Dimplex DHCERA20E Manuel utilisateur

For domestic household use only.

INSTRUCTION MANUAL

2kW DC Ceramic Tower Heater -

Electronic Controls

Model: DHCERA20E

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR

FUTURE REFERENCE. Note also the information presented on the appliance

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/

OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY

Please read the operating instructions carefully before using your product for

the rst time and keep them in a safe place.

• When using electrical appliances, basic precautions should always be followed

to reduce the risk of re, electrical shock and injury to persons, including the

following:

• If the appliance is damaged, check with the supplier before installation and

operation.

- Do not use outdoors.

- Do not use in the immediate surroundings of a bath, shower or a

swimming pool.

- Do not use this heater if it has been dropped.

- Do not use if there are visible signs of damage to the heater.

- Use this heater on a horizontal and stable surface, or x it to the

wall, as applicable.

• Do not locate the appliance immediately below a xed socket outlet or

connection box.

• This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the

appliance.

• Do not use this appliance in series with a thermal control, a program controller,

a timer or any other device that switches on the heat automatically, since a

re risk exists when the appliance is accidentally covered or dis-placed.

• In the event of a fault, unplug the appliance.

• Unplug the appliance when not required for long periods.

• This product is only intended for INDOOR RESIDENTIAL applications only.

• DO NOT cover cord with carpeting, throw rugs, runners, or similar coverings.

• DO NOT route cord under furniture or appliances. Take care to position the

cord away from trac areas and where it will not be a tripping hazard.

• This appliance must not be used in a bathroom.

• Although this appliance complies with safety standards,we do not recommend

its use on deep pile carpets or on long hair type of rugs

• The appliance must be positioned so that the plug is accessible.

• If the supply cord is damaged it must be replaced by the manufacturer or

service agent or a similarly qualied person in order to avoid a hazard.

• Keep the supply cord away from the front of the appliance.

• Do not use this heater in small rooms when they are occupied by persons

not capable of leaving the room on their own, unless constant supervision is

provided.

• To reduce the risk of re, keep textiles, curtains and or ammable material a

minimum distance of 1m from the air outlet.

• In order to avoid overheating, DO NOT COVER the appliance. Do not place

material or garments on the appliance, or obstruct the air circulation around

the appliance, for instance by curtains or furniture, as this could cause

overheating and a re risk.

• In order to avoid a hazard due to inadvertent resetting of the thermal cut-out,

this appliance must not be supplied through an external switching device,

such as a timer, or connected to a circuit that is regularly switched on and o

by the utility.

• Some parts of this product can become very hot and cause burns. Particular

attention has to be given where children and vulnerable people are present.

WARNING - KEEP BATTERIES OUT OF REACH OF CHILDREN

• Swallowing may lead to serious injury in as little as 2 hours or death, due to

chemical burns and potential perforation of the oesophagus.

• Ifyoususpectyourchild has swallowedorinserteda buttonbatteryimmediately

call the 24-hour Poisons Information Centre on 13 11 26 (in Australia) or 0800

764 766 (in New Zealand) for fast, expert advice.

• Examine devices and make sure the battery compartment is correctly secured,

e.g. that the screw or other mechanical fastener is tightened. Do not use if the

compartment is not secure.

• Dispose of used button batteries immediately and safely. Flat batteries can

still be dangerous.

Exposed to the

weather outdoors

Near water If the power cable

wires are frayed or cut

Where small children

may be left unattended

If an extension

lead may become

overloaded

Where there is risk

of re or close to

a naked ame

Where the power

cable may be

damaged

On a slope or

uneven surface

Where it may be

damaged by

chemicals

If there is a risk

of water falling on

the unit

Where there is a risk

of interference by

foreign objects

This product is not

made for DIY repair

Model no. DHCERA20E

Power supply

220-240V~, 50Hz

Rated power

2000W

Heat settings

2 + fan

Thermostat 10-35°C

Timer 0-12hrs

Oscillation 45°

Weight (net) 2.5kg

Dimensions (w x d x h) 150 x 150 x 510mm

Specications

For greater precision, please always refer to the rating label placed on the product.

Parts

Air outlet

Control panel

Air inlet

Power cord

Power switch

Carry handle

Remote

Control Panel

Safety Features

This appliance incorporates a number of safety devices. In addition to the ‘Important

Safety Advice’ section your attention is drawn to the following;

Tilt Switch

The tilt switch will prevent the heater from working if it is accidentally tipped over on

its side.

If the radiator is tipped over while it is hot, disconnect the power and allow it to cool,

then stand the radiator back upright. Reconnect the power - normal operation should

be resumed.

Overheat Protection

The heater is tted with a temperature limiter which will turn OFF the heater should it

overheat for any reason. The product will return to normal operation after the cause

of the overheating has been rectied.

Oscillation

Decrease

Increase

Timer

Fan only

On/O

Power

High power

Low power LED display

Operation

IMPORTANT - OBJECTS OR CLOTHING MUST NOT BE PLACED ON THIS

HEATER.

Before using the heater ensure that all warnings and instructions have been

read carefully. To begin using the heater simply plug it in to a corresponding

power outlet.

1. Turn on the main power switch at the back of the unit to the 'I' position.

The unit will beep once to indicate it is powered and in standby mode. The

LED display will illuminate and indicate the current room temperature.

2. Press the On/O button to turn the unit ON.

3. Press the POWER button once to operate in low power (1200W) or twice

to operate in high power (2000W). The corresponding low and high power

indicator light will illuminate on the control panel.

4. A TIMER can be set up to 12 hours, so the unit turns OFF automatically

after a set period. Press the TIMER button and cycle through, in 1 hour

increments, the desired time. The set time will ash on the LED Display. To

cancel the TIMER, cycle through until '0' shows on the display.

5. To adjust the room temperature, set the desired temperature between

10-35°C. The temperature is set in 1°C increments and will ash on the

LED display until selected. The unit will automatically work to reach and

maintain the set temperature,

6. The unit is equipped with an oscillating base. To activate, press the

OSCILLATION button. Press again to cancel.

7. Press the power On/O button to turn the unit OFF. It takes approx. 30

seconds for the unit to power OFF, this is to protect the heating element.

8. If the unit isn't being used for an extended period of time, switch the main

power switch to '0' (after the unit has turned OFF completely which takes

approx. 30-60 seconds).

Remote Control

The remote control performs the same settings as the control panel on the

unit. Simply follow the same operation instructions mentioned previously.

The remote requires 1 x CR2025 3v lithium battery.

1. Open the battery compartment Fig. 1

2. Insert the battery into the remote control compartment.

3. Close the battery compartment.

Fig. 1

Cleaning

Over time, dust can accumulate on the heater which can eect performance.

It is recommended to clean the unit at least once a month.

1. Turn the unit OFF and disconnect the appliance from the power supply.

2. Remove any dust build up with a soft brush.

3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can be

used for any stubborn marks.

IMPORTANT

The control panel and other parts must not come into contact with water or

any other liquids.

Storage

If not using the unit for an extended period of time. After cleaning please:

• Ensure control switch is OFF and remove plug from the power outlet.

• Cover the unit and store it upright in a location where it will not receive direct

sunlight. NB- Prolonged exposure to direct sunlight will discolour the unit.
