DIGMA FreeDrive 105 Manuel utilisateur
USER MANUAL/ BEDIENUNGSANLEITUNG/ РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
Dashcam/ Autokamera/ Видеорегистратор
FreeDrive 105
EN
CONTENTS
Precautions
Specications
Component parts
Controls
Buttons and connectors
Video Recording Mode
Photo Mode
Playback Mode
System settings (common)
Additional button functions
Troubleshooting
Thank you for purchasing a DIGMA product!
A dashcam is a device that records, stores, and plays video information.
Before using this device, please read through this manual to ensure the product is used correctly and
to prevent it from damage.
The soware, the device’s design features, and the content of this User Manual may change without
prior notice for product improvement reasons.
The manufacturer and distributors of this product shall not be responsible for any damage to the
device’s body or for any damage due to improper or inappropriate use by the user.
PRECAUTIONS
1. Install this device correctly. Do not install the product in a location where it can interfere with the
eld of vision of the driver or the system. This may cause the device to fail, or you may suer an injury.
2. Do not install the device near any magnetic eld sources that may damage the equipment.
3. Do not switch o the device while using or when formatting it. Do not insert or remove the TF card.
This may cause damage to the TF card or result in program malfunction.
4. The product’s TF card shall not be used for storing other les. Before using the product, please
format TF card in the device and make back up copies of video recordings and images.
5. To avoid electric shock, do not insert/pull out the cable with wet hands.
6. Do not use the product in temperatures above 60 °С or below 10 °С. Do not install the product in
environments with high humidity.
7. The charging device and accessories suitable for this device should be used.
8. Use TF cards up to 32 GB.
SPECIFICATIONS:
Screen: 1.5"LCD 480x240
Processor: JL (AC5202B)
Sensor: GC1064 | 1.3 megapixels
Lens: Wide angle | 140° viewing angle
Video: 1920х1088 (30 f/s), 1280х720 (30 f/s), 640х480 (30 f/s)
Video format: AVI (MJPG)
Photo format: JPG
Supported photo resolution: 1920х1088, 1600х912, 1280х720
G-sensor (automatic le locking when an accident occurs)
Memory Card: TF-card (supports up to 32 GB)
Microphone/Speaker: in-built
Languages: German/English/Russian
Built-in chargeable Li-ion battery: 110 mAh
Charging device cable length: 3.5 m
Device dimensions: 67 х 44 х 32 mm
Device mass: 38 g
COMPONENT PARTS
• FreeDrive Dashcam 105
• Vehicle windshield mount
• USB cable
• Charging device (mini-USB connector)
• User manual
INTERFACE
1. Up
2. Menu
3. Down
4. Mini-USB port
5. Lens
6. Speaker
7. ОК
8. Mode/Locking
9. POWER (On/O)
10. Screen
11. TF card slot
12. Connection for holder
13. MIC (Microphone)
14. RESET
15. Infrared lamp
BUTTONS AND CONNECTORS
1. UP button
Menu navigation button Up.
2. Operation mode indicator
The red indicator is for power supply and battery charging, the blue indicator displays the dashcam
operation mode. The red indicator is on when the internal battery is charging. The indicator goes o
when the battery is fully charged. The indicator ashes during recording. When the recoding stops,
the blue indicator goes o.
3. MENU button
Settings menu button. Each dashcam mode (video, photo, playback) has two settings menu tabs. The
rst tab is for customized settings for the current mode. The second tab is for system settings, which
are the same for all three modes. Therefore, common system options can be set from any of the three
modes. And customized settings for one mode can only be set from the corresponding mode.
Stop the video recording to enter the settings menu. Briey press the MENU button. The list of menu
items for all three modes is provided below:
Video Recording Mode -> Video Recording Mode Settings:
Video resolution: video resolution settings in video recording mode.
Available values: 1920х1088 (30 f/s), 1280х720 (30 f/s), 640х480 (30 f/s)
Loop recording: duration of recorded video les. Values: O, 1 min, 3 min, 5 min When O is selected,
the recording will be made into one le until the memory is full, then the recording will stop. When
selecting one of the time values, the recording will be made into les of specied length. When the
memory is full, new les will be recorded over the oldest ones.
Exposure: manual adjustment of sensor light sensitivity. Values: -2.0, -5/3, -4/3, -1.0, -2/3, -1/3 0.0,
+1/3, +2/3, +1.0, +4/3, +5/3, +2.0.
Motion detector: motion detector function on/o: the dashcam will automatically start video
recording when it detects motion. The recording lasts 30 seconds, then the dashcam switches to
standby mode until the next motion is detected. Values: ON/OFF
Microphone: sound recording on/o during video recording. Values: ON/OFF
Stamp: switch on/o the date/time stamp—video recording date and time information overlay on the
video image. Values: ON/OFF
G-sensor tracks changes in acceleration, both positive and negative (hard braking or hard
acceleration), thereby automatically identifying incidents and marking the current video le Read_
Only, which prevents it from being overwritten.* Values for sensor sensitivity settings: O, High (2G),
Medium (4G), Low (8G).
* If les are locked from being overwritten, or if the G-sensor is switched on with the wrong sensitivity
settings, the memory card may become full, and the dashcam will be unable to continue recording
video. If this happens, clear the memory card to continue normal operations.
Photo mode -> Photo mode settings:
Photo mode: photo mode selection: single photo or timer photo. Values: Single, 2 s, 5 s, 10 s.
Photo resolution: photo resolution settings in photo mode. Values: 2 MP (1920х1088), 1.5 MP
(1600х912), 0.9 MP (1280х720)
Series: Burst mode. When the OK button is pressed, the device automatically takes ve photos.
Values: ON/OFF
White balance: adjustment of the image color gamut when taking photos, depending on dierent
types of lighting source. Values: Auto Balance, Sunny, Gloomy, Tungsten, Fluorescent.
Stamp: switch on/o the date/time stamp—video recording date and time information overlay on
image. Values: Date, Date/Time
Playback Mode -> Playback mode menu:
Delete: delete previously recorded video and photo les. Values: Delete one, Delete all.
Protection: enable/disable protection from overwriting for one or several les.
Values: Protect One, Disable One, Protect All, Disable All.
System settings (common):
Date/Time: Time/Date settings.
Auto shuto: The dashcam automatically switches o aer a set time when it is inactive. Values: O, 1 min, 3 min.
Button Sound: Sound when buttons are pressed. Values: ON/OFF
Language: System language selection. Values: German/English/Russian
Frequency: power frequency of lighting devices. This parameter can be used to stop ickering that
occurs during video shooting under articial lighting. Values: 50 Hz, 60 Hz.
Screen: The screen switches o aer a set time of inactivity. When the screen switches o, the
dashcam continues in the state it was before the screen switched o. Values: O, 3 min, 5 min, 10 min.
Car license plate number: enter the car license plate number. This information may be included to be
displayed as a stamp on video and photo les.
Formatting: MicroSD card formatting. All information will be deleted from the card.
Reset settings: reset all settings to factory settings (by default).
Soware version: Displays the dashcam’s embedded soware version.
4. Down button
Menu navigation button down.
5. MiniUSB interface
Connector for external power supply (included) or PC. When external power is available on this connector, the dashcam
will switch on automatically and, if an SD card is inserted, will begin video recording. During recording, when external
power is not available on this connector, the dashcam will automatically stop recording and switch off.
When connecting to a PC, the mode selection menu will appear on the screen: Camera, Storage.
• Camera: in this mode the dashcam operates as web camera.
• Storage: in this mode, you can manage the les on the SD card inserted in the dashcam using a PC:
copying, transferring, deleting.
6. ОК button
Button for conrming a menu selection. Start/Stop recording in Video mode. Take a photo in Photo mode.
7. Mode button
Dashcam mode switching button. When the button is briey pressed, the dashcam will switch to one
of the following operation modes: Video -> Photo -> Playback. When this button is briey pressed in
video recording mode, the current le will be protected from being overwritten: when the button is
pressed, the closed lock icon will appear on the screen. File protection can be disabled later in the
playback menu (Playback Mode).
8. Power button
When external power is available on connector 5, the dashcam will switch on automatically and, if an
SD card is inserted, will begin video recording. However, the dashcam can be switched on/o manually
using the Power button. Briey press the Power button to switch the dashcam on. Press and hold the
Power button to switch the dashcam o. During video recording, briey press the button to switch on
infrared lighting. When the button is pressed again, the infrared lighting switches o.
9. MicroSD card slot
Slot for a microSD card. Please make sure you insert the card into the slot the right way up. If the card
is inserted the wrong way, it may damage the device and card. When a card is inserted into device, it will
be dened as the main data storage device: all previously recorded information on the card could be lost.
Please use high speed cards with recording class 6 or higher.
