Digital Information Preproofer 940 Manuel utilisateur
Preproofer
740/780/940/980
A
capulco Version
Installation manual
Digital Information Ltd.
Technoparkstrasse 1
CH-8005 Zürich
© Copyright by Digital Information Ltd. 2006
This manual is proprietry in nature and the sole property of Digital
Information. It may not be reproduced, in whole or in part, without
the express written permission of Digital Information. Digital
Information reserves the right to modify and/or delete any material
and/or capabilities described herein.
All the documentation in this manual is instructional and for the
operation of Preproofer machine. Digital Information shall not be
responsible for any damage or claims resulting from any errors or
omissions in this manual.
Owning to our policy of continous product development,
specifications, terms and description of Preproofer 940/980 are
subject to change without prior notice.
.
Identifier Hardware Installation manual - EN
Target group Installation, Technician
Product Preproofer Acapulco 740/780/940/980
Version V1.30
Article code Preproofer IM7498-012 EN
Table of contents
Preproofer –HW Installation manual I
.
Table of contents
1Introduction ............................................................................................................... 1-1
2Safety ...................................................................................................................... 2-1
2.1 Warning............................................................................................................................................ 2-1
3Tools and Materials required for the Installation.................................................................... 3-2
3.1 Tools required fort he Installation ...................................................................................................... 3-2
3.2 Materials required for the Installation ................................................................................................ 3-2
3.3 Unpacking the Boxes ....................................................................................................................... 3-2
4Assemble the System.................................................................................................... 4-1
4.1 Overview .......................................................................................................................................... 4-1
4.2 Installation Steps .............................................................................................................................. 4-3
5Function test .............................................................................................................. 5-1
Introduction
Warning 1
Preproofer –HW Installation manual 1-1
.
1Introduction
The Preproofer 940/980 is a fully automatic system printing double-sided proofs in 8up format. The system is
based on two Epson Stylus 9400/9800 printing engines, enabling print widths of 111cm (44”).
The Preproofer 740/780 is a fully automatic system printing double-sided proofs in 4up format. The system is
based on two Epson Stylus 7400/7800 printing engines, enabling print widths of 61cm (24”).
Please note:
Installation of this equipment must be done by a trained technician.
Do NOT leave Epson Printers on the stand without securing them with the Printer locking devices.
Safety
Warning 2
Preproofer –HW Installation manual 2-1
.
2Safety
This section provides important safety information and must be read before switching on or operating
the equipment.
2.1 Warning
All precautions mentioned in this document must be strictly observed at all times. Personnel MUST therefore
read the contents of the document BEFORE commencing any work on the equipment described in the
document.
Improper use of controls and switches, failure to comply with warnings, and the performance of adjustments or
procedures not specified in this document may expose personnel to danger.
Installation of this equipment must be done by a trained technician.
Do NOT leave Epson Printers on the stand without securing them with the Printer locking devices.
3 Tools and Materials required for the Installation
Tools required fort he Installation
3-2 Preproofer –HW Installation manual
.
3Tools and Materials required for the Installation
3.1 Tools required fort he Installation
•Standard Screwdriver set
•Allen keys set
•Set of spanners 10-15 mm
•Phillips Screw driver set
•Measurement Tape
•Cordless drill to unpack the boxes
•wrench
3.2 Materials required for the Installation
•Local Power cord (not supplied)
•Ethernet cable to connect the ShuffleBox the PC (not supplied)
3.3 Unpacking the Boxes
Make sure the following parts are available, after unpacking the cases:
Large case:
•2 side Legs
•2 Shelves
•2 or 3 Cross beams
•2 side media guides for roll media
•Power supply with international plug
•Software package with hardware dongle
•Bag if screws, rectangular End plugs, circular end plugs, Printer locking devices
Small case:
•Curver
•1 anti-curling device + rod
•Upper media deflector
•ShuffleBox + Control panel wires + Y-motor wires
2 Step ladder
All packaged items must be inspected at the customer's site before unpacking begins. The following steps are
taken when there has been damage:
1.) Record the observations on the delivery documentation.
2.) Inform the carrier, shipping agent and insurance agent.
Units may be removed from their box only by an approved engineer or representative. Do not proceed with
unpacking when there has been a damage report until authorized by the shipping and insurance agents.
Assemble the System
Overview 4
Preproofer –HW Installation manual 4-1
.
4Assemble the System
Assemble the stand as described below. If the stand
comes pre-mounted, please skip this section.
4.1 Overview
Once assembled, the stand should look as:
Front View
Back View
4 Assemble the System
Overview
4-2 Preproofer –HW Installation manual
.
T
he parts positions as shown below:
20x M8 Bolts, 20x M8 washers, 20x M8 Nuts
3 Cross Beams, 2 shelves, 2 side legs
