FIREWIRE 800,

PCI EXPRESS ADD-ON CARD

User Manual

DS-30203-2

Features and Benefits

Provides three FireWire 800 (1394b) ports for connecting

multiple 1394b devices

Supports data transfer rates of 100, 200, 400 and 800 Mbps

Built-in 4-pin power connector provides extra power when

connected to the system’s power supply (recommended)

Supports Hot-Swap and Plug & Play connection of peripheral

devices

Works with various types of FireWire 800 (1394b) devices

including portable hard disk, DV camcorder, digital camera,

CD-RW/DVD-ROM drive and other audio/video devices

Support Windows® 2000/XP/Server 2003 / Vista / Win 7

System Requirements

Windows®2000/XP/Server 2003 / Vista / Win 7

PCI Express-enabled system with an available PCI Express slot

Package Contents

1 x PCIe FireWire 800 Card (2+1) Ports

1 x User Manual

1 x Support CD

Optional Accessories

IEEE 1394b cable

Board Layout

Hardware Installation

1. Turn Off the power of your computer.

2. Unplug the power cord and remove the computer’s cover.

3. Remove the slot bracket from an available PCIe slot.

4. To install the card, carefully align the card’s bus connector with

the selected PCIe slot on the motherboard. Push the board down

firmly.

5. Connect the system power source to the board’s power connector.

6. Replace the slot bracket’s holding screw to secure the card.

7. Replace the computer cover and re-connect the power cord.

Driver Installation

Please make sure, that the board is installed, before proceeding with

driver installation.

Important: If your system doesn’t boot to Windows properly with our

card installed, check with your system’s manufacturer for the latest

system firmware update.

For Windows® 2000/XP/Server 2003/ Vista/Win 7

Note: Server 2003 Server Pack 1, or above is required to install

the FireWire 800 Card 2+1 Ports successfully.

Windows®2000/XP/Server 2003 SP1/Vista/Win 7 will automatically

detect and install the correct driver for the FireWire 800 Card 2+1

Ports.

To Verify Windows Installation

Via Right Click you get to My Computer. Then click Manage, Device

Manager. The Device Manager window opens. Scroll to the IEEE

1394 Bus host controllers icon and click on the plus symbol - the

Texas Instruments OHCI Compliant IEEE 1394 Host Controller

should be displayed.
