DG-SC8860VI
Megapixel Vandal Proof Fixed Dome IP Camera with IR
LED, IR Cut Filter & Digital WDR feature
User Manual
V1.0
2014-06-05
As our products undergo continuous development the specifications are subject to change without prior notice.
DG-SC8860VI User Manual
2
COPYRIGHT
Copyright 2014 by Smartlink Network Systems Ltd. No part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of this company
This company makes no representations or warranties, either expressed or implied, with respect to
the contents hereof and specifically disclaims any warranties, merchantability or fitness for any
particular purpose. Any software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not this company, its distributor,
or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or
consequential damages resulting from any defect in the software. Further, this company reserves
the right to revise this publication and to make changes from time to time in the contents thereof
without obligation to notify any person of such revision or changes.
Trademarks:
DIGISOL™ is a trademark of Smartlink Network Systems Ltd. All other trademarks are the
property of the respective manufacturers.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it.
However, special attention must be paid to the dangers of electric shock and static electricity when
working with electrical equipment. All guidelines of this and of the computer manufacturer must
therefore be allowed at all times to ensure the safe use of the equipment.
DG-SC8860VI User Manual
3
INDEX
1. Product Information.........................................................................................................................5
1-1 Product Introduction..............................................................................................................5
1-2 Safety Information.................................................................................................................6
1-3 System Requirements............................................................................................................ 7
1-4 Package Contents...................................................................................................................7
1-5 Get Familiar with your new Network Fixed Dome IP Camera............................................. 8
1-6 Installation of the Network IP Camera................................................................................ 11
2 Using Network IP Camera by Web Interface..................................................................................15
2-1 Locate the IP address of Network IP Camera......................................................................15
2-2 Connect to IP camera’s Web User Interface........................................................................ 16
2-3 Viewing Live Video.............................................................................................................20
2-4 Client Settings..................................................................................................................... 23
3. Advanced Configuration................................................................................................................ 25
3-1 System................................................................................................................................. 26
3-2 Security................................................................................................................................27
3-3 Network............................................................................................................................... 29
3-3-1 “General” Setup Page...............................................................................................29
3-3-2 “Advanced” setup page............................................................................................ 31
3-4 IP Filter................................................................................................................................ 33
3-5 Video....................................................................................................................................34
3-5-1 Image Setting........................................................................................................... 35
3-5-2 Video Setting............................................................................................................ 38
3-5-3 Overlay Setting.........................................................................................................40
3-6 Motion................................................................................................................................. 42
3-7 Privacy Mask....................................................................................................................... 44
3-8 Event....................................................................................................................................45
3-8-1 Settings.....................................................................................................................46
3-8-2 Media........................................................................................................................47
3-8-3 Event Server............................................................................................................. 48
3-9 Recording to SD Card/ Samba Server................................................................................. 52
3-10 SDHC................................................................................................................................ 54
DG-SC8860VI User Manual
4
3-11 Log.....................................................................................................................................56
3-12 Device Info........................................................................................................................ 57
3-13 Maintenance...................................................................................................................... 58
3-14 Language........................................................................................................................... 59
4. Using SKYROS i-View software.................................................................................................. 60
4-1 Installing SKYROS i-View Software..........................................................................................60
5 Getting familiar with SKYROS iView Software............................................................................68
5-1 Configure SKYROS iview.................................................................................................. 74
5-1-1 Device...................................................................................................................... 75
5-1-2 Recording................................................................................................................. 78
5-1-3 System...................................................................................................................... 81
5-1-4 Schedule................................................................................................................... 85
5-1-5 Event........................................................................................................................ 88
5-1-6 Security.................................................................................................................... 89
5-2 Video Playback.................................................................................................................... 92
5-2-1 Start Video Playback................................................................................................ 92
5-2-2 Advanced Search......................................................................................................94
5-2-3 Event Search.............................................................................................................98
5-2-4 Video Playback.......................................................................................................102
6 Secureview Application for Android phones/ devices..................................................................104
7 Secureview Application for i-Phones/ i-Pads............................................................................... 118
8 Appendix.......................................................................................................................................129
8-1 Specification...................................................................................................................... 129
8-2 Troubleshooting.................................................................................................................130
8-3 Glossary.............................................................................................................................131
DG-SC8860VI User Manual
5
1. Product Information
1-1 Product Introduction
DG-SC8860VI is a 2Megapixel Fixed Dome IP camera with IR LED and IR-cut Filter. This camera
offers the latest compression technology with a CMOS sensor & a real time image processing
hardware. With its high performance H.264 compression, users can stream high quality video at
low bandwidth and storage capacity requirements. It has IR LED for visibility under no light
condition.The IR cut filter offers a true image quality during day/night operations.
DG-SC8860VI supports Power over Ethernet, which helps in easy installation by eliminating the
need of a dedicated power source for the camera.
DG-SC8860VI supports Digital WDR, a software-based technique that enables the camera to
produce clearer images in less than ideal lighting conditions. Digital-WDR balances the contrast of
light and shadow to improve visibility in dark areas within a scene.
This IP camera complies with IP66 standard thus protecting it from dust and direct sprays from all
directions (limited ingress permitted). The weather-proof and vandal-resistant casing is perfectly
adapted for harsh environments.
Other features of this network IP Camera include:
Ultra-high resolution 2Mega pixel CMOS image sensor.
Supports Digital-WDR
Built-in Micro SD slot for local storage, which can act like a stand-alone DVR.
3GPP Mobile Surveillance Supported.
ONVIF Compliant.
Continuous Recording to Samba Server.
Support IEEE802.3af Power over Ethernet (PoE) standard.
Weatherproof
Vandalproof
DG-SC8860VI User Manual
6
1-2 Safety Information
In order to keep the safety of users and your properties, please follow the safety instructions as mentioned
below. The warranty will become void if you disobey these safety instructions.
This Network IP Camera is sophisticated electronic device; DO NOT drop it from a height.
DO NOT place this IP Camera at hot / humid places, and avoid direct sunlight.
Accessories of this IP Camera like power supply are dangerous to small children. KEEP THIS
IP CAMERA OUT OF REACH OF CHILDREN.
If you want to use this IP Camera at any place that may be spilled by water or dirt, a secure and
water-proof camera housing is required.
DO NOT pull any cord that is connected to this IP Camera by force.
The IP Camera will get heated up when used for a long time. (This is normal and is not a
malfunction). DO NOT put this IP camera on paper, cloth, or other flammable materials.
If the IP Camera falls into water when powered, DO NOT attempt to retrieve it back yourself!
Find a qualified electrical technician for help.
1-3 System Requirements
Windows XP, Vista or Win 7 operating system (both 32 or 64 bits version)
2GB of system memory
1GB of Display card memory
20GB of available hard disk space on system drive
DG-SC8860VI User Manual
7
1-4 Package Contents
Before you start using this IP camera, please check if there’s anything missing in the package, and
contact your dealer of purchase to claim for missing items:
DG-SC8860VI Megapixel Fixed Dome IP Camera (1 No.)
PU foam pad
Installation Guide CD (includes User Manual, QIG & Utility)
Tools Package (includes one allen key, 4 nylon anchors, 4 screws and 4 washers)
Patch Cord
Note: Power Adapter (12V DC, 2A) is NOT a part of the standard package. It will have to be
ordered separately.
DG-SC8860VI User Manual
8
1-5 Get Familiar with your new Network Fixed Dome IP Camera
Front cover:
Item Description
1. Front Cover
Transparent & Metal cover
2. Rear Cover
Metal Cover
1
2
3
DG-SC8860VI User Manual
9
Item Description
1. Bubble Cover Transparent bubble cover, for lens and LEDs protection.
2. Black inner cover Inside protection.
3. Anti - drop line Protective front cover drop during installation.
Rear Cover:
Item Description
1. IR LED Board IR illumination
2. Top Mount For Rotation
3. Mid Mount For Tilt function
4. Down Mount For Pan function
1
2
3
4
5
6
7,8
9
10
DG-SC8860VI User Manual
10
5. LENS Varifocal Lens
6. Main Board PCBA platform
7. SD Board Micro SD card slot
8. Reset button For resetting function (on SD card board)
9. Power Terminal Block J15
10. RJ45 connector Network connection
1-6 Installation of the Network IP Camera
Please follow the instructions mentioned below to setup your new IP camera.
1. Unscrew your front cover by using the tool from the tools package.
