of slack, route the power
supply through a cable clamp
(not included) and the hole in the
electrical cover bracket.
3. Remove the two covers o of the
unit at the front to access the wire
connections. (Figure 3)
Wiring Diagram
AC/DC
ADAPTER
RELAY BOARD
SWITCH BOARD
DISPLAY / CONTROL BOARD
THERMISTOR
LED STRIPS
(RGB) - MEDIA
FLAME LED STRIPS (AMBER)
CUTOUT
THERMAL
FLICKER MOTOR
BLOWER MOTOR
LED STRIPS
(RGB) - FLAME
M
M
ELEMENTS
LED DRIVER
BOARDS
Figure 2
Screws
Electrical Cover Bracket
9
Fireplace Installation
For 120V Installations
Use two conductor, non-metallic
sheath cable with ground wire (3
wires total) for the incoming power
supply.
CAUTION: Use the appropriate
wire to meet local and national
electrical codes for rated power
consumption.
• Connect the L1 wire from the unit
to the live wire from the power
supply.
• Connect the N and H1 wires from
the unit to the neutral wire from
the power supply.
• Connect the L2 and H2 wires
together, with a wire connector
and leave them disconnected
from everything.
• Attach the grounding wire to
the cover with the provided
grounding screw. Place wire in-
between screw and lock washer
and tighten (Figure 4).
• Reposition the electrical cover
brackets over the wires and
connectors and attach to
replace chassis using the screw
removed in step 1 and step 3.
Figure 4
Hole for
Ground Screw
Figure 3
10 www.dimplex.com
Fireplace Installation
For 240V Installations
Use three conductor, non-metallic
sheath cable with ground wire (4
wires total) for the incoming power
supply on replace inserts.
CAUTION: Use the appropriate
wire to meet local and national
electrical codes for rated power
consumption.
• Connect the L1 wire from the unit
to the L1 wire from the power
supply.
• Connect the L2 wire from the unit
to the L2 wire from the power
supply.
• Connect the N wire from the unit
to the neutral wire from the power
supply.
• Connect the H1 and H2 wires
together, with a wire connector
and leave them disconnected
from everything.
• Attach the grounding wire to
the cover with the provided
grounding screw. Place wire in-
between screw and lock washer
and tighten (Figure 4).
• Reposition the electrical cover
brackets over the wires and
connectors and attach to
replace chassis using the screw
removed in step 1 and step 3.
Surface Mount Installation
CAUTION: Two people will be
required for various steps of this
procedure.
WARNING: Ensure that the circuit
on which the replace is to be
installed has the power cut o at
the service panel until installation
is complete.
1. Determine the mounting location
of the unit so that the wall-
mounting bracket can be installed
into 3 wall studs.
!NOTE: It is recommended that
the mounting bracket be installed
56 in. (142 cm) o of the ground
to maintain an optimized viewing
angle of the ame.
2. Hold the wall mounting bracket,
with the bubble level on the top,
on the wall so that the bubble on
the level is centered between the
two black lines.
3. Mark the 4 mounting screw
locations, on the wall, ensuring
that the wall bracket stays level.
(Figure 5)
4. In locations where the screws are
being installed only into drywall,
install the supplied wall anchors
before installing the screw (predrill
if required).
Autres manuels pour BLF7451
2
Table des matières
Langues :
Autres manuels Dimplex Cheminée intérieure
Dimplex
Dimplex ELECTRALOG DF203A Manuel utilisateur
Dimplex
Dimplex VF5452L Manuel utilisateur
Dimplex
Dimplex Auvergne Log 2920 Manuel utilisateur
Dimplex
Dimplex WTN20-AU Manuel utilisateur
Dimplex
Dimplex VCX1525 Manuel utilisateur
Dimplex
Dimplex DWF1203 Manuel utilisateur
Dimplex
Dimplex THWG XLF50 Manuel utilisateur
Dimplex
Dimplex BLF50-EU Manuel utilisateur
Dimplex
Dimplex DFP6975O Manuel utilisateur
Dimplex
Dimplex PF2325 Manuel utilisateur
Dimplex
Dimplex RLG20 Manuel utilisateur
Dimplex
Dimplex Chalbury Fire CHB20BR Manuel utilisateur
Dimplex
Dimplex CHADWICK CDW15XHD Manuel utilisateur
Dimplex
Dimplex CHERITON LOG Manuel utilisateur
Dimplex
Dimplex KTN20-AU Manuel utilisateur
Dimplex
Dimplex STOCKBRIDGE SKG20BL Manuel utilisateur
Dimplex
Dimplex COMPACT FIREPLACE Manuel utilisateur
Dimplex
Dimplex OS2527GB Manuel utilisateur
Dimplex
Dimplex Indoor Fireplace Manuel utilisateur
Dimplex
Dimplex DF2624L Manuel utilisateur
