Dimplex DLGM29 Manuel utilisateur

Owner’s Manual

Model

DLGM29

7212240100R02

IMPORTANT SAFETY INFORMATION: Always read this manual rst

before attempting to install or use the log grate. For your safety, always

comply with all warnings and safety instructions contained in this

manual to prevent personal injury or property damage.

To view the full line of Dimplex products, please visit

www.dimplex.com

2 www.dimplex.com

Table of Contents

Always use a qualied technician

or service agency to repair

this Log Grate.

!NOTE: Procedures and

techniques that are considered

important enough to

emphasize.

CAUTION: Procedures and

techniques which, if not

carefully followed, will result in

damage to the equipment.

WARNING: Procedures

and techniques which, if not

carefully followed, will expose

the user to the risk of re,

serious injury, or death.

Welcome & Congratulations....................3

IMPORTANT INSTRUCTIONS ..................4

Site Selection and Preparation ..................7

Log Grate Assembly ..........................9

Log Grate Installation ........................14

Operation..................................15

Maintenance...............................17

Warranty .................................18

ReplacementParts..........................20

Welcome & Congratulations

Thank you and congratulations for choosing to purchase an Log Grate

from Dimplex, the world leader in electric replaces.

Please carefully read and save these instructions.

CAUTION: Read all instructions and warnings carefully before

starting installation. Failure to follow these instructions may result in a

possible electric shock, re hazard and will void the warranty.

Please record your model and serial numbers below for future

reference: model and serial numbers can be found on the Model and

Serial Number Label of your Log Grate.

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)

Monday to Friday 8:00 a.m. to 4:30 p.m. EST

Please have your model number and product serial

number ready. (See above)

Model Number

Serial Number

4 www.dimplex.com

When using electrical appliances,

basic precautions should always

be followed to reduce the risk of

fire, electric shock, and injury to

persons, including the following:

①Read all instructions before

using the Log Grate.

② Always unplug the Log Grate

when not in use.

③ Do not operate any unit with

a damaged cord or plug, or if the

Log Grate has been dropped or

damaged in any manner. Return

unit to authorized service facility

for examination, electrical or

mechanical adjustment, or repair.

④ Do not use outdoors.

⑤ The Log Grate is not intended

for use in bathrooms, laundry

areas and similar indoor

locations. Never locate unit where

it may fall into a bathtub or other

water container.

⑥ Do not run the cord under

carpeting. Do not cover cord with

throw rugs, runners, or the like.

Arrange cord away from trafc

area and where it will not be

tripped over.

⑦ To disconnect the unit, turn the

controls off, then remove the plug

IMPORTANT INSTRUCTIONS

from the outlet.

⑧ Do not block air intake or

exhaust in any manner.

⑨ Do not use on soft surfaces,

like a bed.

⑩ Do not modify the Log Grate.

Use it only as described in

this manual. Any other use

not recommended by the

manufacturer may cause re,

electric shock or injury to persons.

⑪ Do not burn wood or other

materials in the Log Grate.

⑫ Always use a certied

electrician should new circuits or

outlets be required.

⑬ Always use properly grounded,

fused and polarized outlets.

⑭ Disconnect the power supply

before performing any cleaning,

maintenance or relocation of the

unit.

⑮ When transporting or storing

the unit and cord, keep in a

dry place, free from excessive

vibration and store so as to avoid

damage.

⑯ The Log Grate must not be

located directly below a socket

outlet.

SAVE THESE INSTRUCTIONS

⑰ The Log Grate must be

positioned so that the plug is

accessible.

WARNING: Remote control

contains small batteries.

Keep away from children. If

swallowed, seek medical attention

immediately.

WARNING: Do not install

battery backwards, charge, put

in re or mix with used or other

battery types - may explode or

leak causing injury.

!NOTE: Changes or

modications not expressly

approved by the party responsible

for compliance could void

user's authority to operate the

equipment.

IMPORTANT INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER-SERVICEABLE PARTS INSIDE

6 www.dimplex.com

CAUTION: This equipment has

been tested and found to comply with

the limits for Class B digital device,

pursuant to part 15 of the FCC

Rules. These limits are designed to

provide reasonable protection against

harmful interference in a residential

installation. This equipment

generates, uses and can radiate

radio frequency energy and, if not

installed and used in accordance with

the instructions, may cause harmful

interference to radio or television

reception, which can be determined

by turning the equipment off and

on, the user is encouraged to try to

correct the interference by one or

more of the following measures:

Reorient or relocate the receiving•

antenna.

Increase the separation between•

the equipment and the receiver.

Connect the equipment into an•

outlet on a circuit different from

that to which the receiver is

connected.

Consult the dealer or an•

experienced radio/TV technician

for help.

Operation is subject to the following

two conditions: (1) this device may

not cause interference and (2) this

device must accept any interference,

including interference that may cause

undesired operation of the device.

IMPORTANT INSTRUCTIONS

WARNING: Ensure the power

cord is not installed so that it is

pinched or against a sharp edge

and ensure that the power cord is

stored or secured to avoid tripping

or snagging to reduce the risk

of re, electric shock or injury to

persons.

Construction and electrical

outlet wiring must comply with

local building codes and other

applicable regulations to reduce

the risk of re, electric shock and

injury to persons.

Do not attempt to wire your own

new outlets or circuits. To reduce

the risk of re, electric shock or

injury to persons, always use a

licensed electrician.

Site Selection and Preparation

This section provides instructions

for selecting a location and

preparing the site to install the

Log Grate.

Select a suitable location1.

that ensures the Log Grate is

sitting on a hard level surface

for optimum ame effect.

Allow for approximately 2"2.

(5.1cm) of clearance behind

the unit (from the frame to

the back of mantel) and 7"

(17.8cm) directly above the

back log to allow for removal

of the Rell Container.

Carefully unpack all of the3.

components from the box.

CAUTION: Handle logs carefully,

they are fragile and can easily crack

or break, if dropped.

8 www.dimplex.com

Site Selection and Preparation

Figure 1

Transducer

Wire Slots

Emitter

Unpack the transducer4.

(contained within the water

reservoir) which has been

wrapped to protect it during

shipping. See Figure 1.

To access the transducer:

Remove top cover by turning•

the retaining tabs on both

ends of the water reservoir.

Remove any packing•

material.

Install transducer so that it•

is sitting level in the circular

holding area in the Reservoir.

Retaining

Tabs

Removable Rell

Container

Water

Reservoir

Orient transducer wire so that•

it does not sit directly above

the Emitter and the wire

passes through the slot in the

side of the tank.

Reinstall the top cover and•

ensure both retaining tabs

have been turned so that

they are pointing inwards.

!NOTE: Completely assemble

the unit before lling with water.

Top Cover

Log Grate Assembly

CAUTION: Handle logs

carefully, they are fragile and

can easily crack or break, if

dropped.

10 www.dimplex.com

Hook and

Loop Pads

Wire Connectors

Log Grate Assembly

Each log is a separate component

that needs to be placed on the

grate. Position each log so that

the hook and loop pad on the

backside of the log lines up with

the corresponding hook and loop

pad on the log grate. These pads

assist with securing the logs to

the grate.

!NOTE: Each of these logs

are hand made, and as such, the

hook and loop pads on the logs

and grate may not align perfectly,

therefore, we have included

additional pads should you need

to re-position them.

Each of the logs contain LED

lights to create a ickering effect.

During assembly, each log

requires the electrical connectors

on the log and grate to be

connected as they are being

placed. In some cases, these

wires can have tie wraps added to

prevent the wires from being seen

after nal assembly, not included.
